HORNER VIM400 Product Specifications And Installation Data

To obtain user manual updates, visit our web site at www.heapg.com.
1

INTRODUCTION

The Video Capture Option (VIM400) allows four channels of NTSC or PAL video to be connected to an
SVGA OCS 451, 551, or 651. By using the Video Object in Cscape software, video can be displayed on
OCS screens in various sizes shown in Table 1.
The Video Object allows viewing video in a window, freezing the video, saving a single frame of the video
to Compact Flash, or viewing the video full screen with the full frame rate. A separate control register
allows ladder code to optionally freeze or save video snap-shots based on the machine state.
2

SPECIFICATIONS

Colors
Video Inputs
Video Objects
Resolutions per Video
Object
Resolution
(Display Sizes)
Signal Form
Image Input
UL
CE
08 October 2003
Video Capture Option for the
Products Specifications and Installation Data
Table 1 – VIM400 Specifications
Maximum 32,768
4 Video Inputs (NTSC or PAL)
Up to 4 Video Objects displayed per screen.
Each Video Object can be optionally set for the user to
dynamically select one of the four inputs.
•
640 x 480 full screen
•
640 x 480 pixel size
•
320 x 240 pixel size
•
160 x 120 pixel size
NTSC, PAL
1.0Vp-p, 75 ohms imbalance
See Compliance Table at
http://www.heapg.com/Support/compliance.htm
SVGA Color Touch OCS
HE500VIM400
4
