HORNER HE800PCU100 Configuration

Printer control unit

Advertisement

Quick Links

MAN0790-01
For PCU100 (PCU) specifications and installation information, refer to datasheet (MAN0432). See
Technical Support section in this document for manual updates and assistance.
1
Product Overview
The Printer Control Unit (PCU100)...
Is a low cost solution that allows you to collect, store and track data (up to 25 hours) and
print data Trend Reports without costly HMI units or chart recorders.
Comes conveniently pre-programmed to record and print four standard types of data trend
measurements that are commonly used in business and industry: Pressure, Flow Rate,
Temperature and Level trends.
Allows fast, easy creation of OCS interface using pre-programmed controls.
Connects to any Hewlett-Packard printer with IEEE 1284 parallel port and that uses PCL3
such as HP Deskjet 5650.
Provides customized reports such as alarm or industry-specific reports - available for additional
cost by contacting Horner Sales staff.
An example of a data trend report is on the last page of this document.
2
Configuration Overview
2.1
Brief Summary of Steps to be Taken
The following steps must be done to configure the PCU. They are covered in detail later in this section.
1. Setup equipment including the PCU, Hewlett Packard printer, cable, and Master Controller (Horner
Operator Control Station [OCS] in our example).
2. Configure the OCS to interface with the PCU via the CsCAN network.
3. Build a ladder program in the OCS to interface to and control the PCU.
19 APR 2005
Printer Control Unit
HE800PCU100
Configuration
PAGE 1
