DEWESOFT KRYPTON V25-1 Technical Reference Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KRYPTON®
TECHNICAL REFERENCE MANUAL
KRYPTON V25-1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KRYPTON V25-1 and is the answer not in the manual?

Questions and answers

Related Manuals for DEWESOFT KRYPTON V25-1

Summary of Contents for DEWESOFT KRYPTON V25-1

  • Page 1 KRYPTON® TECHNICAL REFERENCE MANUAL KRYPTON V25-1...

  • Page 2: Table Of Contents

    KRYPTON® TECHNICAL REFERENCE MANUAL 1. Table of Contents 1. Table of Contents 2. About this document 2.1. Legend 2.2. Online versions 2.2.1. KRYPTON® Technical Reference Manual 2.2.2. DewesoftX® User Manual 3. Getting started 3.1. Software installation 3.2. Connecting KRYPTON 3.2.1. DewesoftX® Settings for KRYPTON 3.2.2.
  • Page 3 KRYPTON® TECHNICAL REFERENCE MANUAL 5.2.1.1. KRYPTONi-8xLV-100V-L1T2m 5.2.1.2. KRYPTONi-4xLV, KRYPTONi-8xLV: Specifications 5.2.1.3. KRYPTONi-4xLV, KRYPTONi-8xLV: BNC connector: Pinout 5.2.1.4. KRYPTONi-8xLV-100V-L1T2m: LEMO connector: Pinout 5.2.1.5. KRYPTONi-4xLV, KRYPTONi-8xLV: Wiring diagrams 5.2.2. KRYPTONi-1xLV 5.2.2.1. KRYPTONi-1xLV: Specifications 5.2.2.2. KRYPTONi-1xLV: BNC connector: Pinout 5.2.2.3. KRYPTONi-1xLV: Wiring diagrams 5.2.3.
  • Page 4 KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.3.1.1. KRYPTONi-8xTH, KRYPTONi-16xTH: Specifications: Accuracy table 5.5.3.2. KRYPTONi-8xTH, KRYPTONi-16xTH: Thermocouple connector: Pinout 5.5.3.3. KRYPTONi-8xTH, KRYPTONi-16xTH: Wiring diagrams 5.5.4. KRYPTONi-8xTH-HS, KRYPTONi-16xTH-HS 5.5.4.1. KRYPTONi-8xTH-HS, KRYPTONi-16xTH-HS: Specifications 5.5.4.1.1. KRYPTONi-8xTH-HS, KRYPTONi-16xTH-HS: Specifications: Accuracy table 5.5.4.2. KRYPTONi-8xTH-HS, KRYPTONi-16xTH-HS: Thermocouple connector: Pinout 5.5.4.3.
  • Page 5 KRYPTON® TECHNICAL REFERENCE MANUAL 5.9.1. KRYPTONi-2xCAN-USB 5.9.1.1. KRYPTONi-2xCAN-USB: Specifications 5.9.3. KRYPTONi-2xCAN-USB: DSUB Connectors: Pinout 5.9.2. KRYPTONi-1xCAN, KRYPTONi-1xCAN-FD 5.9.2.1. KRYPTONi-1xCAN, KRYPTONi-1xCAN-FD: Specifications 5.9.2.2. KRYPTONi-1xCAN, KRYPTONi-1xCAN-FD: DSUB Connector: Pinout 6. KRYPTON CPU 6.1. KRYPTON CPU: Specifications 6.2. KRYPTON CPU: Dimensions 6.3. KRYPTON CPU: Connectors 6.3.1.

  • Page 6: About This Document

    ● Technical data ● Only Dewesoft Version X2-SP4 or higher support KRYPTON. Only Dewesoft Version X3-SP1 or higher support KRYPTON One. 2.1. Legend The following symbols and formats will be used throughout the document. Important Gives you important information about a subject.

  • Page 7: Online Versions

    2.2. Online versions 2.2.1. KRYPTON® Technical Reference Manual The most recent version of this manual can be downloaded from our homepage: https://download.dewesoft.com/list/manuals-brochures/hardware-manuals In the Hardware Manuals section click the download link for the KRYPTON® technical reference manual. 2.2.2. DewesoftX® User Manual The DewesoftX®...

  • Page 8: Getting Started

    KRYPTON® TECHNICAL REFERENCE MANUAL 3. Getting started This chapter will help you to install the software, connect your KRYPTON system to the PC via EtherCAT, and will show you how to configure DewesoftX®. To follow these steps, you need the following items: your brand new KRYPTON system (included in the shipment) ●...

  • Page 9: Dewesoftx® Settings For Krypton

    KRYPTON® TECHNICAL REFERENCE MANUAL Connection of KRYPTON device to PC 3.2.1. DewesoftX® Settings for KRYPTON The connected device will show up in DewesoftX® settings. Click on the Options button at the top right, and then on the Settings item in the pop-up to open the DewesoftX® settings dialogue. DewesoftX®...

  • Page 10: Channel Setup Krypton

    KRYPTON® TECHNICAL REFERENCE MANUAL 3.2.2. Channel setup KRYPTON When DewesoftX® has started up, you will be in Measure mode and see the Setup files list or you can ❶ create a New setup . Click on Ch. setup (on the right of Setup files) to switch to the Channel setup mode ❷.

  • Page 11: Simple Measurement

    KRYPTON® TECHNICAL REFERENCE MANUAL 3.3. Simple Measurement This chapter describes measurement basics, how to configure KRYPTON and gives some details on the measurement setup. 3.3.1. Help - manual Note that this document is just a quick start guide. For detailed information about DewesoftX® consult ❶...

  • Page 12: Sample Rate

    KRYPTON® TECHNICAL REFERENCE MANUAL Channel setup screen 3.3.3. Sample rate One of the most important settings is the sample rate. The sample rate defines how many data points KRYPTON will transfer to the DewesoftX®. Higher sample rate also means that more data needs to be transferred via EtherCAT to your computer.

  • Page 13: Measurement Mode

    KRYPTON® TECHNICAL REFERENCE MANUAL 3.3.4. Measurement Mode A click on Measure (at the right side of Ch. setup option) will take you to the Recorder screen measure mode where you can already see live data. Important When switching to Measure mode the data will not be stored automatically. Measure mode ❺...

  • Page 14: Analyze Mode

    KRYPTON® TECHNICAL REFERENCE MANUAL 3.3.5. Analyze Mode When you have just stopped a measurement and switched to Analyze mode, DewesoftX® will automatically open the last recorded data file in Review mode, so that you can start the analysis right away. Analyze mode The Review mode is much like the measurement mode.

  • Page 15: Advanced Configuration

    KRYPTON® TECHNICAL REFERENCE MANUAL 3.4. Advanced configuration Note, that the Dewesoft’s launcher has already done the hardware setup for you – you can check this in ❶ ❷ the Settings dialogue. Click the Options button – and then click the Settings menu item Open settings dialogue The settings window will appear where all the currently connected devices will be seen.

  • Page 16: Firmware Upgrade

    As the file is zipped, you need to first unzipped it and then copied it into the Firmwares folder of ● your DewesoftX® installation (e.g. D:\DewesoftX\System\Firmwares). Connect the Dewesoft instrument to the PC and run DewesoftX®. ● Go to settings under the Update tab: ●...

  • Page 17: Licensing

    KRYPTON® TECHNICAL REFERENCE MANUAL 3.6. Licensing KRYPTON or any other Dewesoft device already comes with an embedded Dewesoft license. You can ❶ check the license details with all the available options in the Licensing tab by pressing the three ❻...

