- Page 1 Thermo Scientific Medifuge Small Benchtop Centrifuge Instructions for Use 50148677_f • 08 / 2017 Visit us online to register your warranty: thermofisher.com/labwarranty...
-
Page 2: Table Of Contents
Thermo Scientific Medifuge Centrifuge � � � � � � � � � � � � � � � � � � � � � � � 12 Thermo Scientific DualSpin Rotor � � � � � � � � � � � � � � � � � � � � � � � � � � � 13 2. - Page 3 Thermo Scientific Medifuge Centrifuge 6. Storage ........19 7.
- Page 4 Thermo Scientific Medifuge Centrifuge 2. Basics ......... 47 3.
-
Page 5: Preface
Thermo Scientific Medifuge Centrifuge Preface Before using the centrifuge, read through this instruction manual carefully and follow the instructions� Not following the instructions and safety information in this instruction manual will result in the expiration of the sellers warranty� Intended Use This centrifuge is intended to be used as a laboratory equipment to separate sample mixtures of different densities�... -
Page 6: Items Supplied
Size and relation of graphics are not showing real dimensions and are just for visual identification� If any parts are missing, please contact the nearest Thermo Fisher Scientific representative� Article No. Item Graphic Quantity Centrifuge Thermo Scientific Medifuge small benchtop centrifuge Power supply cable Rotor 75008810 Thermo Scientific DualSpin rotor (factory ™... -
Page 7: Precautions
Thermo Scientific Medifuge Centrifuge Precautions Signal Words and Colors WA RNIN G Indicates a hazardous situation that, if not avoided, could result in death or serious injury. CAUT ION Inidicates a hazardous situation that, if not avoided, could result in minor or moderate injury (e.g. -
Page 8: Preparation
Thermo Scientific Medifuge Centrifuge Preparation Use only with a rotor that has been properly installed� Follow the instructions in section ƒ “Rotor Installation” on page 29� Do not use a rotor or accessories that show any signs of corrosion or cracks�... -
Page 9: Operation
Thermo Scientific Medifuge Centrifuge If toxins or pathogenic substances have contaminated the centrifuge or its parts, appropriate ƒ disinfection measures have to be taken (“Disinfection” on page 49)� ƒ Extreme care should be taken with highly corrosive substances which can cause damage and impair the mechanical stability of the rotor�... -
Page 10: Service Lifetime
Thermo Scientific Medifuge Centrifuge Service Lifetime The centrifuge is designed for 10 years or 140 000 cycles of service, whichever is first� Usage beyond these limits might affect the safety of the centrifuge housing or the lid latch system� The rotor is designed for 5 years or 60 000 cycles of service, whichever is first� Usage beyond these... -
Page 11: Symbols Used On The Centrifuge
Thermo Scientific Medifuge Centrifuge Symbols used on the Centrifuge This symbol refers to general hazards� This symbol refers to biological hazards� Observe the information contained in the instruction manual to keep yourself and your environment safe� This symbol refers to physical hazards from hot surfaces�... -
Page 12: Technical Specifications
Thermo Scientific Medifuge Centrifuge I. Technical Specifications 1. Technical Data Thermo Scientific Medifuge Centrifuge Environmental Conditions For interior use Altitudes of up to 3 000 m above sea level Max� relative humidity 80% up to 31 °C; decreasing linearly to 50% relative humidity at 40 °C Environmental Conditions during Temperature: -10 °C to +55 °C... -
