- Page 1 OWNER'S MANUAL ADJUSTABLE STEEL FRAME MSF4829B www.montezumastorage.com...
- Page 2 LIFE ORGANIZED Montezuma is committed to helping you succeed in both your work and personal life by being organized, prepared and equipped with the right tools, gear and home supplies at your finger tips. Keep your life organized with Montezuma.
-
Page 3: Specifications
SPECIFICATIONS MAXIMUM PRODUCT WEIGHT: 1000 lb (450 kg) of static, evenly distributed weight Weight capacity does not include work top. Depending on the work top used, weight capacity may be reduced. FULLY EXTENDED DIMENSIONS: 64" W x 17" D x 41" H (162.5 cm W x 43.2 cm D x 104 cm H) Steel frame width adjusts from 40"... -
Page 4: Parts List
M6 x 10 mm Bolt 122328 Leveling Feet 122326 Montezuma Nameplate 121701 To order replacement parts, email service@montezumastorage.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). Have the part number and quantity ready. Replacement keys may be ordered using the code that appears on the face of the lock. - Page 5 M6 x 10 mm Bolt M6 Hex Nut For frame assembly For use with the bolts Leveling Feet Montezuma Nameplate For leveling the workbench For attaching to the front of the workbench...
- Page 6 ASSEMBLY Install one of the leveling feet at the bottom of each adjustable leg section. Slide each adjustable leg section onto a main leg section until you reach the desired height. Take into consideration the thickness of the work top you will be using – you will need to reduce the length of the leg by the thickness of your work top to hit your targeted height.
- Page 7 Take two of the four cross bar pieces and slip them together with the top flanges facing in the same direction. You will see three sets of four holes – you can join the two cross bars together at any of these hole patterns. (The other end of each cross bar only has two holes, which will attach to a leg assembly.) For a 4' wide work top, line up the four holes labeled A in the illustration below with the four holes labeled D.
- Page 8 Turn the workbench upright and place in the location it will be used. Check to make sure the frame is still level. If you need to adjust, use the leveling feet. Attach the Montezuma Nameplate to the right hand side of the front cross bar using the self-adhesive backing.
-
Page 9: Maintenance
MAINTENANCE Periodically tighten all hardware and make sure frame is level. SAFETY DO NOT let children play or hang on the edge of the unit. It could tip and cause personal injury or product damage. DO NOT stand or lean on the work top on the steel frame. The unit could tip and cause personal injury or product damage. - Page 10 This product is warranted to be free from defects in materials and workmanship for a period of one (1) year from the date of original purchase. If this product is defective, email service@montezumastorage.com or call 1-800-459-4409 (Monday–Friday, 8:00 am–4:30 pm, CST). If the product is defective, we will replace the defective part at no cost to you.
- Page 12 Manufactured by: QUALITY CRAFT Romeoville, IL 60446 service@montezumastorage.com 1-800-459-4409 (Monday to Friday, 8:00 am–4:30 pm, CST) Made in China www.montezumastorage.com FORM#: MSF4829B-01/20...
