- Page 1 DIGI+ Digi Cell Plus - Digital Oil Test Cell MA-K32184 Rev.-1.0 © 2021, Parker Hannifin Manufacturing Ltd www.parker.com...
-
Page 2: Table Of Contents
Contents Overview ..................4 Introduction .......................4 Smart Setup, Data Storage & Rechargeable Battery ..........4 Safety Information .....................5 Test by-product (H ) ....................6 Conformity .........................6 Exclusion of Liability ....................6 Principle of Operation ....................7 Water (H O) in Oil Measurement ................7 Base Number of Oil Measurement ................7 Technical Specification .....................8 Before Starting ................ - Page 3 Contents Maintenance & Servicing ............34 Shipping Note......................34 Troubleshooting ................. 35 Measurement ......................35 BN-specific Measurement ..................35 Results ........................36 Result Comparison ....................37 Connectivity, Battery & Power ................37 DIGI_CFG.csv ......................37 Digi Cell Plus - Digital Oil Test Cell Information Guide...
-
Page 4: Overview
Overview Introduction Digi Cell Plus (DIGI+) is a Digital Oil Test Cell with USB storage and charging. DIGI+ provides an accurate means of detecting and measuring the quantity of water (H O) in oil and / or the residual Base Number (BN) of oil. This battery- operated, rugged and compact mobile instrument provides easily retrievable data to ensure fast, accurate and consistent management of lubricating oil samples. -
Page 5: Safety Information
Safety Information DIGI+ and reagents should be operated by persons trained in the use and handling of hydrocarbon products, including new and used lubricants. Persons should also be familiar with basic laboratory or workshop environments and associated hazard awareness. Prior to operating, DIGI+ should be inspected for damage. If any damage is found, consult with the supplier of DIGI+ accordingly. -
Page 6: Test By-Product
Test by-product (H Hydrogen gas (H Use in well ventilated areas. build-up risk No open flames, smoking or sources of ignition. Never add water instead of oil samples. Dispose of waste carefully. The water in oil test reagents react rapidly with water. In normal operation up to 70 ml H is generated. -
Page 7: Principle Of Operation
Principle of Operation DIGI+ measures the pressure generated by a chemical reaction that takes place inside the closed sample cup. An oil sample and reagents are put into the sample cup and DIGI+ is closed and shaken to aid the chemical reaction. The pressure is proportional to the parameter to be measured. -
Page 8: Technical Specification
Technical Specification Water Measurement Range (v/v) Measurement Range (mg KOH/g) 0.1 % to 20.0 % 1 to 150 0.1 % to 10.0 % 0.02 % to 1.00 % 200 ppm to 10000 ppm 100 ppm to 3000 ppm Water Range Resolution BN Resolution 0.1 % to 20.0 % 0.1 %... -
Page 9: Before Starting
Before Starting Contents NOTE: Original packaging must not be disposed of as this is required to return the DIGI+ safely to the supplier for maintenance and / or servicing. Accessories: PPE, reagents, syringes and consumables DIGI+ Agitator – DIGI+ Water (H O) and DIGI+ Combined variants Micro-USB charging cable... -
Page 10: Manufacturer Information, Consumables & Spares
Manufacturer Information, Consumables & Spares For service, please see the ‘Contact, consumables and spares information sheet’. Digi Cell Plus - Digital Oil Test Cell Information Guide... -
Page 11: Digi+ Instrument Overview & Operation
DIGI+ Instrument Overview & Operation Easy-to-read multicolour backlit screen Soft touch keypad 112mm DIGI+ body upper Pressure Sensor - Wipe gently only with soft cloth O-ring 76mm Sample cup Agitator O testing only Charging Charge fully with Refit USB socket cover micro-USB cable before first use Fully charged battery... -
Page 12: Powering On & Off
Powering On & Off Powering On Powering Off Use Left (L), Middle (M) or Right (R) button to power on AUTO-OFF Backlight turns off after 20 seconds. Press any button to after re-activate 5 minutes Opening & Closing DIGI+ Opening Closing Hold the sample cup Hold the sample cup and... -
Page 13: Sampling
