Montezuma 3005UC Owner's Manual

30" 5-drawer utility cart
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
30" 5-DRAWER
UTILITY CART
3005UC
www.montezumastorage.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3005UC and is the answer not in the manual?

Questions and answers

Related Manuals for Montezuma 3005UC

Summary of Contents for Montezuma 3005UC

  • Page 1 OWNER'S MANUAL 30" 5-DRAWER UTILITY CART 3005UC www.montezumastorage.com...
  • Page 2 LIFE ORGANIZED Montezuma is committed to helping you succeed in both your work and personal life by being organized, prepared and equipped with the right tools, gear and home supplies at your finger tips. We are here to ensure that your life is organized.

  • Page 3: Specifications

    SPECIFICATIONS MAXIMUM PRODUCT WEIGHT (INCLUDING CONTENTS): 600 lb (272 kg) MAXIMUM DRAWER WEIGHT: 100 lb (45 kg) OVERALL DIMENSIONS: 36-3/4" W x 18-1/8" D x 37" H (93.2 cm W x 46 cm D x 91.3 cm H) NET WEIGHT: 158 lb (71.67 kg) INSIDE DRAWER DIMENSIONS: REF DIMENSIONS 26-5/8"...

  • Page 4: Parts List

    PARTS LIST The keys are taped to the top drawer.
  • Page 5 REF DESCRIPTION PART NUMBER QTY M6 x 16 mm Hex Bolt 301206 Side Handle 360501 Swivel Caster 502001 Rigid Caster 502002 Washer 608060 Spring Washer 608061 Slide Set 360505 Drawer Liner 360502 Lock and Key (1301–1313) 608001 Support Post 306510 Bracket 360508 Tray Liner...

  • Page 6: Handle Installation

    HANDLE INSTALLATION NOTE: Assemble the handle first to make it easier to move the cart. Position the handle over the holes in the cart and attach with the M6 x 16 mm hex bolts provided. Tighten securely. BOTTOM TRAY INSTALLATION CAUTION: Two or more people are required to lay down or stand up the service cart.

  • Page 7: Caster Installation

    CASTER INSTALLATION While the service cart is still lying on its back, position the two swivel casters on the bottom, on the same side as the handle. Insert four M10 x 30 mm hex bolts through spring washers and washers, then through each caster and into the bottom of the service cart.

  • Page 8: Drawer Removal

    RAISE AND RELEASE DRAWER FRONTS These units are equipped with raise and release drawer fronts. To open, lift up on the drawer front while pulling towards you. To close, shut the drawer firmly until the latch engages. If the drawer does not stay closed, the hook may be bent, or it may be rubbing against the drawer slides.

  • Page 9: Maintenance

    MAINTENANCE Periodically clean the drawer fronts, drawer trim, and other surfaces with mild detergent and water. Lubricate the casters with high quality bearing grease (annually/yearly). Lubricate the slides (twice a year) with a product like WD40 or other quality lubricant. This is especially true as the temperature decreases, which can cause the bearing to become stiff.
  • Page 10 SAFETY Do not attempt to lift the unit by its side handles using chains, ropes or other lifting devices. The side handle could fail, which may cause personal injury or damage to the product. Lock the drawers before moving this product. The drawers could come open and make the product unstable and tip, which may cause personal injury or product damage.
  • Page 11 This product is warranted to be free from defects in materials and workmanship for a period of five (5) years from the date of original purchase. If this product is defective, email service@montezumastorage.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the product is defective, we will replace the defective part at no cost to you.
  • Page 12 Manufactured by: QUALITY CRAFT Surrey, BC, Canada V3S 5N4 service@montezumastorage.com 1-800-459-4409 (Monday to Friday, 8:00 am–4:30 pm, CST) Made in China www.montezumastorage.com FORM # 3005UC -10/19...
