Troubleshooting
If the unit is not functional - check main power supply is ʻonʼ and check fuses.
If the unit is functional but lamp does not light - lamp may require replacing.
If the unit lights but will not move - check sound sensitivity knob.
If after trying this solution you still have a problem contact CHAUVET.
Caution
Do not obstruct the air vents.
Do not touch unit or lamps while hot.
No user serviceable parts inside. Please refer to CHAUVET for service.
Power Connections
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other connec-
tions be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.
120V~60Hz AC
Power
3.15A 250V
Fuse
1 x 24v 250W
Lamps
Part No EHJ 24V 250W
343 x 211 x 320mm / 13.5 x 8.3 x 12.6in
Dimensions
14.5kg / 32lbs
Weight
Technical Specifications
User Informtion (Please complete for your records)
Date Purchased:
/
/
Dealer Stamp:
230V~50Hz AC
3.15A 250V
1 x 24v 250W
Part No EHJ 24V 250W
343 x 211 x 320mm / 13.5 x 8.3 x 12.6in
14.5kg / 32lbs
Serial No: ________________
Model: CH-325 Fusion
Fusion
CH-325
User Guide
Please read these instructions carefully before use
World-wide Headquarters:
3000 North 29th Ct., Hollywood, FL
USA 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
www.ChauvetLighting.com