Sampling Obtaining a representative sample is one of the most important parts of oil analysis. If a sample does not represent the true condition of the lubricant and component at the time of sampling, the reliability of both the test result, and the interpretation of it, is affected. -
Page 14: Setup Menu Navigation
Setup Menu Navigation Setting Date & Time > Date/Time < OK q to select YEAR u q to select MONTH u q to select DAY OK q to select HOUR (24H) u q to select MINUTES OK BN Calibration Gas is generated from a chemical that reacts with available (remaining) BN additive in the sample. Gas pressure from used oil is compared to new oil as a ratio: Pressure is generated in DIGI+ proportional to the remaining BN additive in the used oil sample and is compared to pressure from the new oil. -
Page 15: Oil Types
Oil Types DIGI+ stores the value of pressure generated by new oil as a reference. The pressure for new oil is measured once and saved. DIGI+ can save values for multiple new oils in its memory as OIL TYPES . •... -
Page 16: Bn Oil Type List Name, Bn Value & Calibration
BN OIL TYPE List Name, BN Value & Calibration DIGI+ stores calibration data for up to 8 different OIL TYPES . In Smart DIGI+ mode stores calibration data separately for up to 10 different OIL TYPES (these can only be edited in DIGI_CFG.csv file on USB drive) NOTE: It is recommended to use the oil grade or name as the “Name”... -
Page 17: Cleaning
Cleaning Cleaning is required following each oil calibration and each test. The following steps should be taken to ensure safety: 1. Contents should be disposed of carefully. 2. DIGI+ body upper and sample cup (including agitator for H O testing) should be thoroughly cleaned. -
Page 18: Testing
Testing Before starting the test: • DIGI+ should be clean and dry (particular attention should be paid to the seal). See Cleaning • EasySHIP reagent must be above 18 °C and should be shaken thoroughly Test Menu Navigation Water (H O) - Single Test Follow on-screen instructions... -
Page 19: Base Number (Bn) - Single Test
Base Number (BN) - Single Test BN Calibration Measure Used Oil Select Oil using q (Follow on-screen instructions) Note: Close and hand tighten only (1/8 turn max.) ABOUT BN TESTING AND CALIBRATION • BN Calibration must take place for an OIL TYPE to be measured •... -
Page 20: Interpreting Results
Interpreting Results Water Water contamination may cause different problems in different types of lubricating oil, although corrosion is always directly associated with water ingress. Whatever the equipment, water can displace the oil at contacting surfaces, reducing the amount of lubrication and activating surfaces which may themselves act as catalysts for degradation of the oil. -
Page 21: Base Number
Base Number BN is only relevant to diesel engine lubricants and not relevant for gear oils or hydraulic oils. Alkaline additives are present to neutralise acids derived from both combustion (mainly strong sulphuric and nitric acids) and those weaker, organic acids resulting from oxidation of the oil as occurs during ageing. -
Page 22: Gas Engine Oils
Gas Engine Oils Type Water % Maximum BN value (% Change) Typical Measurement Frequency in days Medium Speed Natural Gas 100 °C Minimum 2 (-50 %) 0.3 % Lean Burn 40 °C Other Applications Type Warning Exceeds limit Notes Typical Measurement Frequency in days Check upper limit Enclosed Gear Oils... -
Page 23: Spid (Smart Features) - Overview And Setup
SPID (Smart features) – Overview and setup Smart features are automatically launched when DIGI+ is connected to a PC (Windows and Mac), providing the ability to record results and to export for further analysis. The SPID structure provides a guided approach to measurements, ensuring all samples are measured in order. -
Page 24: Creating & Editing An Oil Type List Via A Pc And & Importing To Digi
Creating & Editing an OIL TYPE List via a PC and & Importing to DIGI+ (BN measurement) For optimal efficiency, the oil reference list for BN measurement may be configured via a PC rather than entered manually via the DIGI+ keypad: Creating an OIL TYPE List on PC (first time setup) Power on >... - Page 25 Editing an OIL TYPE List on PC Locate file on Connect to PC using micro-USB cable. File will be on the drive list as ‘DIGI DRIVE (X:)’ Make changes Save file (or replace one on ‘DIGI DRIVE (X:)’) to OIL TYPE list Importing edited OIL TYPE List to DIGI+ Connect...
