G A LAXY
OWNER'S MANUAL
Important Safety and Product Information
EVELO.COM
galaxy_manual_single.indd 1
09/06/2017 19:52

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GALAXY and is the answer not in the manual?

Questions and answers

Summary of Contents for Evelo GALAXY

  • Page 1 G A LAXY OWNER’S MANUAL Important Safety and Product Information EVELO.COM galaxy_manual_single.indd 1 09/06/2017 19:52...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Welcome! Contact Information Unboxing Registration Warranty Battery Care and Maintenance Assembly Riding Your EVELO Electric Bicycle Maintenance Troubleshooting galaxy_manual_single.indd 2 09/06/2017 19:52...
  • Page 3: Welcome

    The Galaxy has been tested and recommended for use by riders weighing 300 pounds (136 kilograms) or less. CONTACT INFORMATION Your enjoyment of —...
  • Page 4: Unboxing

    A small box is included containing the charger and some smaller parts. Be sure to open that box prior to beginning assembly. Included with your bike are the following: • EVELO Owner’s Manual • Battery Keys • Left and Right Pedals •...
  • Page 5: Registration

    The frame’s serial number is located on the head tube, just above the front fork. Please note that your keys are unique to your bicycle and EVELO cannot provide exact replacements. We recommend using one key for day-to-day use, while storing the other in a safe place.
  • Page 6: Warranty

    WARRANTY Warranty Overview Every EVELO Electric Bicycle comes with a 4 year / 20,000 mile warranty against manufacturing defects in materials or workmanship on its frame, battery, controller, and motor assembly. This warranty applies only to the original registered owner of the EVELO bicycle and is not transferable.
  • Page 7 For warranty issues, EVELO will cover the cost of labor involved handling the warranty service within the 30-day period after purchase. To receive this service, the customer should contact EVELO directly, and we will make the necessary arrangements.
  • Page 8: Battery Care And Maintenance

    BATTERY CARE & MAINTENANCE The battery provided with your EVELO electric bicycle is a high-quality unit that requires very little from the user in terms of care. However, a few things are worth noting with respect to any lithium-ion battery.
  • Page 9: Assembly

    The charger that comes with your bike has internal controls that prevent overcharging of the battery. ASSEMBLY OF YOUR EVELO ELECTRIC BICYCLE NOTE If you do not have the ability or skill to assemble the bicycle yourself, please take it to a local bike shop for professional assembly.
  • Page 10 ASSEMBLY ST E P 1 Rotate Fork Turn the front fork 180 degrees so that the stem (where the handlebars will attach) is facing forward and the wires/cables are not wrapped around the frame. S T E P Install Front Wheel The front wheel is attached to the bike with a quick-release type of skewer.
  • Page 11 Lift the front wheel and spin it. As it spins, squeeze the lever and make sure the wheel stops. If the wheel doesn’t stop before the lever reaches the handlebar grip, contact our customer service department for adjustment guidance: contact@evelo.com or 877-991-7272, 7 days / week. EVELO.COM galaxy_manual_single.indd 11...
  • Page 12 ST E P 3 Attach Front Fender Using the wrench, allen wrench, bolt and nut provided, install the fender using the hole passing through the fork as shown: Then, secure both fender struts near the front axle as shown: S TE P 4 Attach Handlebars Remove the bolts that hold the handlebar clamping bracket on.
  • Page 13 Locate the left-side pedal (marked with an “L”). Thread the “L” pedal COUNTER-CLOCKWISE* onto the non-drive-side crank (side of the bike without gears). Tighten the “L” pedal COUNTER-CLOCKWISE with a 15 mm wrench or the wrench provided. EVELO.COM galaxy_manual_single.indd 13 09/06/2017 19:52...
  • Page 14 ST E P 8 Fit Adjustments Many parts of your new EVELO Electric Bicycle can be customized for a personalized fit. Seat Adjustment The seat is easily adjusted up or down by releasing the lever that clamps the post into the bike.
  • Page 15: Riding Your Evelo Electric Bicycle

    Lower pressure will give a softer ride. A higher pressure will provide a firmer ride, but will give the best range per charge. Using a pump (not included), inflate the tires to within this range. RIDING YOUR EVELO ELECTRIC BICYCLE PRE-RIDE CHECKLIST Carry out this pre-ride checklist before EVERY RIDE! Make sure the tires are properly inflated.
  • Page 16 QUICK-START GUIDE TO OPERATING THE DISPLAY PANEL Full instructions for your display panel are online at http://support.evelo.com/ support/solutions (Search for “Galaxy Display”), but some of the most basic functions are listed here for your convenience. The following images are useful reference. galaxy_manual_single.indd 16 09/06/2017 19:52...
  • Page 17 6. Data Reset Double Press the MODE button quickly to reset temporary data, including AVG Speed / MAX Speed / Trip / Time. * These temporary data are not erased by power off. EVELO.COM galaxy_manual_single.indd 17 09/06/2017 19:52...
  • Page 18 A NOTE ABOUT DISC BRAKES Your bike is equipped with disc brakes, you can prevent brake squeal by properly “embedding” the brake pads. It is important to do this when the brake pads are new. Select an area in which to ride that allows you to reach a moderate speed safely. Accelerate to a moderate speed and apply the brakes evenly, slowing the bike to a walking pace.
  • Page 19 ACHIEVING THE BEST PERFORMANCE FROM YOUR EVELO ELECTRIC BICYCLE THE MID-DRIVE MOTOR One of the special features of your new bicycle is its mid-drive motor. This design allows the motor, as well as the rider, to take advantage of gear changes in the shifting system, improving efficiency.
  • Page 20 RIDING IN THE RAIN EVELO Electric Bicycles are designed so that you can operate them in rainy weather. Factory-level design elements keep the electrical components well-protected and nearly all the electrical connections are located within the frame.
  • Page 21 Avoid road hazards. Watch for and avoid potholes, drain grates, railroad tracks, loose road material, and other hazards. • Use both the front and the rear brakes together for best performance. Using ONLY the rear will significantly increase your stopping distance. EVELO.COM galaxy_manual_single.indd 21 09/06/2017 19:52...
  • Page 22: Maintenance

    If your brakes are worn beyond this adjustment, either take the bike to a local bike shop for professional service, or contact EVELO for additional instructions. • Tune-Up — We recommend a full-service tune-up annually by a professional bicycle mechanic.
  • Page 23: Troubleshooting

    TROUBLESHOOTING If you experience difficulty with your EVELO Electric Bicycle, consult the following list. If you do not find the problem on this list, contact our Customer Service Team, and we will work with you to identify the source of the problem and help with a solution.
  • Page 24 Questions? Get In Touch: Email: contact@evelo.com Call: 877-991-7272 EVELO.COM EVELO.COM Galaxy 2nd Edition galaxy_manual_single.indd 24 09/06/2017 19:52...
