  • Page 1 IOLITE X TECHNICAL REFERENCE MANUAL V24-1...
  • Page 2: Table Of Contents

    1. Table of contents 2. About this document 2.1. Legend 2.2. Online versions 2.2.1. Device Technical Reference Manual 2.2.2. DEWESoft® User Manual 3. Getting started 3.1. Software installation 3.2. Connecting IOLITE® X 3.2.1. Default configurations 3.2.1.1. Connection to the PC 3.2.1.2.
  • Page 3 8.1. Safety symbols in the manual 8.2. General Safety Instructions 8.2.1. Environmental Considerations 8.2.2. Product End-of-Life Handling 8.2.3. System and Components Recycling 8.2.4. General safety and hazard warnings for all Dewesoft systems 8.3. Documentation version history IOLITE X V24-1 2/50...
  • Page 4: About This Document

    The most recent version of this manual can be downloaded from our homepage: https://dewesoft.com/download/manuals 2.2.2. DEWESoft® User Manual The DEWESoft® User Manual document provides basics and additional information and examples for working with DEWESoft® and certain parts of the program. The latest version of the DEWESoft® tutorials can be found here: https://dewesoft.com/download/manuals...
  • Page 5: Getting Started

    IOLITE X TECHNICAL REFERENCE MANUAL 3. Getting started This chapter will help you to install the software, connect your IOLITE® X system to the PC and will show you how to configure DewesoftX®. To follow these steps, you need the following items: your brand new IOLITE X system (included in the shipment) ●...
  • Page 6: Connecting Iolite

    IOLITE X TECHNICAL REFERENCE MANUAL 3.2. Connecting IOLITE® X In this chapter, you can see the basic instructions for connecting IOLITE® X devices. Advanced connections are described in the following chapters. The IOLITE X line has a GbE with PTPv2 (IEEE1588v2) synchronization and PoE++ power delivery (Power over Ethernet).
  • Page 7: Daisy Chain Connection With Standard Poe

    IOLITE X TECHNICAL REFERENCE MANUAL 3.2.1.2. Daisy chain connection with PoE Important This device supports PoE++ power delivery and requires a certain voltage level to work! The device that is first in line, has to be powered with 48 V - 57 V to enable the PoE. Caution When connecting devices with Power over Ethernet be sure to connect them at least 2 cm apart to ensure better cooling of the devices.
  • Page 8: Dewesoftx® Settings Iolite

    IOLITE X TECHNICAL REFERENCE MANUAL 3.2.2. DewesoftX® Settings IOLITE® X 3.2.2.1. Ethernet configuration on the PC IOLITE X will be properly connected to DewesoftX software when the IP address of the device and the IP address of the network card, where the device is connected, are in the same subnet. Warning As a network device with DHCP enabled it can use dynamic IP assignment.
  • Page 9: Autodetect

    IOLITE X TECHNICAL REFERENCE MANUAL Autodetect 3.2.2.4. Configuring the IP address inside the discovery module If the device is not automatically detected, the use has to add the device manually with an IP address (default: 192.168.10.1) The user can modify the IP of the X device to match it to the IP of the network card. When the IP addresses will match, the user will be able to add the device in the settings.
  • Page 10: Device Overview

    IOLITE X TECHNICAL REFERENCE MANUAL 3.2.3. Device overview After the device is properly added it will be listed in the HW tree view list. When you select the device the properties pane at the right will show the related data e.g. Serial number, Firmware version, IP address etc.
  • Page 11: Connecting Settings

    IOLITE X TECHNICAL REFERENCE MANUAL X device overview 3.2.3.1. Connecting settings Under the connecting setting you will see the IP address of the device, which relates to the IP of the currently connected device. Changing this IP will not change the IP of the device, but will search for a device with the IP address you entered.
  • Page 12: Simple Measurement

    IOLITE X TECHNICAL REFERENCE MANUAL 3.3. Simple Measurement This chapter describes measurement basics, how to configure IOLITE® X and gives some details on the measurement setup. 3.3.1. Help - Manual Note that this document is just a quick start guide. For detailed information about DewesoftX® consult ❶...
  • Page 13: Analog Channel Setup

    IOLITE X TECHNICAL REFERENCE MANUAL 3.3.2. Analog channel setup In the analog channel setup screen you can see all channels of your connected IOLITE® X systems. Per default only the first channel will be set to used. Unused channels will not show up in measure mode and can thus not be used for display, calculations or storing: thus, we will also set the other channels to ❶...
  • Page 14: Sample Rate