-
Page 26: Bn Measurement Visual Indicators
BN Measurement Visual Indicators By connecting to a PC and using the DIGI+ smart functionality, cautionary alert limits can be entered for easy real-time result viewing. The user simply enters ‘Low BN’ and ‘High BN’ limits into columns C & D of the DIGI_CFG file. Note: It is recommended to set these below target to give warning time. -
Page 27: Creating A Sample Point Identification (Spid) List Via A Pc & Importing To Digi
Creating a Sample Point Identification (SPID) List via a PC and & Importing to DIGI+ Creating a SPID List on PC (first time setup) Power on > PC Import < SETUP > SPIDs < Locate file on Configuration file is called ‘DIGI_CFG.CSV’. File will be on the drive list as ‘DIGI DRIVE (X:)’... - Page 28 Editing a SPID List on PC Locate file on Configuration file is called ‘DIGI_CFG.CSV’ File will be on the drive list as ‘DIGI DRIVE (X:)’ Locate File Make changes Save file (or replace one on ‘DIGI DRIVE (X:)’) to SPID list Importing edited SPID List to DIGI+ Connect Connect to PC using micro-USB cable...
-
Page 29: Spid Measurement & Storage
SPID Measurement & Storage A SPID set is a batch of single tests. A new set is opened and then test results are collected. Measurements can be repeated, for example, with an H O measurement, if the test is below the detection limit and a lower range is needed (from 0.1 % to 20.0 % to a 0.02 % to 1.00 % range on the same SPID). -
Page 30: Examples
Examples Spreadsheet Text Editor Care must be taken to ensure comma formatting is maintained and correct columns are being edited. See online guidance on using .csv files Measurement & Download Cycle Select SPID to 0/X SPIDs Done measure New SET Keep measuring automatically SPID (repeat if... -
Page 31: Measuring And Closing A Spid Set
Measuring and Closing a SPID Set Action Visual Description From SPID HOME screen TEST q to select SPID to be tested (RETEST if test data already exists) Follow on-screen instructions START Measurement. When completed press any key to continue Saving, Repeating or Deleting Measurements After performing a test in a SPID sequence the user can: SAVE, REPLACE or DISCARD measurement DELETE result or RETEST... -
Page 32: Clearing Digi+ Memory
Clearing DIGI+ Memory To delete SPID data and disable smart functionality: Visual Description > SPIDs < OK > Delete < DIGI+ Reset To remove all PC loaded data and stored data: Visual Description > Reset < Digi Cell Plus - Digital Oil Test Cell Information Guide... -
Page 33: Digi+ Utility
DIGI+ Utility A utility to configure DIGI+, download data and view trends in the SPIDs is available. See the ‘Contact, consumables and spares information sheet’ for links to these tools. Digi Cell Plus - Digital Oil Test Cell Information Guide... -
Page 34: Maintenance & Servicing
Maintenance & Servicing No user-serviceable parts are contained within. DIGI+ must not be disassembled and will render warranty void. For servicing, please see the ‘Contact, consumables and spares information sheet’ on the USB drive supplied with DIGI+ kit or consult supplier. DIGI+ has been designed with precision components for long term measurement accuracy therefore no periodic recalibration is necessary. -
Page 35: Troubleshooting
Troubleshooting Measurement Symptom Possible Cause Possible explanation and Solutions In very rare cases, the water test reagents may react with a component of the stock oil. If DIGI+ continuously over- Reaction with the oil pressurises, yet the water content is known to be in range, the water test will not be suitable for use with that stock oil. -
Page 36: Results
Results Symptom Possible Cause Possible explanation and Solutions Unclean instrument Dirt or leftover reagents / oil from last test. Before starting testing, the insides of DIGI+ and sample cup must be clean and dry (particular attention should be paid to the Contamination O-ring and threaded surfaces). -
Page 37: Result Comparison
Result Comparison Symptom Possible Cause Possible explanation and Solutions A sample with water and / or low BN can continue to age Samples continue to age such that the chemical composition of the oil is different to after being taken when it was tested. - Page 38 PT – Portugal FR, IE, IL, IS, IT, LU, MT, NL, NO, PL, PT, RU, Tel: +351 22 999 7360 SE, SK, UK, ZA) © 2021 Parker Hannifin Corporation. All rights reserved. Digi Cell Plus - Digital Oil Test Cell Information Guide...