  • Page 18: Troubleshooting

    Make sure to connect the data-cable directly to the Ethernet card of your PC. Do not use any ● switches or hubs If the computer is still having trouble recognizing the Dewesoft EtherCAT devices, here are some additional steps: Check if there is an Ethercat DAQ Filter driver installed on your computer as shown in the picture ●...
  • Page 19 KRYPTON® TECHNICAL REFERENCE MANUAL If the driver is not installed, it can be downloaded from our page. If the driver is already installed and the devices are still not recognized, the Speed & Duplex of the ● network card needs to be adjusted manually. Go to network connections ○...

  • Page 20: System Overview

    KRYPTON® TECHNICAL REFERENCE MANUAL 4. System overview KRYPTON® Rugged and distributed EtherCAT data acquisition system for field measurement in extreme and harsh environments. KRYPTON DAQ systems offer IP67 degree of protection and can operate in the extreme temperature range from -40 °C to +85 °C and offer high shock protection. Voltage Strain / Stress Quarter Bridge...

  • Page 21: Main Features

    KRYPTON® TECHNICAL REFERENCE MANUAL 4.1. Main features DISTRIBUTED DAQ: KRYPTON DAQ modules were designed for distributed measurements to bring data acquisition closer to sensors. This introduces many advantages as opposed to traditional DAQ systems. KRYPTON allows distributing DAQ units down to a single channel. ETHERCAT DAQ: EtherCAT protocol with 100 Mbit/s bus speed is used for data transmission, data synchronization, and power supply.

  • Page 22: Small And Flexible Data Acquisition

    KRYPTON takes the opposite approach. We kept the same advantages of other Dewesoft DAQ devices like plug and play and sensor auto-detection), but with KRYPTON we are bringing data acquisition systems closer to the origin of data - near the sensors.

  • Page 23: High-End Signal Conditioning

    KRYPTON® TECHNICAL REFERENCE MANUAL 4.1.4. High-end signal conditioning KRYPTON is not just small and rugged but also has quality analog amplifiers for precise signal measurement. An array of different modules are available for almost any sensor: STG: Universal differential voltage and Full / Half / ●...

  • Page 24: Krypton One - Single Channel Data Acquisition

    KRYPTON ONE data acquisition modules are completely compatible with every other KRYPTON, SIRIUS and other data acquisition systems from Dewesoft. KRYPTONi-1xACC Main characteristics of KRYPTON ONE modules: The fastest KRYPTON: single-channel architecture allows a maximum sample rate of 40 kS/s.

  • Page 25: General Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL 4.2. General specifications Interface Data interface EtherCAT® Data Rate 100 Mbps Full Duplex bus speed Max. Throughput per Chain From 6 MB/s to 10 MB/s (see 1) Sync Accuracy below 1 sample to Sirius® EtherCAT® Max. Cable Length 100 m Max.

  • Page 26: Module Overview

    KRYPTON takes the opposite approach. We kept the same advantages of other Dewesoft DAQ devices (plug and play, sensor auto-detection), but we are bringing DAQ units closer to the origin of data, near the sensors. That greatly reduces the cost of the sensor cabling, chances of wiring errors and greatly improves the signal quality.

  • Page 27: Technical Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.1. Technical specifications 5.1.1. KRYPTON Multichannel TH-HS Connectors DB9, L2B10f Thermocou Thermocou L0B6f DB25 L1T7f #ch per 3x, 6x 8x, 16x 8x, 16x 4x, 8x 4x, 8x 16xDI, 4xCNT module 16xDO 8xDI, 8xDO Data rate / 20 kS/s 100 S/s 100 S/s,...

  • Page 28: Krypton Single Width

    KRYPTON® TECHNICAL REFERENCE MANUAL LVDT DSI-LVDT ✗ ✗ ✗ ✗ ✗ ✗ ✗ ✗ Charge DSI-CHG ✗ ✗ ✗ ✗ ✗ ✗ ✗ ✗ TEDS ✓ ✗ ✗ ✗ ✓ ✗ ✗ ✗ ✗ Isolation Differential 1000 V 1000 V 1000 V Differential 1000 V...

  • Page 29: Krypton Dual Width

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.1.1.2. KRYPTON dual width Dimensions : KRYPTON dual KRYPTON® V25-1 29/147...

  • Page 30: Krypton One

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.1.2. KRYPTON ONE TH-HV K-type Thermocou DSUB15HD DSUB15HD Banana ple LEMO LEMO T-type Connector Male Female jack REDEL 7 pin female Number of channels per module Data rate per channel 40 kS/s 40 kS/s 40 kS/s 40 kS/s 40 kS/s 100 S/s...

  • Page 31: Krypton One Form Factor

    KRYPTON® TECHNICAL REFERENCE MANUAL CAT III CAT III 600 Galvanic Galvanic 125 Vrms 125 Vrms 125 Vrms 600 V isolation isolation Isolation Isolation Isolation CAT II CAT II 1000 Isolation None CH, GND CH, GND CH, GND CH, GND CH, GND 1000 V None Power...

  • Page 32: General Connection Diagrams

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.1.3. General connection diagrams In illustration below “Typical connection diagrams” parts of the measurement chain are shown: Amplifier ● Connections ● Sensor ● Typical connection diagrams KRYPTON® V25-1 32/147...

  • Page 33: Voltage Measurement

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.2. VOLTAGE MEASUREMENT KRYPTON product family includes three types of low voltage (LV) modules and one type of high voltage (HV) modules. KRYPTON LV modules are rugged isolated DAQ devices for low voltage measurements. Below is the list of the products: KRYPTONi-8xLV, ●...

  • Page 34: Kryptoni-4Xlv, Kryptoni-8Xlv: Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.2.1.2. KRYPTONi-4xLV, KRYPTONi-8xLV: Specifications Analog input KRYPTONi-4xLV KRYPTONi-8xLV Input type Isolated voltage Isolated voltage Number of channels 4 ADC Type 24-bit oversampled SAR with 41 kHz 24-bit oversampled SAR with 41 kHz anti-aliasing filter anti-aliasing filter Sampling Rates Simultaneous 20k, 10k, 5k, 2k, 1k, 500, 200, Simultaneous 20k, 10k, 5k, 2k, 1k, 500, 200, 100 S/s (software-selectable)

  • Page 35: Kryptoni-4Xlv, Kryptoni-8Xlv: Bnc Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Environmental IP Rating (see 1) IP67 IP67 Physical Weight 700 g 1000 g Slice Dimensions 213 x 39 x 56 mm 213 x 54 x 56 mm Dimensions with Connectors 213 x 39 x 66.8 mm 213 x 54 x 66.8 mm 1) Depending on the mating connector types 2) Upon request...

  • Page 36: Kryptoni-4Xlv, Kryptoni-8Xlv: Wiring Diagrams

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.2.1.5. KRYPTONi-4xLV, KRYPTONi-8xLV: Wiring diagrams Voltage KRYPTON® V25-1 36/147...

  • Page 37: Kryptoni-1Xlv

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.2.2. KRYPTONi-1xLV KRYPTONi-1xLV is a single channel low voltage module with BNC connector. KRYPTONi-1xLV 5.2.2.1. KRYPTONi-1xLV: Specifications Analog input Input types Voltage Number of channels ADC Type 24-bit SAR with anti-aliasing filter Sampling Rate Simultaneous 40 kS/s per channel (software-selectable) Voltage Ranges ±50 V ±10 V...