    IOLITE X TECHNICAL REFERENCE MANUAL 3.3.3. Sample rate One of the most important settings is the sample rate. The sample rate defines how many data points IOLITE® X will transfer to DewesoftX®. A higher sample rate also means that more data needs to be transferred to your computer.
  • Page 15: Measurement Mode

    IOLITE X TECHNICAL REFERENCE MANUAL 3.3.4. Measurement Mode A click on Measure (at the right side of Ch. setup in Illustration below) will take you to the Recorder screen measure mode where you can already see live data. Hint When switching to Measure mode the data will not be stored automatically. Measure mode ❺...
  • Page 16: Analyse Mode

    IOLITE X TECHNICAL REFERENCE MANUAL 3.3.5. Analyse Mode When you have just stopped a measurement, DewesoftX® will automatically open the last recorded data file in Review mode, so that you can start the analysis right away. Analyse mode The Review mode is much like the measurement mode. You will see the same measurement displays, the channel-selector list and the properties of the currently selected widget.
  • Page 17: Firmware Upgrade

    ● the section Drivers. Copy the file into the Firmwares folder of your DewesoftX® installation (e.g. ● D:\DewesoftX\System\Firmwares). Connect the Dewesoft instrument to the PC and run DewesoftX®. ● Go to settings under the Update tab: ● Firmware update settings If the firmware package isn’t selected, select it by pressing the button and find the folder with the...
  • Page 18: Licensing

    IOLITE X TECHNICAL REFERENCE MANUAL 3.5. Licensing IOLITE X or any other Dewesoft device already comes with an embedded DewesoftX® license. You can ❶ check the license details with all the available options in the Licensing tab by pressing the three ❻...
  • Page 19: System Overview

    IOLITE X TECHNICAL REFERENCE MANUAL 4. System Overview IOLITE X Small in size, but powerful and easily distributed for monitoring and industrial applications. openDAQ SDK compliant. Voltage Strain / Stress Resistance Quarter Bridge Half Bridge Full Bridge IEPE DSI Compatible TEDS Compatible IOLITE X V24-1 18/50...
  • Page 20: Main Features

    Plug-and-play technology with smart sensors and advanced TEDS is supported by default. This makes performing measurements with the Dewesoft DAQ systems easier than riding a bike. You will be ready to measure in no time. IOLITE X V24-1...
  • Page 21: System Specifications

    IOLITE X TECHNICAL REFERENCE MANUAL 4.2. System specifications IOLITE X GLAN Ethernet Data interface 1 GbE incl. IEEE1588v2 synchronization (PTPv2) Data Rate 1 Gbps Sync Accuracy 100 ns Bus connectors Ethernet RJ45, single cable for data, power and sync, daisy chainable Power over Ethernet 48 - 57 V DC (PoE++ power delivery) Max.
  • Page 22 IOLITE X TECHNICAL REFERENCE MANUAL X 8xSTGS X 8xLVe X 16xLV X 8xACC Terminal block, Terminal block, Connectors DSUB-37 DSUB-37 Terminal block Channels per module Data rate per channel 50 kS/s 200 kS/s 100 kS/s 200 kS/s Resolution 24-bit 24-bit 24-bit 24-bit Bandwidth...
  • Page 23: Iolite X: Multi Channel Device

    IOLITE X TECHNICAL REFERENCE MANUAL 4.2.1. IOLITE X: Multi channel device IOLITE X multi-channel modules are fully compatible with the DIN rail mount. Chassis offers an easy clip-in mechanism for mounting to all standard industrial DIN rail mounts. IOLITE X DAQ devices use RJ45 connectors which allow easy connection of modules with standard low-cost Ethernet cables.
  • Page 24: Iolite X - Multi Channel: Dimension

    IOLITE X TECHNICAL REFERENCE MANUAL 4.2.1.2. IOLITE X - Multi channel: Dimension IOLITE X V24-1 23/50...
  • Page 25: Iolite X - Multi Channel: Connectors

    IOLITE X TECHNICAL REFERENCE MANUAL 4.2.1.3. IOLITE X - Multi channel: Connectors 4.2.1.3.1. IOLITE X - Multi channel: PWR IN Name Description Chassis Connected to chassis PWR- PWR + Connector (on the device): 2x3 OMNIMATE SC 3.81/03/180 Mating Connectors (for the cable): Power in connector: pin-out (two 3-pin connectors) 2x3 OMNIMATE BCF 3.81/03/180;...
  • Page 26: Out (Data, Sync, Pwr)

    IOLITE X TECHNICAL REFERENCE MANUAL 4.2.1.3.3. OUT (Data, Sync, PWR) Name Description P1_p Pair 1 + P1_n Pair 1 - P2_p Pair 2 + P2_n Pair 2 - P3_p Pair 3 + P3_n Pair 3 - P4_p Pair 4 + OUT connector: pin-out (RJ45 female) P4_n Pair 4 -...
  • Page 27: Module Overview

