Bison BA778 Instruction Manual

—— Instruction Manual ——
M
ODEL
Heavy Duty Playground Pole
P A R T S L I S T
Item Qty Description
A 1 Backboard Mounting Bracket
B 3 4-1/2" Band Clamp
C 2 7/16" x 2" Carriage Bolt
D 2 3/8" x 1" Hex Bolt
E 2 3/8" Lock Washer
F 2 3/8" Flat Washer
G 3 5/16" x 2" Carriage Bolt
H 3 5/16" Flange Nut
I 1 4-1/2" Pole Cap
J 2 7/16" Hex Nut
♦
Inspect all contents prior to installation. Report any missing parts to dealer immediately.
♦
Read all instructions before proceeding.
2 Ea. 9/16" Combination Wrench
2 Ea. 5/8" Combination Wrench
1 Ea. 3/4" Combination Wrench
1 Ea. Adjustable Wrench
Date: 11-29-04 Rev: 2
B 778
A

TOOLS/MATERIALS REQUIRED

B.A. N.J.C.
Item Qty Description
K 2 7/16" Flat Washer
L 2 7/16" Lock Washer
M 2 4-1/2" U-Bolt
N 2 Backboard Brace
O 2 1/2" Set Screw, Square Head
P 2 1/2" Jam Nut
Q 4 1/2" Flat Washer
R 4 1/2" Lock Washer
S 4 1/2" Hex Nut
1 Ea. Level
1 Ea. Tape Measure
1 Ea. 12" Post Hole Digger and/or a Shovel
8-10 Ea. 60# Bag of Premix Concrete
File: Bisonserver/publisher/instructions/BA778
Page 1
Customer Service
(800) 247-7668
Ref#: 920228