  • Page 38: Kryptoni-1Xlv: Bnc Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Isolation 125 Vrms channel to ground isolation Power Power Supply 9 - 48 V DC Power consumption 1.5 W (typ.) Physical Dimensions 62 x 56 x 29 mm Weight 250 g 5.2.2.2. KRYPTONi-1xLV: BNC connector: Pinout Name Description Analog Input +...

  • Page 39: Kryptoni-1Xhv

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.2.3. KRYPTONi-1xHV KRYPTONi-1xHV has two banana front connectors for single channel high voltage measurement. KRYPTONi-1xHV 5.2.3.1. KRYPTONi-1xHV: Specifications Analog Input Input types Voltage Number of channels ADC Type 24-bit SAR with anti-aliasing filter Sampling Rate 40 kS/s (software-selectable) Input range ±1000 V Input accuracy...

  • Page 40: Kryptoni-1Xhv: Banana Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Alias Rejection -100 dB (all sample rates) Delay Through ADC 37 / fs Oversampling Additional specifications Input connector 4 mm safety banana jack Power Power Supply 9 - 48 V DC Power consumption 1 W (typ.) Environmental IP rating IP65 / IP67 (see 1)

  • Page 41: Current Measurement

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.3. CURRENT MEASUREMENT KRYPTON LA modules are rugged isolated DAQ devices for low amperage measurements. Currently, KRYPTONi-8xLA is available. 5.3.1. KRYPTONi-8xLA KRYPTONi-8xLA has 8 BNC input connectors for current measurement. KRYPTONi-8xLA 5.3.1.1. KRYPTONi-8xLA: Specifications Analog input KRYPTONi-8xLA Input type Isolated current...

  • Page 42: Kryptoni-8Xla: Bnc Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Delay Through ADC 37 / fs Oversampling Additional Specifications Input Connector Isolation Voltage 1000 Vpeak channel/ground & channel/channel Power Power Supply 9 - 48 V DC Power Consumption 6.8 W Environmental IP Rating (see 1) IP67 Physical Weight 1000 g...

  • Page 43: Strain And Stress Measurement

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.4. STRAIN AND STRESS MEASUREMENT KRYPTON STG modules have universal differential voltage and Full / Half / Quarter bridge input. STG modules are available in 1, 3 and 6 channel configurations and are compatible with DSI adapters: KRYPTON-3xSTG, KRYPTON-3xSTG-L2B10f, ●...

  • Page 44: Krypton-3Xstg, 6Xstg: Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL KRYPTON-3xSTG-L2B10f module has 3 LEMO L2B10f connectors for voltage or strain measurement. KRYPTON-3xSTG-L2B10f KRYPTON-6xSTG-L1T7f module has 6 LEMO L1T7f connectors for voltage or strain measurement. KRYPTON-6xSTG-L1T7f 5.4.1.1. KRYPTON-3xSTG, 6xSTG: Specifications Analog inputs KRYPTON-3xSTG Voltage Input type Full / half / quarter strain Number of channels 3 ADC Type 24-bit oversampled SAR with 41 kHz anti-aliasing filter...
  • Page 45 KRYPTON® TECHNICAL REFERENCE MANUAL Gain Drift Typical 10 ppm/K (max. 40 ppm/K) Offset Drift Typical 0.3 μV/K + 5 ppm of range/K, max 2 μV/K + 10 ppm of range/K Gain Linearity < 0.02 % Input Coupling DC Input Impedance 10 MΩ Overvoltage Protection In+ to In-: 50 V continuous, 200 V peak (10 ms) Analog input performance Bandwidth (-3 dB) 0.49 fs...
  • Page 46 KRYPTON® TECHNICAL REFERENCE MANUAL Analog inputs KRYPTON-6xSTG Voltage Input type Full / half / quarter strain Number of channels 6 ADC Type 24-bit oversampled SAR with 41 kHz anti-aliasing filter Sampling Rate Simultaneous 20k, 10k, 5k, 2k, 1k, 500, 200, 100 S/s (software-selectable) Voltage Mode Ranges ±10 V...

  • Page 47: Krypton-3Xstg, 6Xstg: Connectors

    KRYPTON® TECHNICAL REFERENCE MANUAL Internal Shunt Resistor 100 kΩ (others on request) Shunt Resistor Accuracy 0.1 %; TCR: 10 ppm/K (others on request) Input Short, Sensor Offset Adjust Software-selectable Additional Specifications Input connector DB9; L1T7f; L2B10f TEDs support Standard + DSI adapters Power Consumption 5.9 W (8.9 W load 120 Ω...

  • Page 48: Krypton-3Xstg, 6Xstg Connector: Lemo L1T7F Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL TEDS TEDS ¼ Bridge / Shunt Not connected SNS- Sense- EXC- Excitation- SNS+ Sense+ EXC+ Excitation + STG-L2B10f connector: pinout (10-pin LEMO female) Ground Connector type: EEG.2B.310.CLN Input- Mating connector: FGG.2B.310.CLAD72 Input + 5.4.1.2.3. KRYPTON-3xSTG, 6xSTG Connector: LEMO L1T7f Connector: Pinout Name Description Input +...

  • Page 49: Krypton-3Xstg, 6Xstg: Wiring Diagrams

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.4.1.3. KRYPTON-3xSTG, 6xSTG: Wiring diagrams 5.4.1.3.1. KRYPTON-3xSTG, 6xSTG: DSUB Connector: Wiring diagrams Voltage Single ended Differential Use only when sensor Output (+) and Output (-) are referenced to Gnd. Gnd must be connected. Bridge Full-bridge Half-bridge KRYPTON®...
  • Page 50 KRYPTON® TECHNICAL REFERENCE MANUAL Quarter-bridge KRYPTON® V25-1 50/147...
  • Page 51 KRYPTON® TECHNICAL REFERENCE MANUAL Current External direct shunt External loop powered shunt Potentiometer KRYPTON® V25-1 51/147...

  • Page 52: Krypton-3Xstg, 6Xstg: Lemo L2B10F Connector: Wiring Diagrams

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.4.1.3.2. KRYPTON-3xSTG, 6xSTG: LEMO L2B10f Connector: Wiring diagrams Voltage Bridge Full-bridge Half-bridge Quarter-bridge KRYPTON® V25-1 52/147...
  • Page 53 KRYPTON® TECHNICAL REFERENCE MANUAL Current External direct shunt External loop powered shunt Potentiometer KRYPTON® V25-1 53/147...

  • Page 54: Krypton-3Xstg, 6Xstg: Lemo L1T7F Connector: Wiring Diagrams

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.4.1.3.3. KRYPTON-3xSTG, 6xSTG: LEMO L1T7f Connector: Wiring diagrams Voltage Bridge Full-bridge Half-bridge Quarter-bridge KRYPTON® V25-1 54/147...

  • Page 55: Kryptoni-1Xstg

    KRYPTON® TECHNICAL REFERENCE MANUAL Current External direct shunt External loop powered shunt Potentiometer 5.4.2. KRYPTONi-1xSTG KRYPTONi-1xSTG is the world’s only single channel perfect strain gauge DAQ device. KRYPTONi-1xSTG is isolated and includes an internal shunt for two current input ranges (20 mA, 2 mA). KRYPTON-1xSTG module has one DSUB-9 female connector for voltage or strain measurement.

