Summary of Contents for FAAC 844 ER 3PH
- Page 1 844 ER 3PH Translation of the original instructions...
- Page 2 Nessuna parte di questo manuale può essere riprodotta, archiviata, distribuita a terzi né altrimenti copiata, in qualsiasi formato e con qualsiasi mezzo, sia esso elettronico, meccanico o tramite fotocopia, senza il preventivo consenso scritto di FAAC S.p.A. Tutti i nomi e i marchi citati sono di proprietà dei rispettivi fabbricanti.
-
Page 3: Eu Declaration Of Conformity
DECLARATION OF INCORPORATION FOR PARTLY COMPLETED MACHINERY (2006/42/EC ANNEX II P.1, B) The Manufacturer Company name: FAAC S.p.A. Soc. Unipersonale Manufacturer and person authorised to prepare the relevant technical documentation Company name: FAAC S.p.A. Soc. Unipersonale Address: Via Calari, 10 - 40069 Zola Predosa BOLOGNA - ITALY... -
Page 4: Table Of Contents
3. 844 ER 3PH ........ -
Page 5: Introduction To This Instruction Manual
When drafting the manual, the results of the risk assessment con- WARNING ELECTRIC SHOCK HAZARD - The operation or step described must ducted by FAAC S.p.A. on the entire product life cycle have been taken be carried out following the instructions provided and according to the safety into account in order to implement effective risk reduction measures. -
Page 6: Safety Recommendations
Protect from mechanical stress. If stored for more than 3 months, regularly check the condition of the components and the packaging. - Storage temperature: 5°C to 30°C. - Percentage of humidity: 30% to 70%. 844 ER 3PH 532366 - Rev.A... -
Page 7: Unpacking And Handling
VENT CLOSURE The 844 ER 3PH is supplied with the vent hole closed with a screw and washer (2). Whenever the gearmotor is handled, the vent must be closed to prevent oil leaking out. -
Page 8: Er 3Ph
- It is forbidden to use 844 ER 3PH in a constructional configuration Only one gearmotor must be installed for each leaf. The system other than the one provided by the manufacturer. -
Page 9: Technical Data
Cod..MMYY PROG •••••• Electromechanical oil-bath gearmotor, supplied without pinion. To choose the correct FAAC Module 4 pinion to install (Z12, Z16, Z20) see Technical data. Irreversible system In order to be operated manually, the gearmotor has to be released using the key provided. -
Page 10: Component Identification
14 Pair of plates for the inductive opening and closing limit switches COMPONENTS SUPPLIED SEPARATELY The installation requires the following FAAC components that are supplied separately: Steel rack with spacers (to be screwed or welded on) -
Page 11: Dimensions
Make sure that the gate is at its opening or closing end of travel position (the relative limit switch must be engaged) before turning the power back on and operating the automation. 7 844 ER 3PH 532366 - Rev.A... -
Page 12: Installation Requirements
EN 349. For the safety distances required to prevent danger zones being reached, refer to ISO 13857. If the area of installation gives rise to the risk of impact by vehicles, provide an appropriate protective structure to protect the gearmotor. 844 ER 3PH 532366 - Rev.A... -
Page 13: Example System
4.3 EXAMPLE SYSTEM The example is an illustration only and is just one of the possible ap- plications of the 844 ER 3PH. Mains power supply 4G 1.5 mm Circuit breaker Junction box Gearmotor power supply Gearmotor 844 ER 3PH... -
Page 14: Installation Dimensions
4.4 INSTALLATION DIMENSIONS ■ FOUNDATION PLATE Opening to the right Opening to the left 90° 90° 0 … 50 0 … 50 ■ STEEL RACK 9 844 ER 3PH 532366 - Rev.A... -
Page 15: Mechanical Installation
5.1 REPLACING THE SPRING (FOR LEAVES WEIGHING MORE THAN 1000 KG) If the 844 ER 3PH is installed on a leaf that weighs more than 1000 kg, the clutch adjustment spring has to be replaced with the other spring supplied with the hardware/accessories (with a greater wire diameter and more resistant to compression). -
