Parameter Table - Carel ir33+ User Manual

ENG
For a detailed explanation of these parameters, see the standard ir33+ user manual.
The rows of the table in grey correspond to masked parameters.
User Par. Description
Pro
C /2 Probe measurement stability
C /3 Probe display stability
Value
0
1
2
3
4
5
6
7
C /4 "Virtual probe composition
0 = Control probe S1 - 100 = Probe S2"
C /5 Temperature unit of measure: 0 = °C; 1 = °F
C /6 Display decimal point: 0/1=no/yes
C /tI Display on user terminal
1 - Virtual probe
2 - Probe 1
3 - Probe 2
4 - Probe 3
5 - Probe 4
6 - Reserved
7 - Set point
C /tE Reading on remote display
0 - Not fi tted
1 - Virtual probe
2 - Probe 1
4 - Probe 3
5 - Probe 4
6 - Reserved
C /P "Type of probe
0 = NTC Standard Range -50T90°C
1 = NTC Enhanced Range -40T150°C
2 = PTC Standard Range -50T150°C"
C /A2 "Probe 2 confi guration (S2)
0 - Absent
1 - Product (display only)
2 - Defrost
3 - Condenser
4 - Frost"
C /A3 "Probe 3 confi guration (S3/ DI1)
0 - Digital input 1
1 - Product (display only)
2 - Defrost
3 - Condenser
4 - Frost"
C /A4 "Probe 4 confi guration (S4/ DI2)
0 Digital input 2
1 Product (display only)
2 Defrost
3 Condenser
4 Frost"
ir33+ VCC +040000058 - rel. 1.2 - 15.02.2018
4.

PARAMETER TABLE

Display Value Display
delay. (s) delay. (s)
disabled 8
5 9
10 10
15 11
20 12
25 13
30 14
40 15
Def. Min Max
4 1 15
0 0 15
50
60
75
90
105
120
150
180
0 0 100
0 0 1
0 0 1
1 1 7
0 0 6
0 0 2
2 0 4
0 0 4
0 0 4
22
UOM Type Carel ModBus® R/W
SPV
- I 17 117
- I 18 118
- I 19 119
- D 43 43
- D 44 44
- I 20 120
- I 21 121
- I 22 122
- I 23 123
- I 24 124
- I 25 125
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
