Summary of Contents for Progress PCN43100X

  • Page 1 User Manual Oven PCN43100X...

  • Page 2: Table Of Contents

    2 Progress CONTENTS Safety information Using the accessories Safety instructions Additional functions Product description Hints and tips Control panel Care and cleaning Before first use Troubleshooting Daily use Technical data Clock functions Energy efficiency Automatic programmes Subject to change without notice.

  • Page 3: Safety Instructions

    Progress 3 General Safety Only a qualified person must install this appliance and • replace the cable. WARNING: The appliance and its accessible parts become • hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised.
  • Page 4 4 Progress • Make sure that the electrical information • Make sure that the ventilation openings on the rating plate agrees with the are not blocked. power supply. If not, contact an • Do not let the appliance stay unattended electrician.

  • Page 5: Product Description

    Progress 5 • If the appliance is installed behind a • Do not clean the catalytic enamel (if furniture panel (e.g. a door) make sure applicable) with any kind of detergent. the door is never closed when the Internal light appliance is in operation.

  • Page 6: Control Panel

    6 Progress Accessories Baking tray Wire shelf For cakes and biscuits. For cookware, cake tins, roasts. CONTROL PANEL Electronic programmer Use the sensor fields to operate the appliance. Sensor Function Description Field DISPLAY Shows the current settings of the appliance.
  • Page 7 Progress 7 Sensor Function Description Field DOWN To move down in the menu. To move up in the menu. To confirm a selection or setting. OVEN LIGHT To activate or deactivate the oven lamp. CLOCK To set the clock functions.

  • Page 8: Before First Use

    8 Progress Symbol Name Description Minute minder The minute minder function operates. Heat up indicator When the appliance is at the set temperature, the bars go off the display. If you activate an oven function, the bars come on in the display. The bars show that the temperature in the appliance increases or decreases.
  • Page 9 Progress 9 Oven functions Oven function Application True Fan Cook- To bake on up to two shelf positions at the same time and to dry food. Set the temperature 20 - 40 °C lower than for Top / Bottom Heat.

  • Page 10: Clock Functions

    10 Progress Setting the oven function 1. Touch The Temperature / Time display shows the 1. Activate the appliance with temperature in the appliance. The display shows the set temperature, the If you want to change the temperature, symbol and the number of the oven...
  • Page 11 Progress 11 Count Up Timer When the set time ends, an acoustic signal sounds for two minutes. symbol and the The Count Up Timer is not time setting flash in the display. The activated if Duration and End are appliance deactivates.

  • Page 12: Automatic Programmes

    12 Progress Setting the Time delay function When the Time delay function is activated, the display shows a The DURATION and END can be static symbol of the oven used at the same time, if the appliance is to function, with a dot and be switched on and off automatically later.

  • Page 13: Using The Accessories

    Progress 13 The display shows: the cooking time, the 6. When the set time ends, an acoustic duration symbol , a default weight, a unit signal sounds for two minutes. of measurement (kg, g). flashes. The appliance deactivates. 4. Touch or the settings save 7.

  • Page 14: Additional Functions

    14 Progress ADDITIONAL FUNCTIONS Using My Favourite Programme To deactivate the Child Lock function function repeat step 2. Use this function to save your favourite Using the Function Lock temperature and time settings for an oven You can activate the function only when the function or programme.