Page 16: Installing The Foundation Plate
PERSONAL PROTECTIVE EQUIPMENT Carry out the work with the power supply disconnected. - The 844 ER 3PH must be installed with the foundation plate. - The installer is responsible for the evaluation of the foundation materials and dimensions on the basis of the characteristics of the ground and place of installation. -
Page 17: Installing The Gearmotor
Keep the screw and washer as they will have to be reinstalled if the gearmotor has to be removed and subsequently transported. 15 keep the screw and washer 17 16 844 ER 3PH 532366 - Rev.A... -
Page 18: Installing The Rack
6. Make sure that it is horizontal using a spirit level. Weld the spacers (as in step 4). Remove the screw clamps. 7. Repeat from step 5 for all elements of the rack. 20 844 ER 3PH 532366 - Rev.A... -
Page 19: Steel Rack - Screw-On Fastenings
9. Repeat from step 7 for all elements of the rack that are required for the length of the leaf. 21 - If an element of the rack needs to be shortened, cut it with an angle grinder away from the slot. 22 24 23 844 ER 3PH 532366 - Rev.A... -
Page 20: Adjusting And Checking
25 5.7 FASTENING THE GEARMOTOR PERMANENTLY 1. Tighten the upper nuts to the fastening torques indicated in the figure. 2. Press the guards onto the brackets. Fastening permanently. Press the guards. 80 Nm 26 844 ER 3PH 532366 - Rev.A... -
Page 21: Optional Equipment
2. Install the new lock and fasten it using the nut. Insert the locking lever vertically and fasten it using the screw. 3. Make sure that the release lever works, using the new keys. Install the new lock. 27 844 ER 3PH 532366 - Rev.A... -
Page 22: Start-Up
3. Tighten the two elements and fasten them using the screws 3 and the nuts 4. 4. Fasten to the surface using the screws 5. Slot Screw seat 28 844 ER 3PH 532366 - Rev.A... -
Page 23: Installing The End Of Travel Plates
2. Make sure that the flat limit switch cable is connected according to the opening direction of the gate. The opening direction is established by looking at the 844 ER 3PH from the release device side (31). If necessary, move the connection onto the correct connector. -
Page 24: Starting The Automation
The static force is limited by adjusting the mechanical clutch. The clutch must be adjusted with the power supply disconnected. The 844 ER 3PH is supplied with the clutch adjusted for maximum thrust force. 1. Turn off the power supply and remove the protective cover from 32... -
Page 25: Installing The Casing
4. Fill out the EC declaration of conformity and the system register. 5. Give the EC Declaration, the system register with the maintenance plan and the instructions for use of the automation to the system owner/operator. 844 ER 3PH 532366 - Rev.A... -
Page 26: Maintenance
Do not modify the original components in any way. Control devices FAAC S.p.A. disclaims any liability for damage caused by components that are Check that the installed devices and radio controls are in good condition and modified or tampered with. -
Page 27: Instructions For Use
34 10.1 SAFETY RECOMMENDATIONS Systems that use FAAC 844 ER 3PH series gearmotors are designed to control sliding gates in areas that are accessible to people and vehicles in industrial, commercial or residential buildings. -
Page 28: Emergency Use
Make sure that the gate is at its opening or closing end of travel position (the relative limit switch must be engaged) before turning the power back on and operating the automation. 844 ER 3PH 532366 - Rev.A... - Page 32 FAAC S.p.A. Soc. Unipersonale Via Calari, 10 - 40069 Zola Predosa BOLOGNA - ITALY Tel. +39 051 61724 - Fax +39 051 09 57 820 www.faac.it - www.faacgroup.com 844 ER 3PH 532366 - Rev.A...
