Models EVA
EVA-C, EVA-T
& EVA-C-T
Quick Setup
Instructions
WARNING: Electrical and
SANI/DETERGENT
plumbing connections
need to be made by a
licensed service person
and comply with all
Federal, State and Local
Health, Electrical,
Plumbing and Safety
NORMAL-OFF DELIMER
codes.
1
STEP
1
Connect dishmachine to hot water source
recommended 140° temperature (120°
minimum temperature required).
STEP
2
Connect hard wire power supply from
dishmachine to power box.
SWITCH
DRAIN/RINSE
SWITCH
SWITCH
ON/OFF
POWER SWITCH
1/2" WATER
INLET
STEP
3
Connect a 2" drain pipe (not
supplied) from scrap accumulator
to floor or wall drain.
MODEL EVA REAR VIEW
3
2" DRAIN
OUTLET
8"
WALL
DRAIN
FLOOR DRAIN
800-854-6417
HARD WIRE
POWER SUPPLY
TUBE
4
STIFFENER
CHEMICAL
4
TUBING
STEP
4
WHITE
RED
Insert tube stiffener with chemical tubing
into each corresponding chemical
dispensers.
2
BLUE
5-2007