  • Page 56: Kryptoni-1Xstg: Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.4.2.1. KRYPTONi-1xSTG: Specifications Analog input Input types Voltage, current, full bridge strain, half bridge strain, quarter bridge strain Number of channels 1 ADC Type 24-bit SAR with anti-aliasing filter Sampling Rate Simultaneous 40 kS/s per channel (software-selectable) Voltage Mode Ranges ±50 V...

  • Page 57: Kryptoni-1Xstg: Dsub Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Bridge ranges 2…1000 mV/V free programmable Internal Bridge Completion ½ bridge and ¼ bridge 120 and 350 Ω Bridge Completion Accuracy 0.05 %; TCR: 2 ppm/K (others on request) Internal Shunt Resistor 100 kΩ (others on request) Shunt Resistor Accuracy 0.1 %;...

  • Page 58: Kryptoni-1Xstg: Wiring Diagrams

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.4.2.3. KRYPTONi-1xSTG: Wiring diagrams Voltage Single ended Differential Use only when sensor Output (+) and Output (-) are referenced to Gnd. Gnd must be connected. Bridge Full-bridge Half-bridge Quarter-bridge KRYPTON® V25-1 58/147...
  • Page 59 KRYPTON® TECHNICAL REFERENCE MANUAL Current External direct shunt External loop powered shunt Internal shunt This feature is limited only to KRYPTONi-1xSTG. Potentiometer KRYPTON® V25-1 59/147...

  • Page 60: Temperature Measurement

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5. TEMPERATURE MEASUREMENT KRYPTON TH and KRYPTON TH-HS modules are isolated rugged DAQ devices for temperature measurements using thermocouples. Below is the list of the products: KRYPTONi-8xRTD, ● KRYPTONi-8xTH, KRYPTONi-8xTH-HS, ● KRYPTONi-16xTH, KRYPTONi-16xTH-HS, ● KRYPTONi-1xTH-HV. ● 5.5.1.

  • Page 61: Kryptoni-8Xrtd: Lemo Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Accuracy ±0.05 % of reading ±0.2 °C Temperature Drift typ. ±5 ppm/K (max. ±12 ppm/K ±0.003 °C/K) Input Connection 3 wire or 4 wire Resistance mode Ranges 0…10 kΩ 0…1 kΩ Accuracy ±0.02 % of reading ±0.01 % of range Input Connection 3 wire or 4 wire Additional Specifications Input connector Lemo 0B 6pin EEA.0B.306.CLN...

  • Page 62: Kryptoni-8Xrtd: Wiring Diagrams

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.1.3. KRYPTONi-8xRTD: Wiring diagrams Voltage Resistance Temperature 3-wire 4-wire KRYPTON® V25-1 62/147...

  • Page 63: Kryptoni-8Xrtd-Hs

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.2. KRYPTONi-8xRTD-HS KRYPTONi-8xRTD module with 6-pin LEMO input connectors is used for measurements with universal platinum thermometer probes, thermistors, as well as for resistance and voltage measurements. KRYPTONi-8xRTD 5.5.2.1. KRYPTONi-8xRTD-HS: Specifications Analog inputs KRYPTONi-8xRTD-HS Input types Voltage, Resistance or Universal PTxxx inputs Number of channels ADC Type...

  • Page 64: Kryptoni-8Xrtd-Hs: Lemo Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Input Connection 3-wire or 4-wire Additional Specifications Input connector Lemo 0B 6pin EEA.0B.306.CLN Isolation voltage 1000 Vpeak channel/ground & channel/channel Power Power Supply 9 - 48 V DC Power consumption Typ. 3.5 W (Max. 4.7 W) Environmental IP rating (see 1) IP65 Physical...

  • Page 65: Kryptoni-8Xrtd-Hs: Wiring Diagrams

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.2.3. KRYPTONi-8xRTD-HS: Wiring diagrams Voltage Resistance Temperature 3-wire 4-wire KRYPTON® V25-1 65/147...

  • Page 66: Kryptoni-8Xth, Kryptoni-16Xth

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.3. KRYPTONi-8xTH, KRYPTONi-16xTH KRYPTONi-8xTH module has 8 thermocouple-connectors for temperature measurement. KRYPTONi-8xTH KRYPTONi-16xTH module has 16 thermocouple-connectors for temperature measurement. KRYPTONi-16xTH 5.5.3.1. KRYPTONi-8xTH, KRYPTONi-16xTH: Specifications Analog inputs KRYPTONi-8xTH KRYPTONi-16xTH Input type Isolated universal thermocouple and voltage Number of channels 8 ADC Type 24-bit delta-sigma Sampling rates Simultaneous 100, 80, 40, 20, 10 S/s (software selectable)

  • Page 67: Kryptoni-8Xth, Kryptoni-16Xth: Specifications: Accuracy Table

    KRYPTON® TECHNICAL REFERENCE MANUAL Accuracy ±0.02 % of reading ± 0.5 °C ± 10 μV Resolution < 0.001 °C Typical Noise 0.007 °C RMS @ Type K @ 10 S/s 0.02 °C RMS @ Type K @ 100 S/s Additional Specifications Input connector Mini Thermocouple connector (copper) Isolation voltage 1000 Vpeak channel/ground &...

  • Page 68: Kryptoni-8Xth, Kryptoni-16Xth: Thermocouple Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.3.2. KRYPTONi-8xTH, KRYPTONi-16xTH: Thermocouple connector: Pinout Name Description Input+ Input- Thermocouple connector: pinout (Mini TC) 5.5.3.3. KRYPTONi-8xTH, KRYPTONi-16xTH: Wiring diagrams Voltage Temperature T-type thermocouple S-type, R-type thermocouple KRYPTON® V25-1 68/147...
  • Page 69 KRYPTON® TECHNICAL REFERENCE MANUAL N-type thermocouple K-type thermocouple J-type thermocouple E-type thermocouple B-type thermocouple C-type thermocouple KRYPTON® V25-1 69/147...

  • Page 70: Kryptoni-8Xth-Hs, Kryptoni-16Xth-Hs

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.4. KRYPTONi-8xTH-HS, KRYPTONi-16xTH-HS KRYPTONi-8xTH-HS module has 8 thermocouple-connectors for temperature measurement. KRYPTONi-8xTH-HS KRYPTONi-16xTH-HS module has 16 thermocouple-connectors for temperature measurement. KRYPTONi-16xTH-HS 5.5.4.1. KRYPTONi-8xTH-HS, KRYPTONi-16xTH-HS: Specifications Analog inputs KRYPTONi-8xTH-HS Input type Isolated universal thermocouple and voltage Number of channels 8 ADC Type 24-bit delta-sigma Sampling rates Simultaneous 10, 20, 40, 50, 80, 100, 200, 500, 1k, 2k, 5k, 10k S/s (optional) Voltage Mode...
  • Page 71 KRYPTON® TECHNICAL REFERENCE MANUAL 0.002 °C RMS @ Type K @ 10 S/s 0.006 °C RMS @ Type K @ 100 S/s 0.02 °C RMS @ Type K @ 1 kS/s Typical Noise 0.05 °C RMS @ Type K @ 10 kS/s Additional Specifications Input connector Mini Thermocouple connector (copper) Isolation voltage 1000 Vpeak channel/ground &...

  • Page 72: Kryptoni-8Xth-Hs, Kryptoni-16Xth-Hs: Specifications: Accuracy Table

    KRYPTON® TECHNICAL REFERENCE MANUAL Power Power Supply 9 - 48 V DC Power consumption Typ. 4.3 W (Max. 5 W) Environmental IP rating IP67 Physical Weight 1060 g Dimensions 213 x 54 x 56 mm 5.5.4.1.1. KRYPTONi-8xTH-HS, KRYPTONi-16xTH-HS: Specifications: Accuracy table Temperature Type K Type J Type T...

