Faber MatriX 800/500 RD H Installation Manual

Hide thumbs Also See for MatriX 800/500 RD H:

Advertisement

Quick Links

Download this manual
Installation manual
MatriX 800/500 RD H
MatriX 800/500 ST H
MatriX 1050/500 RD H
MatriX 1050/500 ST H
ENG
40011991-2049

Advertisement

loading
Need help?

Need help?

Do you have a question about the MatriX 800/500 RD H and is the answer not in the manual?

Questions and answers

Related Manuals for Faber MatriX 800/500 RD H

Summary of Contents for Faber MatriX 800/500 RD H

  • Page 1 Installation manual MatriX 800/500 RD H MatriX 800/500 ST H MatriX 1050/500 RD H MatriX 1050/500 ST H 40011991-2049...
  • Page 2 Installation manual MatriX 800-1050x500 RD,ST H 1 < < < <...
  • Page 3 Installation manual MatriX 800-1050x500 RD,ST H 2 < < < <...
  • Page 4 Installation manual MatriX 800-1050x500 RD,ST H 3 < < < <...
  • Page 5 Installation manual MatriX 800-1050x500 RD,ST H 1.5a 1.5b 1.9a 1.9b 1.9c 1.9d 1.9e 1.9f 4 < < < <...
  • Page 6 Installation manual MatriX 800-1050x500 RD,ST H 2.1a 2.1b 3.0a 3.0b 3.1a 3.1b 5 < < < <...
  • Page 7 Installation manual MatriX 800-1050x500 RD,ST H 6 < < < <...
  • Page 8 Installation manual MatriX 800-1050x500 RD,ST H 7 < < < <...

  • Page 9: Installation Requirements

    Installation manual MatriX 800-1050x500 RD,ST H Dear user Safety instructions Congratulations on your purchase of a Faber fire! A  Please note! quality product from which you will experience warmth and atmosphere for many years. We It is advisable to always install a screen for the...

  • Page 10: Preparation And Installation Instructions

    C31, outlet via roof position in the false chimney. (See supplied instruction manual 40011721). For a (flat) roof, use a Faber roof outlet with a diameter of 100/150mm. (To prevent damage to cables and pipes during transport, they are bound together C91, existing chimney by tie wraps.
  • Page 11 The controller can be connected to an external source, such as a Domotica system, by using a Physical control: Faber Interface Unit (article number A9323000). Switch on the HPL module with the remote control and check whether the LED lamps are on (see 4.4 Preparing the fireplace...
  • Page 12 Removing glass of the gas control block and its electronics and also limits the temperature of the convection air. Use the (optional) Faber ventilation grids (article 5.1 MatriX 800-1050/500 RD number A9296400) or a similar alternative with a To take out the front glass, the side glass must first minimum free passage of 200cm²...
  • Page 13 Installation manual MatriX 800-1050x500 RD,ST H  To get the correct glow effect, the HPL module Open the glass clamps (see fig. 4.2);  must be switched on at 100% intensity. Push up frame “C” and move slightly forward so that it remains in the open position (see fig. Make sure the ITC-V2 app is connected to the fire.
  • Page 14 Installation manual MatriX 800-1050x500 RD,ST H  Pay extra attention to the fitting of the logs, Check: the logs must be able to slide slightly over the All section settings of the burners. burner tubes.  Now repeat the above check using the ITC-V2 APP. If necessary, increase block 1 with glass (App set at Dealer level).
  • Page 15 (fig. 12.1, 12.2 and 12.3 A, N and F). You Remove the front glass (see chapter 5). can find this value in the upper row of the You can clean the glass with Faber glass polish. restrictor table. This is a specially formulated cleaning agent that can be ordered at authorized Faber dealers.
  • Page 16 Installation manual MatriX 800-1050x500 RD,ST H  THL is the Total Horizontal Length and Pipes at an angle of inclination: consists of elbows and pipes entirely in These are pipes vertically ascending at an the horizontal plane. See elbows I, K and Q angle of 30°...
  • Page 17 Installation manual MatriX 800-1050x500 RD,ST H 11.1 Restrictor table (100/150) MatriX 800/500 RD H, ST H en MatriX 1050/500 RD H, ST H Start length (STL) Vertical (TVH) and Horizontal (THL) 60,2 70,2 80,2 90,2 90,2 100,2 100,2 110,2 110,2...
  • Page 18 Installation manual MatriX 800-1050x500 RD,ST H 11.2 Restrictor table (130/200) MatriX 800/500 RD H, ST H en MatriX 1050/500 RD H, ST H Start length (STL) Vertical (TVH) and Horizontal (THL) 17 < < < <...
  • Page 19 Installation manual MatriX 800-1050x500 RD,ST H 12 Examples flue materials 18 < < < <...
  • Page 20 Installation manual MatriX 800-1050x500 RD,ST H 13 Calculation sheet Starter length (STL) First part on top of the appliance Value Flue length from 0,1m till 0,45m Flue length from 0,5m till 0,90m Flue length from 1m till 1,4m Flue length from 1,5m till 2m Flue length 2m or more Bend 90°...
  • Page 21 Installation manual MatriX 800-1050x500 RD,ST H found value Search in the table at TVH and THL and enter the value that is found. ……………………………… If the detected value is a number, check whether the completed STL is higher or equal to the value in the table.