    IOLITE X TECHNICAL REFERENCE MANUAL 5. Module Overview 5.1. VOLTAGE MEASUREMENT The IOLITE X product family includes two types of low voltage (LV) modules: 8-ch module with excitation and 16-ch module. Below is the list of LV products: IOLITE X 16xLV ●...
  • Page 28: Iolite X 16Xlv: Specifications

    IOLITE X TECHNICAL REFERENCE MANUAL 5.1.2.1. IOLITE X 16xLV: Specifications Analog input IOLITE X 16xLV Input type Voltage Number of channels 16 24-bit delta-sigma with anti-aliasing filter (-3 dB @ 160 ADC Type kHz) Butterworth 2nd order Sampling Rates Simultaneous up to 100 kS/s Voltage mode Voltage ranges ±200 V...
  • Page 29: Iolite X 16Xlv: Connectors

    IOLITE X TECHNICAL REFERENCE MANUAL Modular IOLITE X 16xLV Terminal block 9 pole Input Connectors OMNIMATE SL 2.50 / BLF 2.50/180 9 - 57 V DC, Power over Ethernet: 48 - 57 V DC Power supply (PoE++ power delivery) 250 V functional isolation Isolation Voltage (channel to power supply ground) TB @Typ.
  • Page 30: Iolite X 16Xlv: T2A9F Connector: Wiring Diagram

    IOLITE X TECHNICAL REFERENCE MANUAL IOLITE 16xLV: T2A2f Power OUT Connector: Pinout Connector (on the device): OMNIMATE Signal SL 2.50/02/90G Mating connector (for the cable): OMNIMATE Signal BLF 2.50/02/180 PWR OUT pins are intended to supply external loads. Do not connect the external power supply to the PWR OUT pins! It can damage the equipment.
  • Page 31: Iolite X 8Xlve

    IOLITE X TECHNICAL REFERENCE MANUAL 5.1.3. IOLITE X 8xLVe The 8-channel low voltage module comes with unipolar excitation in the range between 2 V and 24 V. IOLITE X 8xLVe module comes with either DSUB-37 or terminal block connectors for analog input. IOLITE X 8xLVe TB IOLITE X 8xLVe D37f IOLITE X V24-1...
  • Page 32: Iolite X 8Xlve: Specifications

    IOLITE X TECHNICAL REFERENCE MANUAL 5.1.3.1. IOLITE X 8xLVe: Specifications Inputs IOLITE X 8xLVe Input types Voltage, Potentiometer, Current (Ext. shunt) Number of channels 8 24-bit delta-sigma with anti-aliasing filter (-3 dB @ 160 kHz) ADC Type Butterworth 2nd order Sampling Rate Simultaneous up to 200 kS/s Voltage Mode Ranges...
  • Page 33 IOLITE X TECHNICAL REFERENCE MANUAL Current limit 2.8 W max. power per channel, 22.4 W per slice Excitation accuracy 0.05 % ± 2 mV Drift ±20 ppm/K ± 60 μV/K Stability 10 % to 90 % load < 0.06 @ 5 V exc (< 0.01 @ 24 V exc) Noise @ 10 V / 350 Ω...
  • Page 34: Iolite X 8Xlve: Connectors

    IOLITE X TECHNICAL REFERENCE MANUAL 5.1.3.2. IOLITE X 8xLVe: Connectors 5.1.3.2.1. IOLITE X 8xLVe: DSUB Connector: Pinout IOLITE X 8xLVe D37f connector: Pin-out IOLITE X V24-1 33/50...
  • Page 35: Iolite X 8Xlve: Dsub Connector: Wiring Diagram

    IOLITE X TECHNICAL REFERENCE MANUAL 5.1.3.2.2. IOLITE X 8xLVe: DSUB Connector: Wiring diagram Voltage Current Potentiometer IOLITE X V24-1 34/50...
  • Page 36: Iolite X 8Xlve: T2A9F Connector: Pinout

    IOLITE X TECHNICAL REFERENCE MANUAL 5.1.3.2.3. IOLITE X 8xLVe: T2A9f Connector: Pinout Name Description IN + Input+ IN - Input- SNS + Sense+ SNS - Sense- EXC + Excitation+ EXC - Excitation- Ground TEDS TEDS Analog in connector: pin-out (terminal block male) AI connector (on the device): OMNIMATE Signal SL 2.50/09/90G Mating connector (for the cable): OMNIMATE Signal BLF 2.50/09/180 IOLITE X V24-1...
  • Page 37: Iolite X 8Xlve: T2A9F Connector: Wiring Diagram