Page 13: Thermo Scientific Dualspin Rotor
Thermo Scientific Medifuge Centrifuge Thermo Scientific DualSpin Rotor Maximum Permissible Load 8 x 30 g Maximum Allowed Imbalance 10 g Maximum Speed n 4 900 rpm Maximum RCF-Value at n Fixed Angle Setup 3 114 x g Swing Out Setup 3 490 x g Max�... -
Page 14: Rotor And Accessories
Thermo Scientific Medifuge Centrifuge 2. Rotor and Accessories Article No. Description Graphic 75008810 Thermo Scientific DualSpin rotor (1x) with fixed angle buckets (8x) and swinging buckets (8x) 75008813 Thermo Scientific DualSpin rotor body (1x) 75008815 Fixed angle buckets (8x) 75008816... -
Page 15: Directives, Standards And Guidelines
Thermo Scientific Medifuge Centrifuge 3. Directives, Standards and Guidelines Region Directive Standard Europe 98/79/EC in vitro diagnostic EN 61010-1, 3 Edition medical devices (IVD) 220–230 V, IEC 61010-2-020, 3 Edition 50/60 Hz 2014/35/EC Low Voltage IEC 61010-2-101, 3 Edition (protective goals) -
Page 16: Mains Supply
4. Mains Supply The following table contains an overview of the electrical connection data� This data is to be taken into consideration, when selecting the mains connection socket� Unit Thermo Scientific Medifuge small benchtop centrifuge Article No. 75008802 75008801 75008800... -
Page 17: Transport And Set Up
Thermo Scientific Medifuge Centrifuge II. Transport and Set Up 1. Before Setting Up 1� Check the centrifuge and the packaging for any shipping damage� Inform the shipping company and Thermo Fisher Scientific immediately if any damage is discovered� 2� Remove the packaging�... -
Page 18: Transporting
Thermo Scientific Medifuge Centrifuge 3. Transporting WA RNIN G The centrifuge can be damaged by impact. Do not operate the centrifuge if an impact occured. CAUT ION Do not use a damaged rotor. Replace the rotor, if it was dropped. -
Page 19: Mains Connection
Thermo Scientific Medifuge Centrifuge 5. Mains Connection CAUT ION Plug the centrifuge into grounded electrical sockets only. 1� Turn off the power supply switch located on the back side� 2� Check whether the cable complies with the safety standards of your country�... -
Page 20: Shipping
Thermo Scientific Medifuge Centrifuge 7. Shipping WARNING Before shipping the centrifuge and accessories you have to clean and additionaly disinfect or decontaminate the entire system if biological or chemical substances were used. In doubt contact the Thermo Fisher Scientific customer service. -
Page 21: Control Panel
Thermo Scientific Medifuge Centrifuge III. Control Panel Function Display Controls Speed / RCF Value The speed (rpm) or RCF value (x g) is displayed here� The RCF value (x g) can be set for the fixed angle buckets (45°) or the swing out buckets (90°)�... -
Page 22: Control Panel Settings
Thermo Scientific Medifuge Centrifuge Control Panel Settings The centrifuge always shows the actual operating values� Only when changing speed and time the centrifuge will show the set parameters� The centrifuge will show “0” for speed and time, if switched on and it is not operating� An animation will be shown, when the centrifuge is spinning�... - Page 23 Thermo Scientific Medifuge Centrifuge 2� Press the SPEED arrow keys� This changes the set centrifugation speed� RPM will change in steps of 100 rpm� RCF will change in steps of 100 x g� Keeping a SPEED arrow key pressed will change the speed until the limiting values are reached�...