  • Page 73: Kryptoni-8Xth-Hs, Kryptoni-16Xth-Hs: Thermocouple Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.4.2. KRYPTONi-8xTH-HS, KRYPTONi-16xTH-HS: Thermocouple connector: Pinout Name Description Input + Input - Thermocouple connector: pinout (Mini TC) 5.5.4.3. KRYPTONi-8xTH-HS, KRYPTONi-16xTH-HS: Wiring diagrams Voltage Temperature T-type thermocouple S-type, R-type thermocouple KRYPTON® V25-1 73/147...
  • Page 74 KRYPTON® TECHNICAL REFERENCE MANUAL N-type thermocouple K-type thermocouple J-type thermocouple E-type thermocouple B-type thermocouple C-type thermocouple KRYPTON® V25-1 74/147...

  • Page 75: Kryptoni-1Xth-Hv

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.5. KRYPTONi-1xTH-HV KRYPTONi-1xTH-HV is a single channel isolated module with LEMO REDEL H02 input connector for thermocouple temperature measurement. KRYPTONi-1xTH-HV is a perfect solution as a thermocouple input for high voltage potential for battery measurements. KRYPTONi-1xTH-H 5.5.5.1.

  • Page 76: Kryptoni-1Xth-Hv: Specifications: Accuracy Table

    KRYPTON® TECHNICAL REFERENCE MANUAL Physical Dimensions 62 x 56 x 36 mm Weight 300 g 5.5.5.1.1. KRYPTONi-1xTH-HV: Specifications: Accuracy table Temperature Type K -200 °C 1.19 °C -100 °C 0.85 °C 0 °C 0.75 °C 100 °C 0.76 °C 400 °C 0.82 °C 700 °C 0.88 °C...

  • Page 77: Kryptoni-1Xth-Hv: Wiring Diagrams

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.5.5.3. KRYPTONi-1xTH-HV: Wiring diagrams Temperature K-type thermocouple 5.6. VIBRATION AND SOUND The ACC modules have BNC input connectors and are perfect for sound and vibration IEPE channels. Currently available: KRYPTON-8xACC, KRYPTON-4xACC, ● KRYPTONi-1xACC. ● 5.6.1. KRYPTON-4xACC, KRYPTON-8xACC KRYPTON-4xACC module has 4 BNC connectors for voltage and IEPE measurements.

  • Page 78: Krypton-4Xacc: Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL KRYPTON-8xACC module has 8 BNC connectors for voltage and IEPE measurements. Caution Inputs are single-ended, if isolation is required isolated sensors have to be used. KRYPTON-8xACC 5.6.1.1. KRYPTON-4xACC: Specifications Analog inputs KRYPTON-4xACC Input type Voltage, IEPE Number of channels 4 ADC Type 24-bit delta-sigma with anti-aliasing filter Sampling Rate Simultaneous 20 kS/s per channel (software-selectable)

  • Page 79: Krypton-8Xacc: Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL Oversampling 32 IEPE input Excitation 4 mA, 8 mA Compliance voltage 25 V Output Impedance >100 kΩ Sensor detection Shortcut: <4 V; Open: >19 V Additional Specifications Input connector BNC TEDs support IEPE mode only Power Power Supply 9 - 48 V DC Power Consumption 3 W Environemental...
  • Page 80 KRYPTON® TECHNICAL REFERENCE MANUAL Alias-free Bandwidth DC to 0.453 fs Alias Rejection -100 dB (all sample rates) Delay Through ADC 37 / fs Oversampling 32 IEPE input Excitation 4 mA, 8 mA Compliance voltage 25 V Output Impedance >100 kΩ Sensor detection Shortcut: <4 V;...

  • Page 81: Krypton-4Xacc, Krypton-8Xacc: Bnc Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.6.1.3. KRYPTON-4xACC, KRYPTON-8xACC: BNC Connector: Pinout Name Description Input + Input - ACC connector: pinout (BNC) 5.6.1.4. KRYPTON-8xACC, KRYPTON-4xACC: Wiring diagrams Voltage IEPE KRYPTON® V25-1 81/147...

  • Page 82: Kryptoni-1Xacc

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.6.2. KRYPTONi-1xACC Single channel isolated KRYPTON module with IEPE and voltage input. KRYPTONi-1xACC has a BNC connector. KRYPTONi-1xACC KRYPTON-1xACC can work with 50 kHz if it is the only one in the EtherCAT chain. This feature is useful for the microphone measurements where 50 kHz sampling rate is required.

  • Page 83: Kryptoni-1Xacc: Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.6.2.1. KRYPTONi-1xACC: Specifications Analog inputs Input types Voltage, IEPE Number of channels 1 ADC Type 24-bit SAR with anti-aliasing filter Sampling Rate Simultaneous 40 kS/s (50 kS/s while using it standalone) software-selectable Voltage Mode Voltage Ranges ±10 V ±5 V ±1 V...

  • Page 84: Kryptoni-1Xacc: Bnc Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Dimensions 62 x 56 x 29 mm Weight 250 g 1) Depending on the mating connector types 5.6.2.1. KRYPTONi-1xACC: BNC Connector: Pinout Name Description Input + Input - ACC connector: pinout (BNC) 5.6.2.3. KRYPTONi-1xACC: Wiring diagrams Voltage IEPE KRYPTON®...

  • Page 85: Analog Output (Ao)

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.7. ANALOG OUTPUT (AO) A single channel analog output module has a BNC connector and is the perfect module for output of voltage levels, or slow analog signals, e.g. calculated channels. Currently, the module available is KRYPTON-1xAO. 5.7.1.

  • Page 86: Krypton-1Xao: Bnc Connectors: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Max capacitive load (2 % overshoot) 10 nF Maximum load 500 Ω Output protection Short circuit protected Additional specifications Output connector BNC Power Power supply 9 - 48 V DC Power consumption 2 W (typ.) Environmental IP rating IP65 / IP67 (see 1) Physical Dimensions 62 x 56 x 29 mm...

  • Page 87: Digital And Counter Measurement

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.8. DIGITAL AND COUNTER MEASUREMENT KRYPTON counter modules utilize a patented technology called SUPERCOUNTER® in every of its counter/encoder inputs and in the smallest possible form. It supports counting, waveform timing, encoder, tacho, gear-tooth sensor. KRYPTON digital input/output modules are perfect choices for control applications: KRYPTON-4xCNT, KRYPTON-1xCNT, ●...

  • Page 88: Krypton-4Xcnt: Lemo L1T7F Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Power Power Supply 9 - 48 V DC Power consumption Typ 2.3 W (Max 2.7 W) Physical Dimensions 213 x 39 x 56 mm Weight 700 g 5.8.1.2. KRYPTON-4xCNT: LEMO L1T7f Connector: Pinout Name Description IN0/A Input A IN1/B Input B...

  • Page 89: Krypton-1Xcnt

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.8.2. KRYPTON-1xCNT KRYPTON-1xCNT has a LEMO 7-pin L1T7f connector. KRYPTON-1xCNT 5.8.2.1. KRYPTON-1xCNT: Specifications Counter Input type Digital Number of channels 1 Timebase 100 MHz Time base accuracy Typical: 5 ppm, Max: 20 ppm Max. bandwidth 10 MHz Input Filter 500 ns, 1 μs, 2 μs, 4 μs, 5 μs and 7.5 μs Input Level Compatibility TTL (Low: <...