    IOLITE X TECHNICAL REFERENCE MANUAL 5.1.3.2.4. IOLITE X 8xLVe: T2A9f Connector: Wiring diagram Voltage Current Potentiometer IOLITE X V24-1 36/50...
  • Page 38: Strain And Stress Measurement

    ● 5.2.1. IOLITE X 8xSTGS IOLITE X 8xSTGS is an 8-channel module dedicated for strain measurement supporting inputs for Full, Half and Quarter bridge configuration. STGS module is available with terminal block input connectors and optionally with D-SUB37 input connectors.
  • Page 39: Iolite X 8Xstgs: Connectors

    IOLITE X TECHNICAL REFERENCE MANUAL 5.2.1.2. IOLITE X 8xSTGS: Connectors 5.2.1.2.1. IOLITE X 8xSTGS: T2A9f Connector: Pinout Name Description IN + Input+ IN - Input- SNS + Sense+ SNS - Sense- EXC + Excitation+ EXC - Excitation- iGND Ground ¼ Bridge / Shunt...
  • Page 40: Iolite X 8Xstgs: D-Sub37 Connector: Pinout

    IOLITE X TECHNICAL REFERENCE MANUAL 5.2.1.2.3. IOLITE X 8xSTGS: D-SUB37 Connector: Pinout Warning PWR OUT pins are intended to supply external loads. Do not connect the external power supply to the PWR OUT pins! It can damage the equipment. Incorrect connection can damage the equipment or cause data loss. The connection of PWR...
  • Page 41: Vibration And Sound Measurement

    IOLITE X TECHNICAL REFERENCE MANUAL 5.3. VIBRATION AND SOUND MEASUREMENT The IOLITE X product family includes solutions for vibration and sound measurement with: IOLITE X 8xACC ● Together with our software these modules are also a good choice for machine condition monitoring solutions for rotating machinery.
  • Page 42: Iolite X 8Xacc: Specifications

    IOLITE X TECHNICAL REFERENCE MANUAL 5.3.1.1. IOLITE X 8xACC: Specifications Analog inputs IOLITE X 8xACC Input type Voltage, IEPE Number of channels 8 24-bit delta-sigma with anti-aliasing filter (-3 dB @ 160 kHz) ADC Type Butterworth 2nd order Sampling Rate Simultaneous 200 kS/sec per channel (software-selectable) Voltage Mode Voltage Ranges ±10 V...
  • Page 43: Iolite X 8Xacc: Connectors

    IOLITE X TECHNICAL REFERENCE MANUAL Excitation accuracy 10% Compliance voltage 24 V Output Impedance >60 kΩ Sensor detection Shortcut: <4 V; Open: >19 V Additional Specifications Modular IOLITE X 8xACC Input connector BNC Isolation voltage 250 Vpeak channel to ground TEDs support IEPE mode only (class 1) 9 - 57 V DC, Power over Ethernet: 48 - 57 V DC Power supply...
  • Page 44: Iolite X 8Xacc: Bnc Connector: Wiring Diagram

    IOLITE X TECHNICAL REFERENCE MANUAL 5.3.1.2.2. IOLITE X 8xACC: BNC Connector: Wiring diagram Voltage IEPE IOLITE X V24-1 43/50...
  • Page 45: Iolite X Accessories

    7.2. Support Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties regarding the system. For any support please contact your local distributor first or Dewesoft directly.
  • Page 46: Service/Repair

    When used in text representing the company, product or technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ® sign is not used in the visual representation of the triangle logo.
  • Page 47: General Safety Instructions

    Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the product. Dewesoft d.o.o. assumes no liability for the customer’s failure to comply with these requirements.
  • Page 48 REMOVE POWER and do not use the product until the safe operation can be verified by service-trained personnel. If necessary, return the product to Dewesoft sales and service office for service and repair to ensure that safety features are maintained.
  • Page 49 IOLITE X TECHNICAL REFERENCE MANUAL DO NOT use the system before, during or shortly after a thunderstorm (risk of lightning and high ● energy over-voltage). An advanced range of application under certain conditions is allowed with therefore designed products only. For details please refer to the specifications. Make sure that your hands, shoes, clothes, the floor, the system or measuring leads, integrated ●...
  • Page 50: Documentation Version History

    IOLITE X TECHNICAL REFERENCE MANUAL Fire-alarm and safety-alarm systems, intended for the protection of buildings, are excluded from the scope of IEC 61326-3-1. 8.3. Documentation version history Version Date Notes V24-1 13.4.2024 Initial version - Product line release IOLITE X V24-1 49/50...
