7 Changing the battery

Changing the battery is allowed only outside hazardous areas.
Please also observe the following safety regulations.
1. If the battery is mounted, switch off the handheld computer and turn the
battery module's screw anti-clockwise with a suitable torx screwdriver.
2. Lift the battery module at the lower side.
3. The SIM and microSD slots are located under a cover in the battery
compartment. To open it unscrew all four screws using a suitable
screwdriver.
4. Insert your SIM card (WWAN version only) and – if needed – a microSD card
(max. 32 GB) into the referring slots.
5. Insert the battery module by first placing the contacts on the top side of the
battery module into the respective contact in the mobile computer's
housing in its battery compartment. Press the battery module down at the
lower side and tighten the screw of the battery clockwise with a suitable torx
screwdriver.
6. Do not overtighten the screw. It needs to be fastened hand-tight.
7. Charge the handheld computer: The battery supplied with the handheld
computer is not fully charged. It is recommended to charge the computer for
eight hours before using it for the first time. The full capacity of the battery is
reached after 3 - 4 complete charge / discharge cycles.

Note:
• There is a risk of explosion if the battery is not exchanged properly or if it is
exposed to a flame.
• Do not short-circuit the battery.
• The battery does not contain any parts that can be exchanged.
• The casing of the battery should not be opened under any circumstances.
• Only use ecom charging accessories (see point 4).
• The use of other chargers or batteries is not permitted. Ex-protection cannot be
guaranteed in this case.
• Used batteries are to be disposed of properly.
• The charge level of the battery module should be checked after six months at
the latest in order to prevent deep discharge.
• If the battery is completely discharged, the handheld computer will not switch
on and the display will not show a charging process. Connect the handheld
computer to the charger. After charging for a few minutes the status LED will
appear and you can switch on the handheld computer.

8 Safety Precautions for the Battery

Damaged batteries and chargers should be removed from use and sent to ecom
instruments GmbH for inspection.

Note:
• Extreme temperatures can have an adverse effect on charging the battery
module.
• Do not dispose of the battery module in a fire.
• Do not short-circuit the battery module.
• Dispose of the battery module in accordance with local regulations.
• Do not dispose of the battery module with normal household waste.
14
High quality lithium-ion batteries are used in your i.roc
numerous advantages in everyday use, such as a low weight and high capacity in a
nevertheless compact construction. In addition these batteries also exhibit practically
no memory effect. However, these batteries are susceptible to a natural ageing pro-
cess which impairs their functionality.
Modern batteries today have a lifespan of around 500 charge cycles, which, when
used daily, corresponds to a service life of approximately 2 years. The ageing process
increases rapidly after this period, which means that the batteries are deemed techni-
cally defective after 500 charge cycles. Moreover, the battery cells could expand and
cause irreparable damage to your device in a worst case scenario.
For this reason rechargeable batteries with lithium cells should be replaced after 2
years at the latest or after reaching a battery capacity that is 50% of its initial value.

Note:
The battery used in this unit poses a fire hazard and can cause chemical injuries if it is used
improperly. Neither the battery nor the battery cells should be opened or disassem-
bled and they should not be burned or exposed to temperatures exceeding 60 °C.

9 Accessories

Only the following carrying devices must be carried into the hazardous area:
• Leather Case ecom art. A0030303
• Holster ecom art. A0030304
• Hand Strap ecom art. A0030316
Only the following scan handle must be used within the hazardous area in combina-
®
tion with the i.roc Ci70 –Ex:
• Scan Handle ecom art. A0030302

10 Head Modules

The following head modules are available. Only these named head modules must be
®
used with the i.roc Ci70 –Ex. A change is only possible in the ecom service centers.
Accessory Name
SN-SE955-AA
NL-TLB30-AA
NF-TLB30-AA
NH-UNI13-AA
NT-ARE8-AA
NT-LID-AA

11 Repair

Repairs are to be conducted by ecom instruments GmbH or by personnel or service
centers authorized by ecom instruments GmbH, because the safety of the device
needs to be tested after repairs are implemented. The actual repair report sheet can
be downloaded from the service area at www.ecom ex.com.

12 Cleaning, Maintenance and Storage

• Only use a suitable cloth or sponge to clean the handheld computer. Do not
use any solvents or abrasive cleaning agents when cleaning.
®
Ci70 -Ex. These batteries have
Description
1D Laser Barcode Scanner
125/134 kHz LF RFID R/W Module Air Coil
125/134 kHz LF RFID R/W Module Ferrite
13,56 MHz HF RFID R/W Module
TROVAN LF RFID R/W Module
TROVAN LF RFID R/W Module