  • Page 90: Krypton-1Xcnt: Lemo L1T7F Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.8.2.2. KRYPTON-1xCNT: LEMO L1T7f Connector: Pinout Name Description IN0/A Input A IN1/B Input B IN2/Z Input Z Ground CNT connector: pinout (7-pin LEMO female) +5 V 5 V supply max. current: 100 mA +12 V 12 V supply Connector type: EEG.1T.307.CLN max.

  • Page 91: Kryptoni-16Xdi, Kryptoni-16Xdo, Kryptoni-8Xdi-8Xdo

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.8.3. KRYPTONi-16xDI, KRYPTONi-16xDO, KRYPTONi-8xDI-8xDO KRYPTONi-16xDI KRYPTONi-16xDI module has 16 digital input channels: 8 on each of the two 25-pin DSUB male connectors. KRYPTONi-16xDI KRYPTONi-16xDO KRYPTONi-16xDO module has 16 digital output channels: 8 on each of the two 25-pin DSUB female connectors.

  • Page 92: Kryptoni-16Xdi, Kryptoni-16Xdo, Kryptoni-8Xdi-8Xdo: Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.8.3.1. KRYPTONi-16xDI, KRYPTONi-16xDO, KRYPTONi-8xDI-8xDO: Specifications KRYPTONi-16xDI KRYPTONi-8xDI-8xDO KRYPTONi-16xDO Digital Input Isolated Input Channels 16 Compatibility CMOS Configuration Input low level UIN < 0.8 V Input high level UIN > 2.4 V Input high current @ 5 V IIN < 1.8 mA Input high current @ 30 V IIN <...

  • Page 93: Kryptoni-16Xdi, Kryptoni-16Xdo, Kryptoni-8Xdi-8Xdo: Dsub Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.8.3.2. KRYPTONi-16xDI, KRYPTONi-16xDO, KRYPTONi-8xDI-8xDO: DSUB Connector: Pinout DIO modules are available with two different kinds of connectors, DSUB-25 and DSUB-15. Note When using the supply from the KRYPTON module (pin 9, 10 or 11 on DSUB-25) please keep in mind to connect the GND iso with GND.
  • Page 94 KRYPTON® TECHNICAL REFERENCE MANUAL 16xDI INPUT 1-8 16xDI INPUT 9-16 Name Description Name Description DI1+ Digital input CH1 + DI1+ Digital input CH9 + DI2+ Digital input CH2 + DI2+ Digital input CH10 + DI3+ Digital input CH3 + DI3+ Digital input CH11 + DI4+ Digital input CH4 +...
  • Page 95 KRYPTON® TECHNICAL REFERENCE MANUAL 16xDO OUTPUT 1-8 16xDO OUTPUT 9-16 Name Description Name Description Digital output CH1 Digital output CH9 Digital output CH2 Digital output CH10 Digital output CH3 Digital output CH11 Digital output CH4 Digital output CH12 Digital output CH5 Digital output CH13 Digital output CH6 Digital output CH14...
  • Page 96 KRYPTON® TECHNICAL REFERENCE MANUAL 8xDI 8xDO Name Description Name Description DI1+ Digital input CH1 + Digital output CH1 DI2+ Digital input CH2 + Digital output CH2 DI3+ Digital input CH3 + Digital output CH3 DI4+ Digital input CH4 + Digital output CH4 DI5+ Digital input CH5 + Digital output CH5...

  • Page 97: Kryptoni-4Xdi

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.8.4. KRYPTONi-4xDI KRYPTON ONE isolated module with 4 digital inputs and power supply on the front 15-pin DSUB male connector. KRYPTONi-4xDI 5.8.4.1. KRYPTONi-4xDI: Specifications Digital Inputs Input type Digital Number of channels 4 Compatibility TTL / CMOS Voltage Levels Input low level UIN <...

  • Page 98: Kryptoni-4Xdi: Dsub Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Power Power supply 9 - 48 V DC Power consumption 1.5 W (typ.) Physical Dimensions 62 x 56 x 29 mm Weight 250 g 1) Max. combined load on +5 V and +12 V pins: 1.5 W reduced by the load already present on +Vin pin 5.8.4.2.

  • Page 99: Kryptoni-4Xdo

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.8.5. KRYPTONi-4xDO KRYPTON ONE isolated module with 4 digital outputs and power supply on the front 15-pin DSUB female connector. Output type is an open collector with max 2 A sink current. KRYPTONi-4xDO Hint The PWM option is currently only supported on KRYPTON 4xDO devices. You can see the settings of the PWM signal in the 10.1.

  • Page 100: Kryptoni-4Xdo: Dsub Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Physical Dimensions 62 x 56 x 29 mm Weight 250 g 5.8.5.2. KRYPTONi-4xDO: DSUB Connector: Pinout Note When using the supply from the KRYPTON module ( pin 11, 12 or 15 on DSUB-15) please keep in mind to connect the GND iso with GND.

  • Page 101: Can: Controller Area Network

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.9. CAN: Controller Area Network KRYPTON CAN interfaces are intended for CAN-FD and CAN acquisition in harsh environments. KRYPTON CAN devices support OBDII, J1939 standard protocols and can output CAN messages: KRYPTONi-2xCAN-USB, ● KRYPTONi-1xCAN, KRYPTONi-1xCAN-FD. ● 5.9.1.

  • Page 102: Kryptoni-2Xcan-Usb: Dsub Connectors: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Storage temperature -40°C to +70°C 5 to 95 % RH Humidity non-condensing at 50 °C IP protection IP50 5.9.3. KRYPTONi-2xCAN-USB: DSUB Connectors: Pinout Name Description 5 V supply max. current: 500 mA CAN_LOW CAN low DGND Digital Ground Reserved Reserved...

  • Page 103: Kryptoni-1Xcan, Kryptoni-1Xcan-Fd

    KRYPTON® TECHNICAL REFERENCE MANUAL 5.9.2. KRYPTONi-1xCAN, KRYPTONi-1xCAN-FD KRYPTONi-1xCAN is a single port CAN device that uses EtherCAT as an interface. KRYPTONi-1xCAN-FD is a single port CAN-FD device that uses EtherCAT as a data interface. The CAN-FD supports high-speed CAN interface with data rates up to 8 Mbps. KRYPTONi-1xCAN-FD has galvanically isolated communication lines and an isolated sensor supply of +5 V and +12 V.

  • Page 104: Kryptoni-1Xcan, Kryptoni-1Xcan-Fd: Dsub Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL Environmental specification EtherCAT, 100 Mbit/s EtherCAT, 100 Mbit/s Lemo 1T Lemo 1T (1 cable for data, power and sync, daisy (1 cable for data, power and sync, daisy Interface chainable) chainable) Connector type DSUB-9 DSUB-9 Physical dimensions 62 x 56 x 29 mm 62 x 56 x 29 mm 200 g...

  • Page 105: Krypton Cpu

    KRYPTON® TECHNICAL REFERENCE MANUAL 6. KRYPTON CPU Small, highly portable and extremely rugged IP67 data logger for data recording in harsh environments. Main features: IP67 DEGREE OF PROTECTION: KRYPTON CPU is designed for testing in extremely harsh environments. The unit is fully waterproof, dustproof and can withstand shocks up to 100G. EXTREME OPERATING TEMPERATURE: KRYPTON CPU is able to operate in extreme temperatures ranging from -40 °C to 70 °C.

