SIRIUSi-XHS-PWR
TECHNICAL REFERENCE MANUAL
SIRIUSi-XHS-PWR V21-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIRIUSi-XHS-PWR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEWESOFT SIRIUSi-XHS-PWR

Summary of Contents for DEWESOFT SIRIUSi-XHS-PWR

  • Page 1 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL SIRIUSi-XHS-PWR V21-1...

  • Page 2: Table Of Contents

    2. Safety instructions 3. Getting started 3.1. Software installation 3.2. Connecting SIRIUSi-XHS-PWR 3.2.1. Network settings 3.2.1.1. Troubleshooting 3.2.2. DewesoftX® Settings SIRIUSi-XHS-PWR 3.2.3. Channel Setup SIRIUSi-XHS-PWR 3.3. Simple Measurement 3.3.1. Help - Manual 3.3.2. Analogue channel setup 3.3.3. Sample rate 3.3.4. Measurement Mode 3.3.5.
  • Page 3 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 7. Notice 7.1. Warranty Information 7.2. Calibration 7.3. Support 7.4. Service/repair 7.5. Restricted Rights 7.6. Copyright 7.7. Trademarks 7.8. Documentation version history SIRIUSi-XHS PWR V21-1 3/39...

  • Page 4: About This Document

    TECHNICAL REFERENCE MANUAL 1. About this document This is the Technical Reference Manual for SIRIUSi-XHS-PWR Version V21-1 SIRIUS-XHS-PWR (SIRIUSi-XHS-1xHV-1xDCCT) is a high performance, high speed line of SIRIUS® real time data acquisition hardware used for the most demanded power measurements, specially designed for E-mobility applications.

  • Page 5: Online Versions

    1.2.1. SIRIUS-XHS-PWR technical reference manual The most recent version of this manual can be downloaded from our homepage: https://download.dewesoft.com/list/manuals-brochures/hardware-manuals In the Hardware Manuals section click the download link for the SIRIUSi-XHS-PWR technical reference manual. 1.2.2. DewesoftX® tutorials The DewesoftX® tutorials document, provides basics and additional information and examples for working with DewesoftX®...

  • Page 6: Safety Instructions

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 2. Safety instructions Your safety is our primary concern! Please be safe! Warning Prior to first usage it is recommended to read Safety Reference Manual in a separate document: SIRIUSi XHS-PWR, Safety, Technical Reference Manual V21-1...

  • Page 7: Getting Started

    ● 3.1. Software installation For optimal working, we recommend that you install the latest version of Dewesoft. If you already have installed the older version Dewesoft is recommended that you find the newest version on the website under Support/Downloads/DewesoftX section. You can also check if a newer version is available in software.

  • Page 8: Connecting Siriusi-Xhs-Pwr

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 3.2. Connecting SIRIUSi-XHS-PWR In this chapter, you can see the basic instructions for connecting SIRIUSi-XHS-PWR devices. Advanced connections are described in the following chapters. 3.2.1. Standalone unit connection Image 2: Connection of SIRIUSi-XHS-PWR standalone device to PC...
  • Page 9 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 3.2.2. Multiple units connection Image 3: Connection of multiple SIRIUSi-XHS-PWR units to PC using PoE List of required accessories: Function Dewesoft order code Power supply PS-120-L1B2f (default), L1B2f-BAN-3m Switch DS-PWR-SWITCH4 Power + Data L1B8m-L1B8f-3m Ethernet Connection to PC...

  • Page 10: Network Settings

    - Subnet mask: 255.255.255.0 3.2.3.1. Troubleshooting If Dewesoft doesn’t detect your devices you should try pinging them via command prompt. In command prompt write: ping IP replace IP with IP that is set on your device. The result should be something like this:...

