The focus of this document is to assist with the assembly of your new EVELO

Delta X. The scope is intentionally narrow -- The "User Guide" that was

included with your bike covers a much broader spectrum of topics: fit

Unboxing Your EVELO

1. Begin unboxing the bike by cutting the

banding then opening the box. Use caution

regarding the staples as they can be very

sharp.

2. Remove the small boxes.

3. The easiest way to get the bike out of the

box is to lie the box down on its side and

then slide it out. See image ----->

4. Remove packaging including zip ties.

Caution: sometimes the zip ties are used to

hold cables or wires in place. A good indi-

cator is if the zip tie is touching a painted

surface of the bike—those should remain in

place.

5. Empty all the boxes so you know what

you are working with.

Assembly of EVELO Delta X

adjustments, battery care, controls etc.

Our Team is here to help 7 days a week!

contact@evelo.com

877-991-7272

Feel Free to reach out!

Table of Contents

Do you have a question about the Delta X and is the answer not in the manual?

Page 1 Assembly of EVELO Delta X The focus of this document is to assist with the assembly of your new EVELO Delta X. The scope is intentionally narrow -- The “User Guide” that was included with your bike covers a much broader spectrum of topics: fit adjustments, battery care, controls etc.
Page 2 Rotate Fork (if needed) Depending on how the bike was packed at the factory, you may need to turn the forkso that the Fork Arch is facing forward. If needed, rotate the steering assembly so that the cables aren’t wrapped around the frame and the arch is facing forward.
Page 3 Install fender and headlight (cont.) 3. On the fork legs there are two brackets near the bottom. 4. After removing them, pass one of the supplied bolts through a washer, then the bracket, the loop in the strut, add a washer, thread on the nut. Tighten with tools provided.
Page 4 Install Pedals Installation of the pedals requires a 15 mm wrench. It is important to note that the pedals are threaded differently. The right pedal will screw in clockwise, and the left pedal will screw in counterclockwise. There is an L and an R stamped into the end of each pedal for refer- ence.
Page 5 It is located on the headtube of your bike, just above the front fork. There is considerable additional information in your “User Guide”. Of course, if you ever have questions, our team is ready to help! contact@evelo.com 877-991-7272...
