HORNER HE800FOX100 Product Specifications And Installation Data

Fiber optic expansion module

Advertisement

Quick Links

1

PRODUCT DESCRIPTION

For detailed installation, configuration and other information, refer to the hardware manual of the
controller you are using. See the Additional References section in this document.
The FOX100 allows an OCS/RCS to connect up to five Fiber Optic Expansion bases and hubs (i.e.,
FOX104 and FOX404).
Note: The FOX100 is designed for use only with the following OCS/ RCS controllers: OCS110 /
OCS210 / Graphic OCS250, and RCS250.
2

FOX SPECIFICATIONS

Maximum number of stacks (total
number of hubs and bases)
Maximum number of cable drops to
any specific hub or base
Maximum length of Fiber Optic cable
Base ID#
Expansion I/O
Type of Fiber Optic Cable
Primary Power
Power Draw
Height
Width
Mounting Depth
Operating Temperature
Humidity
08 June 2005
Table 1 – FOX100 Hub and Base Specifications
Each Base or Hub must have a unique Base ID #.
EIAJ RC-5720 Plastic Fiber, TX+RX 10m per drop max host (OCS or
Fiber Optic Expansion Module
Products Specifications
5
3 (See Section Five for Example Setups.)
10 Meters per Drop
hub) to base
EIAJ RC-5720 (RC)
9-30VDC @ 400mA maximum
9-30VDC @ 400mA maximum
4.25" (108 mm)
6.63" (168.3 mm)
4.7" (119.4 mm)
32 - 122°F (0 - 50°C)
5% to 95% non-condensing
(HE800FOX100)
and Installation Data
MAN0509-03
