HORNER HEXHSQ Specifications & Installation

24 / 5 V dual Channel High Speed PWM or Stepper Output Modules
1. SPECIFICATIONS
Parameter
Number of Channels
Output range
External supply range
Nominal Output impedance
Short Circuit protection
Isolated
Output Supply voltage
Output frequency
Mark Space ratio
Operating temperature
Compliance
http://www.horner-apg.com/en/support/certification.aspx
2. WIRING – I/O
Terminal Connector
1
2
3
4
The HEXHSQ requires external power
between 6 and 24 volts dc.
Wiring specification: It is recommended that shielded I/O wiring is used. Use Belden 8441, 18 AWG or larger or equivalent.
©Horner APG, LLC. No part of this publication may be reproduced without the prior agreement and written permission of Horner APG, LLC. Information in this document is subject to change without notice.
HEXHSQ HEXHSQ-5
2
6-30 VDC 5 VDC
6-30 VDC Internally powered
50Ω 50Ω
Foldback,
200mA loaded 100mA shorted
90mA shorted
1K VDC 1K VDC
n/a 50mA max @ 5V
0-400 KHz 0-8MHz
0-100% 0-100%
-10 to 60⁰C -10 to 60⁰C
CE, UL, see compliance table at:
http://heapg.com/support/compliance.htm
1 4
HEXHSQ Name
Q1
Q2
C
V+
HEXHSQ / HEXHSQ-5
2 Model #
HE-XE/HE-XT
HEXE/HEXT240
HE-XL/HE-XV
HEXT35X/HEXT501
HE-XC/HE-XW
HEXT251/HEXT391
See the relevant product manual for PWM and Stepper register mapping and
configuration. Requires f/w 12.94 or higher and Cscape 9.3 SP5 or higher.
Stepper on model 02's requires f/w 12.96 or higher.
Terminal Connector
The HEXHSQ-5 is a 5 volt only card that uses internal power and must
not have power applied. VO is an isolated 5 volt output available for
powering input circuitry of devices receiving the PWM signals.
MAN0979-01-EN_XHSQ_XHSQ-5_Datasheet
Specifications / Installation
Model Limitations
Series Name PWM
2 channels 8MHz
XLe / XLt
(50% duty) max
2 Channels
XL6 / XL10
500KHz Max
2 Channels
XL4 / XL7
500KHz Max
1 4
HEXHSQ-5 Name
Q1
1
Q2
2
C
3
VO
4
Stepper
1 stepper
5KHz max
1 stepper
5KHz max
2 steppers
500KHz max
8/28/2013