  • Page 106: Krypton Cpu: Specifications

    KRYPTON® TECHNICAL REFERENCE MANUAL 6.1. KRYPTON CPU: Specifications Computer Processor Intel® Atom™ Quad Core at 1.91 GHz Memory 4 GB Storage Non-removable 240 GB mSATA SSD Interfaces and options USB 3x USB 2.0 Ethernet 1x GLAN (Push-Pull), 1x WLAN (RP-SMA Female Jack) EtherCAT®...

  • Page 107: Krypton Cpu: Dimensions

    KRYPTON® TECHNICAL REFERENCE MANUAL 6.2. KRYPTON CPU: Dimensions Dimensions-KRYPTON CPU KRYPTON® V25-1 107/147...

  • Page 108: Krypton Cpu: Connectors

    KRYPTON® TECHNICAL REFERENCE MANUAL 6.3. KRYPTON CPU: Connectors Name Description Power In 3-pin LEMO male connector 3x USB 2.0 connector Ethernet RJ-45 connector EtherCAT 8-pin LEMO connector DVI connector WiFi RP-SMA Female WLAN antenna 6.3.1. KRYPTON CPU: Power In Connector: Pinout Name Description Supply...

  • Page 109: Krypton Accessories

    Optional KRYPTON Accessories and Sensors can be found in a separate documents depending on the functionality, which are available for download from our homepage: https://dewesoft.com/download/manuals 7.1. KRYPTON Power Supply The KRYPTON Power Supply is available as an option. You can connect the LEMO 8-pin connector of the KRYPTON Power Supply directly to the OUT connector of the KRYPTON module.

  • Page 110: Other Accessories

    7.3. Other accessories Optional KRYPTON Accessories and Sensors, such as EtherCAT accessories and others can be found in a separate documents depending on the functionality, which are available for download from our homepage: https://dewesoft.com/download/manuals 8. Hardware overview 8.1. EtherCAT connector 8.1.1. Cable...
  • Page 111 KRYPTON® TECHNICAL REFERENCE MANUAL Mating connector (for the cable): FGJ.1T.308.CLL.1433 KRYPTON® V25-1 111/147...

  • Page 112: Out Connector: Pinout

    KRYPTON® TECHNICAL REFERENCE MANUAL 8.1.3. OUT connector: Pinout OUT connector for EtherCAT is a LEMO 1T 8-pin female connector. Name Description TX_P Transmission + TX_N Transmission - RX_P Reception + RX_N Reception - PWR OUT OUT connector: pinout (8-pin LEMO female) PWR OUT Ground Ground...

  • Page 113: Leds Blinking Codes

    KRYPTON® TECHNICAL REFERENCE MANUAL 8.2. LEDs blinking codes Each KRYPTON slice has 3 green LEDs: L - D - L. The LED blinking codes adhere to the EtherCAT specification. L means Link: i.e. the In- (left L-LED) or Out-connector (right L-LED) is linked to another ●...

  • Page 114: Pre-Op State

    KRYPTON® TECHNICAL REFERENCE MANUAL When the connection to the PC is lost while the configuration was in the operation state the LED state will change: The L LED will be ON and the D LED will be slowly blinking. Lost PC connection 8.2.2.

  • Page 115: Safe-Op State

    KRYPTON® TECHNICAL REFERENCE MANUAL 8.2.3. SAFE-OP state In this state the EtherCAT master is already reading the data from the slice/s at a slow sampling rate: the D LED is slowly blinking. DewesoftX® will set the KRYPTON slice/s in the SAFE-OP state when you are in Channel Setup.

  • Page 116: Mechanical Locking Of Modules

    KRYPTON® TECHNICAL REFERENCE MANUAL 8.3. Mechanical locking of modules KRYPTON modules can easily be stacked together. The mechanical lock mechanism is on the top and bottom of each KRYPTON module. Here is a view of the bottom lock mechanism: Bottom lock mechanism ❶...

  • Page 117: Mount Krypton On Sirius R2Db, R1Db, R1B, R2B

    KRYPTON® TECHNICAL REFERENCE MANUAL 8.3.1. Mount KRYPTON on SIRIUS R2DB, R1DB, R1B, R2B It is possible to mount KRYPTON devices on modules from SIRIUS product line. Important For this connection you need a custom L1T8m-L1T8f-Xm, where the length shouldn’t be less than 0.8m.

  • Page 118: Connection Overview

    (maximum rate of data transfer), cable length between devices (power supply cable and ECAT cables) and power consumption of devices. We recommend that you calculate the Bandwidth of the system with our Dewesoft calculator, which you find on our web-page. The recommendable upper limitation for KRYPTON ECAT devices is around 6Mb/s, if you exceed the maximum bandwidth you will need additional data (ECAT or USB) lines.
  • Page 119 KRYPTON® TECHNICAL REFERENCE MANUAL All cables The following table shows the signal line coding that will be used in the following system connection examples. Device / Connector Cable Device / Connector Description EtherCAT connection from PC to the KRYPTON Ethernet RJ45 to LEMO 1T EtherCAT device.

  • Page 120: Only Ethercat Devices

    KRYPTON® TECHNICAL REFERENCE MANUAL 9.1. Only EtherCAT devices When you only use Dewesoft EtherCAT devices (KRYPTON or Sirius EtherCAT), the connection is straightforward via ECAT to ECAT cable. A system with only ECAT devices (KRYPTON ONE, KRYPTON-8xTH, SIRIUSe, and KRYPTON-CPU)

  • Page 121: Power Injector

    KRYPTON® TECHNICAL REFERENCE MANUAL 9.2. Power Injector The Power Injector box can be used to inject power to long EtherCAT measurement chains. The Power Injector box needs an external power supply and must be connected directly between the EtherCAT devices. KRYPTON®...
  • Page 122 KRYPTON® TECHNICAL REFERENCE MANUAL A system with Power Injector List of required cables: Function Dewesoft order code Power supply PS-120-L1T8m EtherCAT EtherCAT to EtherCAT: L1T8m-L1T8f, ECAT - PC connection: L1T8f-RJ45 KRYPTON® V25-1 122/147...

  • Page 123: Power Junction

    KRYPTON® TECHNICAL REFERENCE MANUAL Hint To transfer the most power, you should connect a longer ECAT cable (e.g. 50 m) before the power Injector and shorter ECAT cable (e.g. 1 m) to the next device, so the voltage drop will be on the shorter cable.

  • Page 124: Distributed System With Krypton One

    KRYPTON® TECHNICAL REFERENCE MANUAL List of required cables: Function Dewesoft order code Power supply PS-120-L1B2f EtherCAT EtherCAT to EtherCAT: L1T8m-L1T8f Ethernet RJ45-RJ45 9.4. Distributed system with KRYPTON ONE KRYPTON ONE devices can be used in a remote area from other used devices connected with a ECAT-ECAT cable up to 100 m length.

  • Page 125: Ecat Sync Junction/Ecat Gps Junction

    EtherCAT line such as IRIG-B-DC (both) or GPS PPS signal (GPS junction). Left system with Sync Junction - Right system with GPS EtherCAT junction List of required cables: Function Dewesoft order code Power supply PS-120-L1T8m EtherCAT EtherCAT to EtherCAT: L1T8m-L1T8f,...
  • Page 126 The second purpose is to synchronize data between EtherCAT data lines (e.g KRYPTON line) with USB data line (e.g. Sirius USB or DEWE-43-A). Synchronising data from USB and ECAT data lines with Sync junction List of required cables: Function Dewesoft order code Power supply KRYPTON: PS-120-L1T8m Sirius: PS-120-L1B2f EtherCAT...

