Thermo Fisher Scientific General Purpose-Counter Top Series
Laboratory Freezers
User Manual
General Purpose Models: MF02PA-SAEE-TS
327905H01
Rev. B
October 2016
Visit us online to register your warranty
www.thermofisher.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MF02PA-SAEE-TS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Thermo Scientific MF02PA-SAEE-TS

  • Page 1 Thermo Fisher Scientific General Purpose-Counter Top Series Laboratory Freezers User Manual General Purpose Models: MF02PA-SAEE-TS 327905H01 Rev. B October 2016 Visit us online to register your warranty www.thermofisher.com...
  • Page 2 IMPORTANT Read this instruction manual. Failure to follow the instructions in this manual can result in damage to the unit, injury to operating personnel, and poor equipment performance. CAUTION All internal adjustments and maintenance must be performed by qualified service personnel. Material in this manual is for informational purposes only.
  • Page 3: Table Of Contents

    Table of Contents Table of Contents Intended Use and Special Warnings ........2 Positioning & Safely Using your GP Series Freezer .....3 Transporting & Moving your GP Series Freezer ....4 Energy Saving Tips ..............4 Important Information............5 Product Information..............6 Environmental Operating Conditions ........6 Product Details .................7 Controller Overview &...
  • Page 4 This symbol used alone indicates important operating instructions which reduce risk of injury or poor performance of the unit. Please read the manual completely before use. In this manual, the words WARNING and CAUTION mean the following: WARNING: A situation which, if not avoided, could result in serious injury or death.
  • Page 5: Intended Use And Special Warnings

    Intended Use and Special Warnings 1 Intended Use and This equipment is tested in compliance with established regulations and Special Warnings then shipped ready for use. This equipment is intended for general purpose cold storage and is not to be used in the presence of explosive gases or mixtures and / or close to sources with high magnetic or electric fields.
  • Page 6: Positioning & Safely Using Your Gp Series Freezer

    • DO NOT modify system components, especially the controller. Use Thermo Scientific exact replacement equipment or parts. Before use, confirm that the product has not been altered in any way. •...
  • Page 7: Transporting & Moving Your Gp Series Freezer

    Transporting & Moving your GP Series Freezer 3 Transporting & The freezer must always be moved in the vertical position. The cabinet must Moving your GP not be tilted anymore than 10°. In the event that the cabinet is tilted more than 10°, the power supply must not be connected until the equipment has Series Freezer stood upright for at least 24 hours.
  • Page 8: Important Information

    Important Information 5 Important The freezer contains environment-friendly, non ozone depleting refrigerant Information R600a. As R600a is a flammable gas, it is important to avoid damage to the refrigeration circuit during transport and installation. If the refrigeration circuit is damaged, avoid using a naked flame in the vicinity of the equipment and connecting power to the equipment.
  • Page 9: Product Information

    Product Information 6 Product This freezer has been designed and built with the intention of the product Information being used within a laboratory and is designed to store contents between -18°C to -30°C (-0.4°F to -22°F). See below for specific product information: Model Height Width...
  • Page 10: Product Details

    Product Details 7 Product Details 1. Lock 2. Electronic Controller 3. Door Handle 4. Wire Shelf 5. Plastic Tray 6. Adjustable foot (2 at front of equipment) Contact your local representative for information on spare parts. Thermo Fisher Scientific General Purpose Countertop Series User Manual...
  • Page 11: Controller Overview & Operation

    Controller Overview & Operation 8 Controller Overview & Operation 1. Menu 2. Lock keypad 3. Maximum temperature / Up 4. Power 5. Mute 6. Minimum temperature / Down 7. Set / Enter 8.1 Anticipated Operational/Field Environment Environment Units Nominal Minimum Maximum Minimum Starting Temperature °C...
  • Page 12: Default Settings

