EVELO Omega Assembly
The focus of this document is to assist with the assembly of your new EVELO
Omega. The scope is intentionally narrow – The "User Guide" that was
included with your bike covers a much broader spectrum of topics: fit adjust-
ments, battery care, controls etc.
Watch the Assembly
Our Team is here to help 7 days a week
contact@evelo.com | 877-991-7272
Instructions Video
Feel free to reach out!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Omega and is the answer not in the manual?

Questions and answers

Related Manuals for Evelo Omega

Summary of Contents for Evelo Omega

  • Page 1 EVELO Omega Assembly The focus of this document is to assist with the assembly of your new EVELO Omega. The scope is intentionally narrow – The “User Guide” that was included with your bike covers a much broader spectrum of topics: fit adjust- ments, battery care, controls etc.
  • Page 2 Carefully remove all packing material from Tools and User Guides will be in the small bike, avoid using sharp objects as to protect black Evelo box. The pedals will be in a the paint. small cardboard box. Lower kickstand to keep bike upright during assembly.
  • Page 3 Step 2 into stem, and tighten until so that headset spacers from Step 1. spacers no longer rotate. Use a 4mm allen wrench to tighten both bolts Align handlebars with fork. on the side of the stem. ASSEMBLY OF EVELO OMEGA...
  • Page 4 Install Fender and Headlight Remove bolt from front fork assembly. Slide bolt through headlight, fender, and fork. Attach headlight and fender assembly to fork. Position the fender as high up as possible and tighten the bolt and nut. ASSEMBLY OF EVELO OMEGA...

  • Page 5: Install Front Wheel

    Lift the fork, place the wheel partially in the Slide the thru-axle into the fork and wheel and fork, then line up the brake rotor between the securely tighten with an allen wrench. pads and mount the wheel fully into the fork. ASSEMBLY OF EVELO OMEGA...
  • Page 6 Mount Fender Remove bolts from each side of fork and attach lower fender support struts. Make sure to install washer and spacer as shown. Tighten fender support strut hardware. ASSEMBLY OF EVELO OMEGA...

  • Page 7: Install Pedals

    There is an L and an R stamped into the end of each pedal for reference. It is important to note that the pedals are threaded differently. The right pedal screws in clockwise and the left pedal screws in counter-clockwise. ASSEMBLY OF EVELO OMEGA...

  • Page 8: Use Of Battery

    Use the key to unlock the battery, the battery the handlebars. releases downward. The battery is heavy, please be careful. When reinstalling, push the battery into place firmly. Power up the bike and you’re ready to ride! ASSEMBLY OF EVELO OMEGA...

  • Page 9: Serial Number Location

    Serial Number Location To register your bike on our website, you will need to record the serial number. It is located on the headtube of your bike, just above the front fork. ASSEMBLY OF EVELO OMEGA...
  • Page 10 There is considerable additional information in your “User Guide”. Of course, if you ever have questions, our team is ready to help! Our Team is here to help 7 days a week! contact@evelo.com | 877-991-7272 Feel Free to reach out!