  • Page 15: Hints And Tips

    Progress 15 Brightness of the display 1. When the appliance is deactivated, touch and hold for three seconds. There are two modes of display brightness: The display shows SET1 and "1" flashes. • Night brightness - when the appliance is 2.
  • Page 16 16 Progress this occurs, do not change the When you cook frozen food, the trays in the temperature setting. The differences oven can twist during baking. When the equalize during the baking procedure. trays become cold again, the distortions are •...
  • Page 17 Progress 17 Baking on one oven level Baking in tins Food Function Tem- Time (min) Shelf posi- pera- tion ture (°C) Ring cake or brioche True Fan 150 - 50 - 70 Cooking Madeira cake / Fruit True Fan 140 -...
  • Page 18 18 Progress Food Function Temper- Time (min) Shelf posi- ature tion (°C) then 160 - 180 30 - 60 Top / Bottom 190 - 210 20 - 35 Cream puffs / eclairs Heat Top / Bottom 180 - 200 10 - 20...
  • Page 19 Progress 19 Food Function Temper- Time (min) Shelf posi- ature tion (°C) Pastries made with egg True Fan 80 - 100 120 - 150 white, meringues Cooking Macaroons True Fan 100 - 120 30 - 50 Cooking Biscuits made with yeast...
  • Page 20 20 Progress Food Function Temperature Time (min) Shelf position (°C) Stuffed vegeta- True Fan Cook- 160 - 170 30 - 60 bles 1) Preheat the oven. Moist Fan Baking Food Temperature (°C) Time (min) Shelf position Pasta bake 180 - 200...
  • Page 21 Progress 21 Food Temperature (°C) Time (min) Shelf po- sition Biscuits made with 160 - 170 25 - 40 1 / 4 sponge mixture Pastries made with 80 - 100 130 - 170 1 / 4 egg white, meringues Macaroons...
  • Page 22 22 Progress Food Temperature (°C) Time (min) Shelf position Swiss Flan 170 - 190 45 - 55 Cheesecake 140 - 160 60 - 90 Apple cake, covered 150 - 170 50 - 60 Vegetable pie 160 - 180 50 - 60...
  • Page 23 Progress 23 Food Function Quantity Tem- Time (min) Shelf po- pera- sition ture (°C) Roast beef Turbo Grilling per cm of 190 - 5 - 6 per cm of or fillet: thickness thickness rare Roast beef Turbo Grilling per cm of...
  • Page 24 24 Progress Lamb Food Func- Quantity Temper- Time (min) Shelf po- tion ature sition (°C) Leg of lamb, Turbo 1 - 1.5 kg 150 - 180 100 - 120 roast lamb Grilling Saddle of Turbo 1 - 1.5 kg 160 - 180...
  • Page 25 Progress 25 Fish (steamed) Food Func- Quantity Temper- Time (min) Shelf po- tion ature sition (°C) Whole fish Top / 1 - 1.5 kg 210 - 45 - 60 Bottom Heat Grilling • Grill only flat pieces of meat or fish.
  • Page 26 26 Progress Frozen foods • Do not cover it with a bowl or a plate. This can extend the defrost time. • Remove the food packaging. Put the food on a plate. Food Temperature (°C) Time (min) Shelf position Pizza, frozen...
  • Page 27 Progress 27 Defrost • Do not cover the food with a bowl or a plate, as this can extend the defrost • Remove the food packaging and put the time. food on a plate. • Use the first shelf position from the bottom.

  • Page 28: Care And Cleaning

    28 Progress Stone fruit Food Temperature (°C) Cooking time until Continue to cook simmering (min) at 100 °C (min) Pears / Quinces / 160 - 170 35 - 45 10 - 15 Plums Vegetables Food Temperature (°C) Cooking time until...
  • Page 29 Progress 29 sharp-edged objects or a dishwasher. It can cause damage to the nonstick coating. Removing the shelf supports To clean the oven, remove the shelf supports. 1. Pull the front of the shelf support away from the side wall.

  • Page 30: Troubleshooting

    30 Progress Replacing the lamp 6. Hold the door trim (B) on the top edge of the door at the two sides and push Put a cloth on the bottom of the interior of inwards to release the clip seal.
  • Page 31 Progress 31 Problem Possible cause Remedy The oven does not heat up. The necessary settings are Make sure that the settings not set. are correct. The oven does not heat up. The automatic switch-off is Refer to "Automatic switch- activated.

  • Page 32: Technical Data

    32 Progress We recommend that you write the data here: Product number (PNC) ......... Serial number (S.N.) ......... TECHNICAL DATA Technical data Voltage 220 - 240 V Frequency 50 Hz ENERGY EFFICIENCY Product Fiche and information according to EU 65-66/2014...
  • Page 33 Progress 33 Use the residual heat to warm up other meal warm. The display shows the residual dishes. heat indicator or temperature. Cooking with fan Cooking with the lamp off When possible, use the cooking functions Deactivate the lamp during cooking and with fan to save energy.
  • Page 34 34 Progress...
  • Page 35 Progress 35...
  • Page 36 867316962-C-182016...
