SPECTRAL BANDWIDTH CALCULATION FORMULA & GRATINGS LIST

GRATINGS TABLE

Gratings for Omni- λ 150:
Zolix Part number
1-240-H
1-240-V
1-180-H
1-180-500
1-120-300
1-120-500
1-120-750
1-120-1000
1-060-300
1-060-500
1-060-750
1-060-1000
1-060-1250
1-060-1600
1-030-500
1-030-750
1-030-1000
1-030-1250
1-030-1800
1-030-2000
1-030-3000
1-015-500
1-0075-8000
14
Wavelength
range(nm)
UV
可见
UV
300-800
200--600
330-1000
500--1200
650--1200
200—600
330-1000
500--1500
650--2000
800-2400
1000-2400
330-1000
500-1500
650-2000
800-2500
1200-3600
1200-4000
1200-4800
330-1000
6000-16000
Line density (g/
Blazing (nm)
mm)
240 Holographic
240 Holographic
180 Holographic
1800 500
1200 300
1200 500
1200 750
1200 1000
600 300
600 500
600 750
600 1000
600 1250
600 1600
300 500
300 750
300 1000
300 1250
300 1800
300 2000
300 3000
150 500
75 8000
Size (mm)
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
68×68