-
Page 24: Select Runtime
Thermo Scientific Medifuge Centrifuge Select Runtime Press the TIME arrow keys� This changes the set centrifugation time� First runtime will change in steps of single minutes� Holding the key pressed will change the runtime by steps of single minutes� This will continue until the limit of 99 minutes is reached� Keeping the arrow keys pressed at the limits will switch to “hd”�... -
Page 25: Acceleration / Deceleration Profiles
Thermo Scientific Medifuge Centrifuge Acceleration / Deceleration Profiles The centrifuge offers you 1 profile for acceleration (standard) and 3 profiles for deceleration (standard, soft and brake-off)� The acceleration profile cannot be changed� The setting is displayed with the LEDs above the Curve Key�... -
Page 26: Programs
Thermo Scientific Medifuge Centrifuge Programs The centrifuge is able to save up to 4 programs� It is only possible to save a program if the centrifuge is switched on� Loading or saving of programs is not possible if the centrifuge is spinning�... -
Page 27: Acoustic Signals
Thermo Scientific Medifuge Centrifuge Acoustic Signals The centrifuge gives acoustic signals by default� The acoustic signals can be activated or deactivated all together� 1� Keep the TOGGLE key pressed when you turn on the centrifuge� 2� Press the TIME arrow keys to switch on or off the acoustic signals�... -
Page 28: Operation
Thermo Scientific Medifuge Centrifuge IV. Operation 1. Switching on the Centrifuge Turn on the power switch on the back side of the centrifuge� The centrifuge door opens automatically, if the centrifuge was closed when when switched on� 2. Open the Centrifuge Door CAUT ION Open the centrifuge only when the rotor stopped spinning. -
Page 29: Rotor Installation
Thermo Scientific Medifuge Centrifuge 3. Rotor Installation CAUT ION The rotor must turn freely and the rotor locking nut must be tight. Check the locking nut regularly to ensure that it is properly tight. If the rotor is not installed correctly, the rotor can crash. - Page 30 Thermo Scientific Medifuge Centrifuge Turn the rotor locking nut clockwise� Tighten the rotor locking nut with your hand� Make sure that the rotor locking nut is tight by turning it one more complete turn when the rotor locking nut starts to be tight�...
-
Page 31: Installation Of Swing Out Buckets
Thermo Scientific Medifuge Centrifuge Installation of Fixed Angle Buckets Put the fixed angle buckets into the rotor body� If necessary to get smaller tubes in position, use the spacers (75008818 and 75008817) according to the tubes used� Installation of Swing Out Buckets Put the swing out buckets into the rotor body�... -
Page 32: Rotor Temperature Range
Thermo Scientific Medifuge Centrifuge If necessary to get smaller tubes in position, use the spacers (75008818 and 75008817) according to the tubes used� 4. Rotor Temperature Range CAUT ION Operate the rotor in a temperature range between -9 °C and 40 °C only. - Page 33 Thermo Scientific Medifuge Centrifuge Fixed Angle Buckets Correct ✓ Incorrect ✕ Swing Out Buckets Correct ✓ Incorrect ✕...
-
Page 34: Maximum Loading
Thermo Scientific Medifuge Centrifuge Mixed Bucket Set Up Correct ✓ Incorrect ✕ Maximum Loading The rotor can run at high speeds� Each rotor is specifically designed to run at its maximum speed with a defined load� The safety system of the centrifuge requires that you do not overload the rotor�... -
Page 35: Tube And Spacer Guide
Thermo Scientific Medifuge Centrifuge Tube and Spacer Guide CAUT ION Always make sure that the buckets are aligned and the tubes cannot touch each other or the rotor locking nut during centrifugation. This guide provides information on which tubes and spacers can be used in the fixed angle and the swing out buckets�... - Page 36 Thermo Scientific Medifuge Centrifuge Fixed Angle Bucket Fixed Angle Bucket Direct Fit (no spacer necessary) Tube Type Volume Diameter Length Sarstedt S-Monovette blood tube 4�5–5�0 ml 11 mm 92 mm ™ ™ Sarstedt S-Monovette blood tube 4�9 ml 13 mm...
- Page 37 Thermo Scientific Medifuge Centrifuge Fixed Angle Bucket Green Spacer Tube Type Volume Diameter Length Sarstedt S-Monovette blood tube 7�5–8�2 ml 15 mm 92 mm Sarstedt S-Monovette blood tube 9�0–10�0 ml 16 mm 92 mm Generic tube 17�5 mm 90– 100 mm...
- Page 38 Thermo Scientific Medifuge Centrifuge Fixed Angle Bucket Yellow Spacer Tube Type Volume Diameter Length Sarstedt S-Monovette blood tube 1�2–1�4 ml 8 mm 66 mm Sarstedt S-Monovette blood tube 2�6–4�3 ml 13 mm 65 mm Sarstedt S-Monovette blood tube 2�7–3�0 ml...
