Patch Parameter

The patch parameter is a temporary area that controls the sound source operation mode. Mixer settings, synthesizer
function, DSP function and other editable parameters are also included in these areas.
The content of this area is rewritten whenever preset data or user data is selected and manipulated. The parameters
in this area are written into the user area whenever data is written into any user data area.
21.1

Patch Common Parameter List

This list shows setting parameters that are common for each part.
System Exclusive Format
Field Value
01 SYSEX F0
02 MAN 44
03 MOD 11,02
dev
04 Either 00 to 1F, or 7F
act
05 00(IPC), 01(IPR)
cat
06 Patch = 01
prm
07 00-7F
ilen/dlen 0 / bit size - 1
08
ps
09 LSB,MSB = 00, 00
index
10 Indicates Bar Number in the case of
Drawbar Bar Position.
0 in any other case.
data
11 See the Parameter List
sum
12 None
13 EOX F7
MIDI Parameter List
ParamID Parameter
00 MIDI Device ID (Note 1)
01 MIDI Global Channel
Note 1:
This parameter sets the SysEx Device ID.
Tune / Mix Parameter
ParamID Parameter
04 Master Fine Tune (Note 1)
05 Master Coarse Tune (Note 2)
08 Master Volume
09 Master Pan (Note 3)
0A Chorus Send To Reverb (Note 4)
0B DSP Line Bypass (Note 5)
bit Value
07 00-1F
04 00-0F
bit Value
08 00-FF
07 28-58
07 00-7F
07 00-7F
07 00-7F
01 0-1
47
Default Setting Value (Decimal)
10 0-31
00 1-16
Default Setting Value (Decimal)
80 -100 to 0 to 99cent
40 -24 to 0 to 24semi
7F 0-127
40 -64 to 0 to +63
00 0-127
0 0...Effect
1...DSP Bypass