    Controller Overview & Operation 8.2 Default Settings Parameter Description Default Setting Low Temperature Alarm Threshold -30°C (-22°F) High Temperature Alarm Threshold -11°C (12.2°F) Temperature Setting °C/°F 0 for °C Temperature Set Point -20°C ( -4°F) Maximum Set Point -19°C (-2.2°F) Minimum Set Point -21°C (-5.8°F) Control Delta...
  • Page 13: Changing Factory Set Point

    Controller Overview & Operation 8.4 Changing Factory (The set point is the point at which the normally unit holds the temperature at; in rare circumstances such as high/low room temperatures it may be Set Point necessary to adjust this slightly. Changing the factory setting is not recommended.) Function Press...
  • Page 14: Changing Remote Alarm Contacts

    Controller Overview & Operation 8.6 Changing Remote Alarm Contacts Function Press Hold button(s) Example down for screen To change the alarm contact 3 seconds state followed by Three times followed by 1 second followed by Once followed by 1 second followed by 5 seconds Note: NO = Normally Open, NC = Normally Closed.
  • Page 15: Warning Alarms

    Warning Alarms 9 Warning Alarms This freezer has been designed to provide both an audible and visual alarm should any of the following situations occur: • Internal temperature goes outside the set parameters, either too high or too low. If these alarms occur, this can be muted by pressing on the controller.
  • Page 16: Remote Alarm Contacts

    Remote Alarm Contacts 10 Remote Alarm All GP series laboratory freezers include remote alarm contacts and these Contacts terminal contacts enable the user to connect to a remote control station; these contacts can be found on the rear of the cabinet. CAUTION: These contacts must only be accessed by a competent electrician.
  • Page 17: Access Port

    Access Port 11 Access Port All GP freezers are provided with Access port that is located at the rear of the unit. IMPORTANT NOTE These units are intended for General Purpose Cold storage. In case critical samples are stored, we recommend the use of a independent temperature monitoring system which continuously monitors freezer performance.
  • Page 18: Maintenance & Service Of Your Gp Series Freezer

    Maintenance & Service Of Your GP Series Freezer 12 Maintenance & Service Of Your GP Series Freezer 12.1 Defrosting CAUTION: When defrosting your freezer, never use sharp or heavy tools such as chisels or scrapers. Damage to the equipment can result. Let the ice melt enough so that it can be easily removed.
  • Page 19: Cleaning

    Maintenance & Service Of Your GP Series Freezer 12.2 Cleaning • Your freezer should be cleaned regularly. • Before cleaning you MUST switch off and disconnect your freezer from the power supply. • The whole freezer except the door gasket can be cleaned with mild cleaning detergent.
  • Page 20: Electrical Connection

    Electrical Connection 13 Electrical The equipment is intended for connection to alternating current. The Connection connection values for voltage (V) and frequency (Hz) are declared on the name plate in the cabinet. Power must be connected via a wall socket with a switch.
  • Page 21: Troubleshooting

    Troubleshooting 14 Troubleshooting Problem Reason Solution Make sure the plug is properly inserted into the socket. A gap in the electric system Make sure the socket is not faulty. circuit. The equipment does not work. Make sure the power supply cord is not damaged.
  • Page 22 Two Years Limited Warranty This Thermo Scientific product is warranted to be free of defects in materials and workmanship for two (2) years from the first to occur of (i) the date the product is sold by the manufacturer or (ii) the date the product is purchased by the original retail customer (the “Commencement Date”).
  • Page 23 Further information on our compliance with these Directives, the recyclers in your country, and information on Thermo Scientific products which may assist the detection of substances subject to the RoHS Directive are available at www.thermo.com/...
  • Page 24 (manufacturer or specific agent/rep organization), and purchase order number. IF YOU NEED ASSISTANCE: Thermo Scientific products are backed by a global technical support team ready to support your applications. We also offer cold storage accessories, including remote alarms, temperature recorders and validation services. Visit www.thermoscientific.com or call:...
  • Page 25 Thermo Fisher Scientific Inc. 275 Aiken Road Asheville, NC 28804 United States www.thermofisher.com 327905H01 Rev. B...
