QRX / ERX Firmware Update

PRESS TO SEND
QRX PROG FILE
This page is used to update the firmware on a QRX or ERX receiver.
If the ZaxNet mode is set to OFF or receive (RX) this menu will allow for QRX firmware to be updated - if the
ZaxNet mode is set to transmit (TX) then this menu will allow for ERX to be updated.
For complete update instructions see the FIRMWARE section in the back of this manual.

OLED Brightness Adjust

OLED BRIGHTNESS:
3
This setting adjusts the brightness of the OLED display. The brightness setting is from 0 to 3 with 3 being the
brightness.

OLED Display Dim

DISPLAY DIM:
OFF (NORMAL)
This setting adjusts how long after the last key press the display will dim.

Information Page

- - - INFO - - -
FIRMWARE V1-00
SN: 1234 DSP:1B (ZHD)
OPT = 03
This page displays the current firmware version, the serial number, the DSP version, and the option code.

Hide Encryption Menu

ENCRYPTION MENU:
ON
This setting will hide the encryption menu. A hidden encryption menu allows for quicker navigation and
prevents accidental changes.
HIDDEN - The encryption menu doesn't appear when cycling through the menu settings.
•
DISPLAYED - The encryption menu will appear.
•