  • Page 127: Connecting Sirius-R4 And Krypton Stg

    The ECAT sync junction is not required with IOLITE, SIRIUSe, R1, R2, R4, R8 or MINITAURs DAQ systems when extended with EtherCAT devices, because the sync junction is already built into the systems. Connection between SIRIUS-R4 and KRYPTON-6xSTG List of required cables: Function Dewesoft order code EtherCAT EtherCAT to EtherCAT: L1T8m-L1T8f KRYPTON® V25-1 127/147...

  • Page 128: Soft-Sync Connection

    (KRYPTON-TH or RTD device), you don't need any junction devices at all (i.e. for the slow temperature measurement synchronization is automatically done by software). Connecting KRYPTON TH and Sirius USB to PC List of required cables: Function Dewesoft order code Power supply KRYPTON: PS-120-L1T8m Sirius: PS-120-L1B2f EtherCAT...

  • Page 129: Mixed System

    - USB and EtherCAT. Take into consideration that IOLITEs has an internal sync junction for synchronization. A mixed system with a built-in sync junction List of required cables: Function Dewesoft order code Power supply PS-120-L1B2f Supply Daisy chain L1B2m-L1B2f...

  • Page 130: Two Ethercat Lines

    In this configuration, the EtherCAT chains need to be synchronized to each other, so every chain also needs a Sync junction. Connection done with two Ethernet ports List of required cables: Function Dewesoft order code PS-120-L1T8m Power supply EtherCAT to EtherCAT: L1T8m-L1T8f, Ethercat...

  • Page 131: Use The Ds-Hube7 Junction

    In this case, it is possible to use multiple chains, but the speed will be limited to the speed of a single chain. The chains will behave as one, so no additional synchronization is needed. Connection done with DS-HUBe7 List of required cables: Function Dewesoft order code PS-120-L1B2m Power supply EtherCAT to EtherCAT: L1T8m-L1T8f, Ethercat ECAT - PC connection: L1T8f-RJ45 KRYPTON®...

  • Page 132: Advanced

    The KRYPTON 4xDO module has integrated an additional option for the PWM signal output. The option is supported with the Dewesoft X3 SP5 release or newer. The PWM can be enabled in the A/D out module. Go to Settings of the digital out channel and choose the "On"...
  • Page 133 KRYPTON® TECHNICAL REFERENCE MANUAL Adjusting Duty Cycle in Measure mode For more information about enabling PWM output please visit our knowledge base. KRYPTON® V25-1 133/147...

  • Page 134: Appendix

    KRYPTON® TECHNICAL REFERENCE MANUAL 11. Appendix 11.1. Glossary and abbreviations This glossary includes explanations of some of the most important terms and abbreviations that are used in documentation. AAF or Anti Aliasing Filter in short. Bit, the basic unit of information storage, a single binary digit that is either 0 or 1. Baud (Bd) Baud is synonymous to symbols per second.
  • Page 135 A ratio in decibels is ten times the logarithm to base 10 of the ratio of two power quantities. Dewesoft Dewesoft refers to the company. DewesoftX® refers to the software suite for data acquisition, data processing, data analysis and much more.
  • Page 136 KRYPTON® TECHNICAL REFERENCE MANUAL FPGA A field-programmable gate array (FPGA) is an integrated circuit designed to be configured by the customer or designer. field-programmable . After manufacturing: hence The electrical ground (aka. earth). The Global Positioning System (GPS) is a space-based global navigation satellite system that provides reliable location and time information in all weather and at all times and anywhere on or near the Earth when and where there is an unobstructed line of sight to four or more GPS satellites.
  • Page 137 KRYPTON® TECHNICAL REFERENCE MANUAL Microsoft® Corporation is a public multinational corporation head-quartered in Redmond, Washington, USA that develops, manufactures, licenses, and supports a wide range of products and services predominantly related to computing through its various product divisions. DewesoftX® is a Windows® based application and thus a Windows® operating system must be installed on the measurement PC where DewesoftX®...

  • Page 138: Synchronization Cable

    KRYPTON® TECHNICAL REFERENCE MANUAL Signal to Noise Ratio (SNR) is the ratio of the RMS value of the full scale input range to the total RMS noise measured with the inputs shorted together. The value for SNR is expressed in decibels (dB). SNTP Simple Network Time Protocol (SNTP) is a protocol for synchronizing the clocks of computer systems over packet switched, variable-latency data networks.

  • Page 139: Warranty Information

    12.2. Support Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties regarding the system. For any support please contact your local distributor first or Dewesoft directly.

  • Page 140: Copyright

    When used in text representing the company, product or technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ® sign is not used in the visual representation of the triangle logo.

  • Page 141: Safety Instructions

    Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and intended use of the product. Dewesoft d.o.o. assumes no liability for the customer’s failure to comply with these requirements.

  • Page 142: Product End-Of-Life Handling

    This symbol indicates that this system complies with the European Union’s requirements according to Directive 2002/96/EC on waste electrical and electronic equipment (WEEE). Please find further information about recycling on the Dewesoft web site www.dewesoft.com Restriction of Hazardous Substances This product has been classified as Monitoring and Control equipment and is outside the scope of the...
  • Page 143 REMOVE POWER and do not use the product until the safe operation can be verified by service-trained personnel. If necessary, return the product to Dewesoft sales and service office for service and repair to ensure that safety features are maintained.
  • Page 144 KRYPTON® TECHNICAL REFERENCE MANUAL Use measurement leads or measurement accessories aligned with the specification of the ● system only. Fire hazard in case of overload! Do not switch on the system after transporting it from a cold into a warm room and vice versa. ●...

  • Page 145: Documentation Version

    KRYPTON® TECHNICAL REFERENCE MANUAL 14. Documentation version Date Doc-Version Notes [dd.mm.yyyy] v20-1 15.06.2020 The NEW KRYPTON manual - Reworked and revised version ● Added products: ● KRYPTONi-1xCAN-FD ○ KRYPTONi-8xLA ○ Mounting plates ○ V20-2 25.11.2020 Remote-on pin description for KRYPTON CPU ●...

  • Page 146: Previous Versions History

    KRYPTON® TECHNICAL REFERENCE MANUAL V23-2 14.2.2023 KRYPTON-1xAO: changed the specification, now function ● generator option is supported Corrected the mating connector for EtherCAT OUT connectors ● V23-3 28.7.2023 9.2. Power Injector - updated connection picture ● KRYPTON-8xTH-HS; Power consumption specifications change ●...
  • Page 147 KRYPTON® TECHNICAL REFERENCE MANUAL 2.0.0 20.09.2018 Added KRYPTON-4xACC,KRYPTON-8xACC ● Added KRYPTON-6xSTG ● Added KRYPTONi-2xCAN-USB ● Added KRYPTON ONE product line: ● KRYPTONi-1xACC ○ KRYPTON-1xAO ○ KRYPTONi-1xCAN ○ KRYPTON-1xCNT ○ KRYPTONi-4xDI ○ KRYPTONi-4xDO ○ KRYPTONi-1xHV ○ KRYPTONi-1xLV ○ KRYPTONi-1xSTG ○ KRYPTONi-1xTH-HV ○...