-
Page 39: Swing Out Bucket
Thermo Scientific Medifuge Centrifuge Swing Out Bucket Swing Out Bucket Direct Fit (no spacer necessary) Tube Type Volume Diameter Length Sarstedt S-Monovette blood tube 4�5–5�0 ml 11 mm 92 mm Sarstedt S-Monovette blood tube 4�9 ml 13 mm 90 mm Sarstedt S-Monovette blood tube 7�5–8�2 ml... - Page 40 Thermo Scientific Medifuge Centrifuge Swing Out Bucket Green Spacer Tube Type Volume Diameter Length Sarstedt S-Monovette blood tube 1�2–1�4 ml 8 mm 66 mm Sarstedt S-Monovette blood tube 2�6–4�3 ml 13 mm 65 mm Sarstedt S-Monovette blood tube 2�7–3�0 ml...
-
Page 41: Checking The Rotor Lifetime
Thermo Scientific Medifuge Centrifuge Checking the Rotor Lifetime NOTICE The cycle counter is counting the centrifuge runs. The cycle counter can not detect changed or replaced rotors and buckets. The lifetime of rotor and buckets depends on the amount of pyhsical load� Do not exceed the number of cycles recommended for rotor and buckets�... -
Page 42: Close The Centrifuge Door
Thermo Scientific Medifuge Centrifuge 6. Close the Centrifuge Door CAUT ION Do not operate the centrifuge without rubber gasket in the rotor chamber. Spillage can occur if the centrifuge is operated without rubber gasket. A hazardous situation caused by biological or chemical substances can occur. -
Page 43: Centrifugation
Thermo Scientific Medifuge Centrifuge 7. Centrifugation CAUT ION If scraping noises occur, press the STOP key to shut down the centrifuge. Pull out the power supply plug or disconnect the power supply in an emergency. Replace damaged buckets before the next run. -
Page 44: Stopping The Centrifugation
Thermo Scientific Medifuge Centrifuge Stopping the Centrifugation When a centrifugation run is finished and the centrifuge shows “END”, this indicates that the selected parameters were reached� With Set Time If the time is set, the centrifuge will run at the selected speed until the set time is reached� It will then automatically decelerate, stop and beep�... -
Page 45: Removing The Rotor
Thermo Scientific Medifuge Centrifuge 8. Removing the Rotor Turn the rotor locking nut counterclockwise (the opposite direction as marked on the rotor locking nut)� Remove the rotor from the motor shaft� 9. Switch off the Centrifuge To switch off the centrifuge push the mains switch to “0”�... -
Page 46: Maintenance And Care
Thermo Scientific Medifuge Centrifuge V. Maintenance and Care Do not use a rotor or accessories with signs of damage. CAUT ION Make sure that rotor, buckets and accessories are within their service lifetime (age and cycles). It is recommended to check rotors and accessories within a yearly routine inspection to ensure safety. -
Page 47: Basics
Thermo Scientific Medifuge Centrifuge 2. Basics CAUT ION Not rated procedures or agents could deteriorate the materials of the centrifuge and lead to malfunction. Refrain from using any other cleaning or decontamination procedure than those recommended here, if you are not entirely sure that the intended procedure is safe for the equipment. -
Page 48: Cleaning
Thermo Scientific Medifuge Centrifuge 3. Cleaning CAUT ION Do not autoclave the rotor or accessories. Do not clean the rotor or accessories in a dishwasher. Temperatures above 40 °C can damage the material. Before using any cleaning methods except those recommended... -
Page 49: Disinfection
Thermo Scientific Medifuge Centrifuge 4. Disinfection WA RNIN G Hazardous infection is possible when touching the contaminated rotor and centrifuge parts. Infectious material can get into the centrifuge when a tube breaks or as a result of spills. In case of contamination, make sure that others are not put at risk. -
Page 50: Decontamination
Thermo Scientific Medifuge Centrifuge 5. Decontamination WA RNIN G Radiation is possible when touching the contaminated rotor and centrifuge parts. Radioactive material can get into the centrifuge when a tube breaks or as a result of spills. In case of contamination, make sure that others are not put at risk. -
