- Page 1 OWNER'S MANUAL 16" X 24" SIDE LOCKER M162403SL www.montezumastorage.com...
- Page 2 LIFE ORGANIZED Montezuma is committed to helping you succeed in both your work and personal life by being organized, prepared and equipped with the right tools, gear and home supplies at your finger tips. We are here to ensure that your life is organized.
-
Page 3: Specifications
(32.7 cm W x 45 cm D x 20 cm H) 16-3/4" W x 9-3/8" D x 2" H (42.7 cm W x 23.8 cm D x 5 cm H) WE RECOMMEND USING THIS SIDE LOCKER WITH ANY MONTEZUMA 24" DEEP TOOL COMBO THAT IS 46" OR WIDER... -
Page 4: Parts List
PARTS LIST The keys are taped to the shelf. REF DESCRIPTION PART NUMBER M4 x 5 mm Phillips Head Bolt 320060 Handle 301883 Till Liner 552158 Lock and Key (1201–1204) 304166 Shelf 242013 Shelf Support 203902 Shelf Liner 552157 Drawer Liner 552159 314219 Slide Set... - Page 5 M4 x 5 mm Phillips Head Bolt Handle Pre-installed Pre-installed Till Liner For attached the handle For opening lid For protecting your till Lock and Key Shelf Shelf Support For securing For placing at your valuables desired height For installing the shelf Drawer Liner Shelf Liner For the bottom pivot...
- Page 6 M6 x 20 Counter Hanger Connector Sink Screw For hanging the side For attaching the side For installing the hanger cabinet on a tool cabinet locker to a tool combo M6 x 12 mm Hex Bolt Cantridge Magnet Gas Strut Pre-installed Pre-installed For attaching...
-
Page 7: Hanger Installation
HANGER INSTALLATION The hanger can be mounted on either side of a tool cabinet. If necessary, remove the side handles from the tool cabinet. To install the hanger, position it over the holes in the tool cabinet and attach using four M6 x 20 counter sink screws. -
Page 8: Shelf Installation
SIDE LOCKER-CABINET CONNECTION Remove the end covers from the side panel of the side locker. Hang the side locker on your tool cabinet. Position the connector on the back of the side locker and tool cabinet. Attach to the side locker using two M6 x 12 hex bolts and to the tool cabinet with two M6 x 12 hex bolts. -
Page 9: Door Reversal
DOOR REVERSAL To reverse the door, pull off the pivot and remove the door. Then install the door on the other side by inserting the pivot. Be sure to move the mat on the bottom of the door and the magnet to the other side. DRAWER REMOVAL Pull the drawer out so that it’s almost fully extended. -
Page 10: Maintenance
MAINTENANCE Periodically clean the drawer fronts, trim, and other surfaces with mild detergent and water. Lubricate the slides (twice a year) with a product like WD40 or other quality lubricant. This is especially important in low temperatures, which can cause the bearing to become stiff. Grease and oil can be removed with most standard cleaning fluids. - Page 11 This product is warranted to be free from defects in materials and workmanship for a period of five (5) years from the date of original purchase. If this product is defective, email service@montezumastorage.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the product is defective, we will replace the defective part at no cost to you.
- Page 12 Manufactured by: QUALITY CRAFT Surrey, BC, Canada V3S 5N4 service@montezumastorage.com 1-800-459-4409 (Monday to Friday, 8:00 am–4:30 pm, CST) Made in China www.montezumastorage.com M162403SL _02/19...
