AU: 1800 029 701
NZ: 0800 466 444
This kit is applicable to the following sheds:
23151GK
30152GK
23231GK/TK
30232GK
23232GK
30302GK/TK
23301GK
The addition of this frame kit will increase the
wind rating of the specified sheds to
Wind rating: N3/C1 as per AS4055-2012.
Suitable for specific cyclonic regions
DOWNLOAD
OUR APP FOR
ASSEMBLY
VIDEOS
Absco Industries
Assembly Instruction Manual
GABLE SHED
N3/C1 FRAME KIT
FOR PREMIER MODELS
admin@absco.com.au
www.abscosheds.com.au
37152GK
37232GK/TK
37302GECOK
View of frame kit applied to
Where information conflicts with the original
non-cyclonic
instruction
document is to be referenced.
WARNING: This shed must be anchored to a
100mm thick concrete slab with the concrete
anchors supplied.
Failure to do so will result in the shed not
having the structural integrity required to
endure a severe storms or cyclonic event.
WARNING: Doors must remain closed with
all padbolts properly secured during severe
storms or cyclonic event.
LEAVE A REVIEW
Tell us about your experience and
receive a $20 Coles Gift Card.
Visit www.abscosheds.com.au/review
Model: CYCGK
30302GK
manual,
this
02/03/21
1.5
1
Advertisement
Related Manuals for ABSCO SHEDS N3/C1 FRAME KIT
Summary of Contents for ABSCO SHEDS N3/C1 FRAME KIT
- Page 1 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS AU: 1800 029 701 admin@absco.com.au NZ: 0800 466 444 www.abscosheds.com.au View of frame kit applied to 30302GK Where information conflicts with the original non-cyclonic instruction manual, this document is to be referenced.
- Page 2 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS COMPONENT PACKING LIST FRAME PACK COMPONENT PART COMPONENT PART CHK QTY DESCRIPTION DESCRIPTION FRONT VERTICAL C0660 C1555 WALL DOOR BRACE RIGHT FRONT HORIZONTAL C1390 K0640 WALL DOOR BRACE LEFT BACK C3650 S1785...
-
Page 3: Fittings And Accessories
GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS COMPONENT PACKING LIST FITTINGS AND ACCESSORIES COMPONENT PART COMPONENT PART CHK QTY DESCRIPTION DESCRIPTION 8G x 3/8” SELF INSTRUCTION TAPPING SCREW FAST001 MANUAL (220 PACK) 3/16” x 1/2” HINGE FAST002 PAN HD... - Page 4 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS GENERAL INSTRUCTIONS • Before commencing any assembly, read through these instructions in detail to gain a thorough understanding of assembly methods and associated details. • Unpack the carton and carefully identify and check off all the parts against the parts described and illustrated on "COMPONENTS PACKING LIST"...
- Page 5 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS COMPLETED CYCLONE KIT EXAMPLES Structure photographed is 30302GK with CYCGK installed. Exterior views: Front view of 30302GK with frame kit Front view of same shed with frame kit installed and doors open.
- Page 6 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS FRAMING OVERVIEW • Horizontal wall members are boxed. • If shed is on a rebated slab S1785 will need to be cut-to-suit rebate height. Frame layout for models. 37152GK 37232GK 37302GECOK - pictured...
- Page 7 FOR PREMIER MODELS INSTALL EXTRA FASTENERS Absco sheds sheets have punched holes typically spaced at 592mm from centre to centre. To achieve a cyclonic wind rating additional screws will need to be installed to reduce these distances. The fastener intended at these positions is FAST001, a 10mm self tapping screw.
- Page 8 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS INSTALL EXTRA FASTENERS - INTERIOR VIEW “C” - Roof panel to ridge beam. Pre-drill from inside the shed upward through the ridge beam and into the roof panel at 148mm centres, (every pan) then fix with a screw. Some screws will already be in these positions, skip these.
- Page 9 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS USING SELF DRILLING TEK SCREWS Self drilling tek screws are an effective means of securing components without the need to pre-drill holes. By following these instructions you will be able to easily secure your frame kit components.
- Page 10 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS BOXING FRAME SECTIONS 1. All frame sections have one side length of 2. Slide the 38mm side into the 40mm side 38mm and another at 40mm. as shown. 3. Slide opposing sides together so that 4.
- Page 11 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS DOOR BRACING NOTE: If the door has been completely assembled as per original instruction manual you will need to remove the diagonal door braces. 1. Seal any brace holes using the supplied pop rivets, FAST007.
- Page 12 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS DOOR BRACING 5. Place the door frame against the door, ensure 6. Use tek screws to fi x the frame to the door that it is centred. If the door is already fi tted to the at every corner.
- Page 13 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS BRACING FOR FRONT WALL See model specific notes on the FRAME LAYOUT page. At the front of the shed place a horizontal boxed section at 870mm height and tek C1390 screw in position as shown on the right.
- Page 14 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS BRACING FOR REAR WALL 3.0m wide sheds Cut C3650 to 2900 mm 2.3m wide sheds Cut C3650 to 2160 mm 1. Take the two C3650 pieces of framing for the back wall and partially box them together, do not tek screw yet.
- Page 15 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS BRACING FOR SIDE WALLS NOTE: For 2.3m and 1.5m deep models C2750 is to be cut to suit. Construction for the back wall is similar to the side wall. 1. Take two C2750 frame pieces for the gable wall, and partially box them together, do not tek screw yet.
- Page 16 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS BRACING FOR WALLS - DOOR STUDS Door studs are a single frame member with a cutout that allows the wall bracing to slide inside it. S1785 has a rebate so it fits...
- Page 17 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS 3.0m wide sheds 2.3m wide sheds ROOF BRACING Cut C3690 to 2955 mm Cut C3690 to 2215 mm 1. Align the roof framing along the midpoint of 2. Using a marker trace along one edge of the the roof, running perpendicular to the roof sheet channel onto the roof sheet as shown.
-
Page 18: Anchoring Methods
GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS ANCHORING METHODS Bolt and Nut* Fixing M10 dynabolt requires drilling into the M10 4.6/S concrete slab using a masonry bit. Holes must have a minimum slab edge distance of 60mm. Wall Sheet... - Page 19 GABLE SHED N3/C1 FRAME KIT FOR PREMIER MODELS ANCHORING LAYOUT • Slab dimensions below illustrate the minimum required anchors per wall. • Ensure that anchors are evenly spaced along wall. 2360mm for 2.3m wall 3100mm for 3.0m wall 3840mm for 3.7m wall...
- Page 20 Absco Sheds Storage Guidelines • Absco Sheds are designed to be weatherproof for normal weather conditions. In the event of extreme weather conditions such as heavy rain, combined with high wind gusts, the ridge capping, sheeting joins, screw fi xings etc., may exhibit minor deformations which may allow some water entry. These areas should be checked regularly to ensure that maximum strength and protection is maintained.
- Page 21 Lifetime Warranty Statement This warranty against defects is given by: Absco Industries (ABN: 77 869 708 678) Address: PO Box 119 Acacia Ridge QLD 4110 Ph: 1800 029 701 Fax: 07 3344 1191 Email: admin@absco.com.au Date of issue: 19 December 2018 Details of Manufacturer’s Warranty This product comes with a Lifetime structural warranty from the date of purchase.
- Page 22 IMPORTANT 1. Manufacturer’s Disclosure This warranty against defects shall not apply in the following situations: A) Where the product is not assembled in accordance with the instructions provided in the product kit; B) Where the product is used to store corrosive materials such as fertilizer, chlorine etc; C) The warranty does NOT cover damage caused by storms, wind, rain, snow or poor foundations;...
