Zephyr Tornado II Use, Care And Installation Manual page 24

Wiring Diagram
BODY
BODY
24
AK83 Single Blower Wiring Diagram
COM
TRANSFORMER
AC120V
AK83 Dual Blower Wiring Diagram
GREY
BLACK
GREEN
GREEN
BLACK
GREY
COM
TRANSFORMER
AC120V
Tornado II & Tornado III Use, Care, and Installation Guide
BODY
GREEN
WHITE
YELLOW
RED
BLUE
WHITE
YELLOW
RED
BLUE