  • Page 11: Dewesoftx® Settings Siriusi-Xhs-Pwr

    TECHNICAL REFERENCE MANUAL 3.2.4. DewesoftX® Settings SIRIUSi-XHS-PWR SIRIUSi-XHS-PWR devices have static IP. When adding a new device open DewesoftX® and go to Options->Settings as shown in Image 5. Click on the Options button at the top right, and then on the Settings item in the pop-up to open the DewesoftX®...
  • Page 12 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL Image 6: DewesoftX® settings Adding a new XHS device is done by clicking +, this will show the Add device window where you can find a Real-time controller. Sirius-XHS is an RT device so you should add it by clicking + on RT Device. If you want to use two devices you should add two.
  • Page 13 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL Image 7: Adding RT device Support of RT-devices is still an Experimental feature. If you do not see this option when adding a device, the option needs to be enabled under Advanced -> Experimental settings. SIRIUSi-XHS PWR V21-1...
  • Page 14 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL Image 8: Enable experimental feature After that you will see a new Sirius XHS or Dewesoft RT connection in the device tree. SIRIUSi-XHS PWR V21-1 14/39...
  • Page 15 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL Image 9: Two RT devices If the text by the device is disconnected, you should click on the device (Dewesoft RT Connection) , set the correct IP and refresh. SIRIUSi-XHS PWR V21-1 15/39...
  • Page 16 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL Image 10: Setting IP If everything is set correctly both devices should be detected as Sirius-XHS devices. SIRIUSi-XHS PWR V21-1 16/39...
  • Page 17 Image 11: Devices overview Before measurement you need to set synchronization. This is done by selecting Local system and selecting time source as External, External (Clock provider) as PTP and Dewesoft DAQ Devices (Clock slave) as PTP. Image 12: Setting synchronization...

  • Page 18: Channel Setup Siriusi-Xhs-Pwr

    (or multiple channels) in the setup grid, the corresponding connectors in the image will be highlighted. The sampling rate will be set for all connected SIRIUSi-XHS-PWR units: of course only up to the max. sampling rate of the individual units.

  • Page 19: Analogue Channel Setup

    One of the most important settings is the sample rate. The sample rate defines how many data points, SIRIUSi-XHS-PWR will transfer to DewesoftX®. Higher sample rate also means that more data needs to be transferred via ethernet to your computer.

  • Page 20: Measurement Mode

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL The sampling speed mainly depends on your application. To display your signal in a time domain with a good time resolution, you should sample 10 to 20 times faster than the frequency of the signal that you want to measure, e.g.

  • Page 21: Advanced Configuration

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL Image 17: Analyse mode The Review mode is much like the measurement mode. You will see the same measurement screens, the channel-selector list and the properties of the currently selected instrument. Differences are: (1) you have additional tool-buttons (2) there is a Signal overview window which will show you the whole data of one selected channel of the data file...

  • Page 22: Firmware Upgrade

    Dewesoft upgrade package (.dxu file) from the Dewesoft downloads page under ● the section Drivers. Copy the file into the Firmwares folder of your Dewesoft installation (e.g. ● D:\DewesoftX\System\X3\Firmwares). Connect the Dewesoft instrument to the PC and run Dewesoft X3.

  • Page 23: Licensing

    (6). However if the user decides to upgrade the license with an additional extension, Dewesoft will require a new license registration. The registration can be made online (2) or offline by importing an offline license (5) in case the system doesn’t have an internet connection.

  • Page 24: Troubleshooting

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 3.7. Troubleshooting If your SIRIUSi-XHS-PWR device is not found by DewesoftX®: If you did not restart Windows after the software installation, restart now ● Make sure that you have started DewesoftX® version X3 SP12 or higher ●...

  • Page 25: System Overview

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 4. System overview SIRIUS-XHS-PWR Sirius XHS is the first device ever with Hybrid ADC technology capable of doing both high bandwidth transient recording and very high dynamic alias-free acquisition - software-selectable per channel. Modern interfaces and protocols allow open and flexible connectivity.

  • Page 26: Main Features

    SOFTWARE INCLUDED WITH FREE LIFETIME UPGRADES: The easy-to-use but rich in ● functionality, award-winning DEWESoft X3 software is included. All upgrades to the software are free forever with no hidden licensing costs. SIRIUSi-XHS PWR V21-1...

