- Page 1 ORTAL SPACE CREATOR FIREPLACES: SPECIFICATIONS & PRODUCT GUIDE...
- Page 2 1. NOTES The appliance must be installed in accordance with the ORTAL AU/NZ Installation Manual. The appliance must be properly connected to an approved chimney venting system. Refer to the specific appliance installation guide to determine vent size and pathway requirements. In addition, adhere to the following pre- installation guidelines: •...
-
Page 3: Specifications
2. SPECIFICATIONS MODEL BURNER INJECTORS NOMINAL GAS INLET MANIFOLD TURNDOWN FLUE SIZE TYPE CONSUMPTION PRESSURE PRESSURE PRESSURE Marked 650: with 26MJ/h 1.13kPA 0.82kPA 0.23kPA 107/164mm 7x0.950mm orifice B100 Marked 1200: with 37MJ/h 0.69kPA 0.73kPA 0.26kPA 125/205mm 7x1.275mm orifice B135 Marked 1200: with 55MJ/h 1.13kPA 0.61kPA... - Page 4 1597 x 424 517 x 424 2213 2035 x 424 517 x 424 Note: Minimum height off of the floor for all front facing Ortal fireplaces is 210mm. Appliance legs must not be removed. OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 4...
- Page 5 OPTION 1: METAL STUDS FRAMING The frame must be designed to carry the entire weight of the finished wall with no component being supported by the fireplace. CLADDING FOR METAL STUDS MODEL (all measurements in mm) SC 75 SC 120 1456 SC 150 1757...
- Page 6 The frame must be designed to carry the entire weight of the finished wall with no component being supported by the fireplace. CLADDING FOR TIMBER STUDS WITH METAL SECTION MODEL (all measurements in mm) SC 75 SC 120 1456 SC 150...
- Page 7 VENTING (Convection air outlet) A convection air outlet is required for all Ortal fireplaces. This allows for heat building up within the fireplace cavity to be released back into the space, helping to keep the cavity walls cool. It must be located at the top of the fireplace cavity and be placed at a maximum of 150mm below the cavity ceiling.
-
Page 8: Access Panel
6. ACCESS PANEL Access panels are recommended for all ORTAL fireplaces. They allow efficient and comfortable access to the fireplace receiver and valves, which is required for servicing purpose. Access panels can designed and positionned to minimise their visual impact as long as access to the valves and receiver is maintained. -
Page 9: Recessed Installation
7. TV CLEARANCES RECESSED INSTALLATION FLUSH INSTALLATION 305mm MIN 305mm MIN OBLICA | SPECIFICATIONS AND PRODUCT GUIDE PAGE 9... - Page 10 8. TESTING THE ORTAL DECORATIVE ROOM SEALED GAS APPLIANCES HAVE BEEN TESTED AND APPROVED BY AGA & IAPMO-R&T FOR USE WITH NATURAL GAS (NG). Australian Standard AS5263-0:2016 - Decorative Gas Log and Other Fuel Effect Appliances Patent Pending for screen barrier glass bracket: USSN 60/040,074...
