ABSCO SHEDS 3060HG Assembly Instruction Manual

Highlander shed
Hide thumbs

Advertisement

Quick Links

Download this manual
FOR CONSTRUCTION IN
NON-CYCLONIC AREAS
WIND RATING: W33N (N2)
We thank you for choosing an Australian made shed. For further assistance please
visit our detailed instructional video library at
Http://www.abscosheds.com.au/watch-videos
At ABSCO Industries we are always looking to be number ONE, so please let us
know what you think of our instructions. Feedback makes us better.
feedback@absco.com.au
ABSCO INDUSTRIES
Absco Highlander Shed
Model: 3060HG
CAN BE LAID ON A FLAT SLAB BUT
FOR BEST WATERPROOFING
RESULTS SLAB RESULTS SEE BELOW
WHEN LAYING YOUR CONCRETE
SLAB, ENSURE THERE IS A REBATED
EDGE 25mm DEEP AROUND THE PERIMETER
CHANNEL
NOTE: THIS SHED HAS PORTAL FRAMES FOR STRENGTH.
THESE FRAMES WILL NEED TO BE TRIMMED 25mm TO FIT REBATE
ASSEMBLY INSTRUCTION - MODEL: 3060HGK 01/07/16
THIS WILL HELP
REBATED EDGE
WATER EGRESS FROM
THE BASE OF THE SHED
CONCRETE SLAB
FRONT: 5.96m
SIDE:
HEIGHT: 2.3m
75mm WIDE
REBATE
3.00m
Page 1