  • Page 22: Technical Data

    Installation manual MatriX 800-1050x500 RD,ST H 14 Technical data 14.1 MatriX 1050/500 RD H, ST H 21 < < < <...
  • Page 23 Installation manual MatriX 800-1050x500 RD,ST H 14.2 MatriX 1050/500 RD H, ST H 22 < < < <...
  • Page 24 Installation manual MatriX 800-1050x500 RD,ST H 15 Outlet position  Please note! These rules apply only for the proper functioning of the unit, for ventilation and environmental protection you need to comply with the applicable rules as defined in the building regulations. Short roof terminal.
  • Page 25 Installation manual MatriX 800-1050x500 RD,ST H 16 Top view sectional burner 800/500 RD H and ST H 16.1 Position of the light guides 800/500 RD H and ST H 24 < < < <...
  • Page 26 Installation manual MatriX 800-1050x500 RD,ST H 16.2 Top view sectional burner 1050/500 RD H and ST H 16.3 Position of the light guides 1050/500 RD H and ST H ‘ 25 < < < <...
  • Page 27 Installation manual MatriX 800-1050x500 RD,ST H 17 Logset Lay-out 800-1050/500 RD H and ST H 800/500 1050/500 Gebruik de meegeleverde decoratie-instructiekaart, of scan voor een duidelijke instructievideo de QR code: 26 < < < <...

  • Page 28: Dimensional Drawings

    Installation manual MatriX 800-1050x500 RD,ST H 18 Dimensional drawings 18.1 MatriX 800/500 RD H and MatriX 1050/500 RD H 27 < < < <...
  • Page 29 Installation manual MatriX 800-1050x500 RD,ST H 18.2 MatriX 800/500 ST H and MatriX 1050/500 ST H 28 < < < <...
  • Page 30 Installation manual MatriX 800-1050x500 RD,ST H 18.3 Control box FAB1806 29 < < < <...
  • Page 31 Installation manual MatriX 800-1050x500 RD,ST H 18.4 Ventilation grid (article number A9296400) 30 < < < <...
  • Page 32 Installation manual MatriX 800-1050x500 RD,ST H 18.5 Adjustable feet (article number A9319696) 31 < < < <...
  • Page 33 Installation manual MatriX 800-1050x500 RD,ST H 32 < < < <...
  • Page 34 Installation manual MatriX 800-1050x500 RD,ST H 33 < < < <...
  • Page 35 Installation manual MatriX 800-1050x500 RD,ST H 34 < < < <...
  • Page 36 www.faberfires.com contact@faberfires.com Saturnus 8 NL 8448 CC Heerenveen Postbus 219 NL 8440 AE Heerenveen...
