S&A CW-5000AG Manual

Model (Code): (1931) CW-5000AG / (1933) CW-5000BG / (1924) CW-5000DG
Name:
(1931) CW-5000AG Water Chiller for Single 120W CO2 Laser Tube Cooling AC 1P 220V, 50Hz
(1933) CW-5000BG Water Chiller for Single 120W CO2 Laser Tube Cooling AC 1P 220V, 60Hz
(1924) CW-5000DG Water Chiller for Single 120W CO2 Laser Tube Cooling AC 1P 110V, 60Hz
Overview Specifications Packing list Warranty
It is designed for cooling the one CO2 glass laser tube under 150W of the laser engraving and cutting machine. (Its emitting
rate is higher than 60 %.)
Cooling capacity is 800W, Radiating capacity: 50W / ℃
Have design patent Certificate, CE Certificate
This water chiller has been sold largely to Europe, South America, Asia and other markets.
Economic cooling equipment, easy to install and operate, compact and easily movable

Features

◆ It is suitable for cooling the laser tube under 150W, and the temperature can be adjusted precisely.
◆ You can choose different models according to local voltage and frequency.
◆ It can extend the using life of laser tube and ensure the engraving effect better.
◆ Small thermolysis water cooler, energy saving, long working life and simple operation
◆ With completed water flow and over high temperature alarm functions
◆ It can control the water temperature, precision is ±0.1℃, which provide stable working conditions for laser devices.
◆ Cool Capacity is 50W / ℃.
◆ This series of water chillers adopt intelligent controller, which need not adjust the control parameters under normal
circumstances, it will automatically adjust control parameters according to room temperature changes, to meet the cooling
requirement.
◆CW-5000 water chiller has unique low flow alarm protection function, which ensures the cooling water cycle working
