Assembly of Evelo Delta X
The focus of this document is to assist with the assembly of your new EVELO Delta X.
The scope is intentionally narrow – The "User Guide" that was included with your bike
covers a much broader spectrum of topics: fit adjustments, battery care, controls etc.
Our Team is here to help 7 days a week!
Watch the Assembly
contact@evelo.com | 877-991-7272
Instructions Video
Feel Free to reach out!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Evelo Delta
Summary of Contents for Evelo Delta
- Page 1 Assembly of Evelo Delta X The focus of this document is to assist with the assembly of your new EVELO Delta X. The scope is intentionally narrow – The “User Guide” that was included with your bike covers a much broader spectrum of topics: fit adjustments, battery care, controls etc.
- Page 2 Carefully remove all packing material from Tools and User Guides will be in the small bike, avoid using sharp objects as to protect black Evelo box. The Pedals will be in a the paint. small cardboard box. Lower kickstand to keep bike upright during assembly.
- Page 3 Install Fender and Headlight Remove the screw in the Front Fork. Remove Spacer. Thread Headlight and Spacer onto screw. Attach Headlight and Fender assembly to fork. ASSEMBLY OF EVELO DELTA X...
-
Page 4: Install Front Wheel
Install Front Wheel Remove bolts from each side of fork and attach lower fender support struts. Remove black Axle from front fork. Put Front Wheel into Place Replace black Axle and tighten. ASSEMBLY OF EVELO DELTA X... -
Page 5: Install Handlebars
Install Handlebars Remove the 4 screws on top of the stem faceplate. Place Handlebars in cradle and align Replace cover and the 4 screws on top with center. of handlebars. ASSEMBLY OF EVELO DELTA X... -
Page 6: Install Pedals
There is an L and an R stamped into the end of each pedal for reference. It is important to note that the pedals are threaded differently. The right pedal screws in clockwise and the left pedal screws in counter-clockwise. right pedal left pedal ASSEMBLY OF EVELO DELTA X... -
Page 7: Use Of Battery
Plug the charger into any standard outlet. It is charged when the red light turns green. This can be done with the battery either on or off the bike. Power up and you’re ready to ride! ASSEMBLY OF EVELO DELTA X... -
Page 8: Serial Number Location
Serial Number Location To register your bike on our website, you will need to record the serial number. It is located on the headtube of your bike, just above the front fork. ASSEMBLY OF EVELO DELTA X... - Page 9 There is considerable additional information in your “User Guide”. Of course, if you ever have questions, our team is ready to help! Our Team is here to help 7 days a week! contact@evelo.com | 877-991-7272 Feel Free to reach out!
