Chauvet Vue I Supplementary Manual

DMX Mode

This mode allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with
DMX, please read the DMX Primer on page 15.
1) Set dipswitches 1-9 to the desired DMX address. For help setting the address, see the
"SETTING THE STARTING ADDRESS" section on the next page.

DMX Channel Values

C
HANNEL
1
2
3
4
5
6
Vue™ I User Manual
V F
ALUE UNCTION

Control/Operating Mode

000 024

Dimmer mode

025 049 Stand-alone mode 1 (automatic)
050 074 Stand-alone mode 2 (automatic)
075 099 Stand-alone mode 3 (automatic)
100 124 Stand-alone mode 4 (automatic)
125 149 Stand-alone mode 5 (automatic)
150 174 Stand-alone mode 6 (automatic)
175 199 Stand-alone mode 7 (automatic)
200 224 Stand-alone mode 8 (automatic)
225 249 Stand-alone mode 9 (automatic)
250 255 Stand-alone (sound active)
Red (Dimmer Mode)
000 255 Dimmer: 0 – 100%
Green (Dimmer Mode)
000 255 Dimmer: 0 – 100%
Blue (Dimmer Mode)
000 255 Dimmer: 0 – 100%
Stand-alone Speed (Mode 1-9)
(Slow > Fast)
000 255
Strobing Speed (Dimmer Mode)
(Slow > Fast)
Dimmer
000 255
Open > Closed (100 – 0%)