Page 51: Service Of Thermo Fisher Scientific
Thermo Scientific Medifuge Centrifuge 6. Service of Thermo Fisher Scientific Thermo Fisher Scientific recommends having the centrifuge and accessories serviced once a year by an authorized service technician� The service technician checks the following ƒ electrical equipment ƒ suitability of set-up site ƒ... -
Page 52: Troubleshooting
Thermo Scientific Medifuge Centrifuge VI. Troubleshooting 1. Mechanical Emergency Door Release CAUT ION A spinning rotor can cause serious injuries when touched. In case of power outage the rotor can still be spinning. Wait 5 minutes to be sure that the rotor can stop spinning. -
Page 53: Troubleshooting By Guide
Thermo Scientific Medifuge Centrifuge 2. Troubleshooting by Guide NOT ICE If problems occur not stated here, customer service must be contacted� For error numbers shown that are not described in detail in the table, follow this procedure: 1� Restart the centrifuge�... -
Page 54: When To Contact Customer Service
Thermo Scientific Medifuge Centrifuge Error number Description Troubleshooting E-40 Acceleration is too low Make sure that the rotor is correctly loaded and balanced� Make sure that no objects are within the rotor chamber� Make sure that the correct the mains connection is correct�... -
Page 55: Chemical Compatibility Chart
Thermo Scientific Medifuge Centrifuge... - Page 56 Thermo Scientific Medifuge Centrifuge...
- Page 57 Thermo Scientific Medifuge Centrifuge...
- Page 58 Thermo Scientific Medifuge Centrifuge...
- Page 59 Thermo Scientific Medifuge Centrifuge...
- Page 60 Thermo Scientific Medifuge Centrifuge...
- Page 61 Thermo Scientific Medifuge Centrifuge...
- Page 62 Thermo Scientific Medifuge Centrifuge...
- Page 63 Thermo Scientific Medifuge Centrifuge...
- Page 64 Thermo Scientific Medifuge Centrifuge...
- Page 65 Thermo Scientific Medifuge Centrifuge...
- Page 66 Thermo Scientific Medifuge Centrifuge...
- Page 67 Thermo Scientific Medifuge Centrifuge...
-
Page 68: Declaration Of Decontamination
Thermo Scientific Medifuge Centrifuge Declaration of Decontamination NOT ICE Thermo Fisher Scientific representatives will indicate on a customer service repair report if decontamination was required, and if so, what the contaminate was and what procedure was used. If no decontamination was required, it should be stated so. - Page 69 Thermo Scientific Medifuge Centrifuge Decontamination Certificate DECONTAMINATION CERTIFIED BY TITLE/POSITION PHONE DEPARTMENT INSTITUTION ADDRESS CITY STATE INSTRUMENT SERIAL NUMBER ROTOR SERIAL NUMBER PART PART NUMBER HAZARDOUS CONTAMINANTS(S) DECONTAMINATION DATE DECONTAMINATION METHOD(S) DECONTAMINATION CERTIFIER’S SIGNATURE DATE...
-
Page 70: Acceleration/Deceleration Profiles
Thermo Scientific Medifuge Centrifuge Acceleration/Deceleration Profiles The shown diagrams are both based on a fully loaded rotor operated at rated voltage� Your actual operating results may differ to this depending on the operating conditions� Because of that the diagrams are for reference purposes only�... -
Page 71: Index
Thermo Scientific Medifuge Centrifuge Index Leveling Service of Thermo Fisher Location Scientific Set Up Shipping 20, Acceleration / Deceleration Storage Profiles Switching on Mains Connection Switch off Mains Supply Symbols used in the Maintenance and Care Manual Maximum Loading Before Setting Up... - Page 72 50148677 50148677 is the original instruction manual. thermofisher.com/centrifuge © 2017 Thermo Fisher Scientific Inc� All rights reserved� All trademarks are the property of Thermo Fisher Scientific Inc�and its subsidiaries unless otherwise specified� Delrin, TEFLON, and Viton are registered trademarks of DuPont� Noryl is a registered trademark of SABIC� POLYCLEAR is a registered trademark of Hongye CO�, Ltd�...
