- Page 1 OWNER'S MANUAL 56" X 24" HUTCH AND TOOL CABINET M562411TC-H www.montezumastorage.com...
- Page 2 LIFE ORGANIZED Montezuma is committed to helping you succeed in both your work and personal life by being organized, prepared and equipped with the right tools, gear and home supplies at your finger tips. We are here to ensure that your life is organized.
-
Page 3: Specifications
SPECIFICATIONS MAXIMUM PRODUCT WEIGHT (INCLUDING CONTENTS): 2,100 lb (952 kg) MAXIMUM SHELF WEIGHT CAPACITY (HUTCH): 100 lb (45 kg) MAXIMUM DRAWER WEIGHT (CABINET): 150 lb (68 kg) POWER STRIP MODEL: LTS-04C/CH-04C SURGE PROTECTIVE DEVICES RATING: 120 V AC 15 A 60 Hz 1875 W USB: TOTAL 2.1 A –... - Page 4 56" x 24" HUTCH AND TOOL CABINET M562411TC-H OVERALL DIMENSIONS: 56" W x 24-5/8" D x 66-1/8" H (142.2 cm W x 62.5 cm D x 168 cm H) NET WEIGHT: 489 lb (222 kg)
- Page 5 HUTCH DIMENSIONS: 56" W x 24-5/8" D x 25" H (142.2 cm W x 62.5 cm D x 63.5 cm H) CABINET DIMENSIONS: 56" W x 24-5/8" D x 41-1/8" H (142.2 cm W x 62.5 cm D x 104.5 cm H) INSIDE DRAWER DIMENSIONS: REF DIMENSIONS 51-7/8"...
- Page 6 HUTCH PARTS LIST The keys are taped to the door. REF DESCRIPTION PART NUMBER Grommet 314027 M8 x 20 Hex Bolt 321024 Power Strip 333059 Shelf 242035 Washer 324002 M8 x 40 Hex Bolt 321048 Gas Strut 303218 Lock and Key (1201–1204) 304166 To order replacement parts, email service@montezumastorage.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST).
- Page 7 M8 x 20 Hex Bolt 6 for attaching side panels 4 for supporting adjustable shelf Grommet 6 for connecting hutch to cabinet without worktop (optional) For cord access Shelf Washer Power Strip For placing at For use with M8 x 20 For power management desired height Hex Bolt...
-
Page 8: Cabinet Parts List
CABINET PARTS LIST They keys are taped to the top of the caster carton, which is placed in the bottom right drawer of the cabinet. REF DESCRIPTION PART NUMBER Work Top 572013 Power Strip 333059 Grommet 314027 Cabinet Handle 306142 M6 x 12 mm Phillips Head Bolt 320323 Cord Wrap... - Page 9 Work Top Power Strip Grommet For using as a work surface For power management For cord access M6 x 12 mm Phillips Head Bolt Cabinet Handle Cord Wrap For attaching cabinet For assisting in moving For holding the power cord handles and cord wrap the cabinet Washer...
- Page 10 Lock and Key Drawer Liner For securing your valuables For protecting wide drawer...
-
Page 11: Caster Installation
CABINET HANDLE INSTALLATION NOTE: Assemble the handles first to make it easier to move the cabinet. Position the handles over the holes in the cabinet and attach with the M6 x 12 mm Phillips head bolts provided. Tighten securely using a 10 mm socket. CASTER INSTALLATION CAUTION: Two or more people are required to lay down or stand up the cabinet. - Page 12 CABINET CORD WRAP INSTALLATION Position the cord wrap over the holes in the cabinet. Attach with the M6 x 12 mm Phillips head bolts provided. Tighten securely. CABINET POWER STRIP INSTALLATION Cut the black strip holding the cord, then Black pull the white strip to get the plug out of the cabinet and through the grommet.
- Page 13 HUTCH ASSEMBLY Unfold the hutch body as shown. Attach the left and right side panels to the back of the hutch body using three M8 x 20 hex bolts and washers per panel.
- Page 14 Open the hutch door and install the gas strut. Proceed with connecting the hutch to the cabinet before installing the shelf in the hutch. HUTCH-CABINET CONNECTION WARNING: FOR YOUR SAFETY, MOUNT THE HUTCH TO THE CABINET USING ONLY THE HARDWARE PROVIDED. CONNECTING THE HUTCH TO A CABINET WITH A WORKTOP Put the hutch onto the worktop.
- Page 15 On the worktop, mark the locations of the six slotted holes in the hutch. Take the hutch off the cabinet. Remove the worktop by first removing the drawers, then loosening the M6 x 12 Phillips head bolts. Place the worktop on the floor. Drill six 7/16" (1.1 cm) holes at the locations you marked.
- Page 16 Place the worktop and hutch back onto the cabinet. Make sure that both the hutch and the worktop are flush with the front edge of the cabinet and that there are equal gaps on the sides. Connect the hutch, worktop and cabinet together using six M8 x 40 hex bolts and washers.
-
Page 17: Drawer Removal
RAISE AND RELEASE DRAWER FRONTS These units are equipped with raise and release drawer fronts. To open, lift up on the drawer front while pulling towards you. To close, shut the drawer firmly until the latch engages. Lift If the drawer does not stay closed, the hook may be bent, or it may be rubbing against the drawer slides. -
Page 18: Maintenance
MAINTENANCE Periodically clean the drawer fronts, trim, and other surfaces with mild detergent and water. Lubricate the casters with high quality bearing grease (annually/yearly). Lubricate the slides (twice a year) with a product like WD40 or other quality lubricant. This is especially important in low temperatures, which can cause the bearing to become stiff. - Page 19 This product is warranted to be free from defects in materials and workmanship for a period of five (5) years from the date of original purchase. If this product is defective, email service@montezumastorage.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the product is defective, we will replace the defective part at no cost to you.
- Page 20 Manufactured by: QUALITY CRAFT Surrey, BC, Canada V3S 5N4 service@montezumastorage.com 1-800-459-4409 (Monday to Friday, 8:00 am–4:30 pm, CST) Made in China www.montezumastorage.com M562411TC -H _09/20...