  • Page 27: Hybrid Adc Technology

    SIgma-delta filtering group delay. But with SIRIUS XHS, due to the nature of the chosen filter, both modes are perfectly aligned and synchronized. As on any Dewesoft devices, data can be synchronized to other data sources, such as vehicle bus interface, GPS, IMU, video, and others.

  • Page 28: Perfect Amplifiers For Power Measurements

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 4.1.3. Perfect amplifiers for power measurements KEY FEATURES Voltage: Highly isolated CATII 1000 V, from 200 V to 2000 V range, >5 MHz bandwidth with down to 0.03% accuracy, this device is perfect for direct connection of high voltage signal.

  • Page 29: Open Interface Protocols

    Dewesoft X is the world's most advanced and easy-to-use data acquisition and analysis software. Dewesoft X's flexibility and power will help you unleash the DAQ system to its full potential and gives you many advantages over other DAQ systems. Functionalities like plug-and-play, hardware auto-detection, smart TEDS sensors, advanced storing and data analysis features will take your measurement and analysis needs to a whole new level.

  • Page 30: Specifications

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 5. Specifications 5.1. SIRIUS-XHS-PWR specifications 5.1.1. SIRIUSi-XHS-1xHV-1xDCCT-1000A specifications SIRIUS-XHS-PWR specifications SIRIUSi-XHS-1xHV-1xDCCT-1000A Input types Voltage, Current (single phase) Inputs Voltage ADC Type Hybrid ADC - 24-bit alias free up to 1 MS/s, 16-bit up to 15 MS/s...
  • Page 31 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL Primary / Secondary Ratio 1 : 1680 Input Accuracy (Ip @ 10 Arms) Signal frequency Accuracy ±0.1 % of reading ±50 ppm of range ±0.05 A Up to 10kHz 25 mdB +/-0.3% Up to 20 kHz 70 mdB +/-0.8%...
  • Page 32 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 5.1.2. SIRIUSi-XHS-1xHV-1xDCCT-250A specifications SIRIUS-XHS-PWR specifications SIRIUSi-XHS-1xHV-1xDCCT-250A Input types Voltage, Current (single phase) Inputs Voltage ADC Type Hybrid ADC - 24-bit alias free up to 1 MS/s, 16-bit up to 15 MS/s Sampling Rate Simultaneous 15 MS/s...
  • Page 33 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL ±0.1 % of reading ±50 ppm of range ±0.05 A Up to 10kHz 25 mdB +/-0.3% Up to 20 kHz 70 mdB +/-0.8% Up to 200kHz 350 mdB 4% Gain drift (current) typ. 40ppm/K Offset drift typ. 200 uA/K Linearity error @ 1000 A range typ.

  • Page 34: Dimensions

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 5.2. Dimensions 5.2.1. SIRIUSi-XHS-1xHV-1xDCCT-1000A Technical drawing Image 22: SIRIUSi-XHS-1xHV-1xDCCT-1000A dimensions SIRIUSi-XHS PWR V21-1 34/39...
  • Page 35 SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 5.2.2. SIRIUSi-XHS-1xHV-1xDCCT-250A Technical drawing Image 23: SIRIUSi-XHS-1xHV-1xDCCT-250A dimensions SIRIUSi-XHS PWR V21-1 35/39...

  • Page 36: General Product Information And Instructions

    6.1. Environmental Considerations Information about the environmental impact of the product. 6.2. Product End-of-Life Handling Observe the following guidelines when recycling a Dewesoft system: System and Components Recycling Production of these components required the extraction and use of natural resources. The substances...

  • Page 37: Notice

    Dewesoft system can be requested. We retain them for at least one year, after system delivery. 7.3. Support Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties regarding the system. For any support please contact your local distributor first or Dewesoft directly.

  • Page 38: Copyright

    When used in text representing the company, product or technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ® sign is not used in the visual representation of the triangle logo.

  • Page 39: Documentation Version History

    SIRIUSi-XHS-PWR TECHNICAL REFERENCE MANUAL 7.8. Documentation version history Version Date Notes V20-1 17.09.2020 Initial document version. V21-1 26.06.2021 Updated: Safety General product information and instructions SIRIUSi-XHS PWR V21-1 39/39...
