38

Flash Memory Image Parameter Set

This Parameter Set is used for dumping flash memory contents. One Parameter Set corresponds to an image block
of 2 Mbytes of flash memory. The 4 Mbytes of flash memory of this Model is made up of two blocks, so two
Parameter Sets are used.
System Exclusive Format
Field Value
01 SYSEX F0
02 MAN 44
03 MOD 11,02
dev
04 00 to 1F, or 7F
act
05 04(HDS), 05(HDR), 07(Control)
cat
06 Flash Memory Image = 11
prm
07 00
ilen/dlen See "IV This Model's System Exclusive Message".
08
ps
09 Indicates the Flash Image Block Number being transferred.
For details, see "39 About Parameter Set (PS) numbers".
index
10 See "IV This Model's System Exclusive Message".
data
11 See "IV This Model's System Exclusive Message".
sum
12 See "IV This Model's System Exclusive Message".
13 EOX F7
39

About Parameter Set (PS) numbers

When using a system exclusive message to transfer a user Parameter Sets or user Parameter Set parameters, the
specified Parameter Set number do not necessarily need to start from zero when the Parameter Set numbers are
located after the preset Parameter Set. Refer to the table below for user area Parameter Set number for each
category.
PS Category User PS Header (Decimal)
Tone 830
Tone with wave 930
Timbre 560
Drum 20
Voice 1024
Instrument 320
Wave 1024
Rhythm 160
Song 0
SMF 0
DrawbarOrgan 100
Registration Registration 32 (See "35 Registration Data".) 32
Flash Memory Image 0
Number of User PS (Decimal)
100
20
20
4
80
512
1792
16
5
200
100
2
65
