STEP 2 REVERSING THE DOOR
(Cont.)
• Move the plug on the toekick from the left to the right
and reattach toekick to the unit.
• Remove top plug/bushing from the door using a flat
head screwdriver. Discard the bushing.
• Rotate the door 180°.
• Remove the screw from the plug/bushing on the
bottom of the door. Discard the plug/bushing but keep
the screw.
• Remove the black screw post from the bottom of the
door using a flat head scewdriver. Keep the screw
post.
NOTE: The top will now be the bottom of the door and
the bottom is now the top.
10
Installation Instructions
(ZIFS240 model only)
STEP 2 REVERSING THE DOOR
(Cont.)
• Insert the new top plug/bushing in the new top of the
door.
• Rotate the door 180°.
• Re-insert the black screw post in the new bottom of
the door.
• Insert the new bottom plug/bushing in the new bottom
of the door. Secure with the screw removed from the
old plug/bushin.
• To install the door, set the door onto the left bottom
hinge pin. Holding the door in place, insert the new
top left hinge pin into the door and secure the hinge to
the case with screws.
(ZIFS240 model only)
31-51544-11
