FD1

User Manual

V1.0

Need help?

Do you have a question about the Splashdrone Fisherman FD1 and is the answer not in the manual?

Questions and answers

Summary of Contents for SWELLPRO Splashdrone Fisherman FD1

Page 2 Thank you for purchasing SwellPro Fisherman FD1 .We have designed and manufactured the FD1 specially developed for marine fishing enthusiasts. FD1 continues the excellent waterproof feature of Swellpro. The design focuses on simplifying than complex , with new feature of super payload capacities, superior flight performance, easy to maintenance. come with higher competitive performance.
Page 3 Take off and landing on boat Appendix Specification Warranty and after-sales service Accessories available Guidelines for the safety use of batteries Safe operation guidelines and disclaimer and Warning Safe Operation Guide Disclaimer and warning Version Information Drone Components ©2021 Swellpro All rights reserved...
Page 4 [07] Rubber Damper Ball [08] Landing gear [09] GPS top cover [10] Drone indicator lights are visible through the top cover [11] Nose direction markers [12] Power Switch [13] Airdrop release dispenser PL1-F Remote Controller Components ©2021 Swellpro All rights reserved...
Page 5 Adjust the release volume of throttle rudder for the front and backward flying [14] Flight mode swift GPS/headless flight /ATTI [15] Return home switch Commands the drone to return home automatically [16] Handle Throttle switching method: ©2021 Swellpro All rights reserved...
Page 6 [12] Latitude [13] Longitude [14] Flight time [15] Roll angle [16] the release volume of throttle rudder for the left and right flying [17] the release volume of throttle rudder for the front and backward flying ©2021 Swellpro All rights reserved...
Page 7 Alternating Red and Green slow flashing IMU error needs to be calibrated Red and Green alternate slow flashing Initialization process The flashing mode of all calibration prompts is the same. For specific calibration, please refer to the display prompts on the remote control screen. Propellers ©2021 Swellpro All rights reserved...
Page 8 Spin each propeller by hand to check that the motors are free of sand or salt and spin freely.If there are impurities in the motor, be sure to clean it up before starting the motor. Batteries ©2021 Swellpro All rights reserved...
Page 9 At this time, alternating nose red indicator light fast flashing. (If you want to land the drone manually,Please switch to ATTI mode to take over the drone control again) Level 1 warning: pop-up icon, slow flashing prompt (interval 3 seconds) ©2021 Swellpro All rights reserved...
Page 10 Return home Flare maneuver Description If the drone’s height > 20 Meters and distance from Home Point > 15 Meters, the drone will maintain its altitude and return to its Home Point. ©2021 Swellpro All rights reserved...
Page 11 4. If the remote control prompts "WARNING Gyroscope error Calibrate Gyroscope", it needs to be calibrated. 5. When hovering in GPS mode, the aircraft jitters at the hovering point. Gyroscope Calibration Process Remote control Description ©2021 Swellpro All rights reserved...
Page 12 4. The drone is subject to strong magnetic interference. 5. The drone has been hit or violently shaken. 6. When hovering in GPS mode, the aircraft shakes or drifts greatly. 7. "WARNING Compass error Calibrate Compass" appear on the FPV screen Compass Calibration ©2021 Swellpro All rights reserved...
Page 13 1. The drone cannot start the motors after completing the compass calibration. 2. When hovering in GPS mode, the aircraft will shake or drift at angle. 3. The drone has been hit or violently shaken. 4. "WARNING IMU error-Calibrate IMU" appear on the FPV screen Cautions ©2021 Swellpro All rights reserved...
Page 14 . The installation of the Remote control battery The remote controller battery is behind the hatch. Press the hatch slightly and slide it open. Install 4pcs AAA batteries in the correct direction. ©2021 Swellpro All rights reserved...
Page 15 Drone control The remote controller defaults to the left-hand throttle. If you want to switch to the right-hand throttle, please refer to P8 of this manual. Left hand throttle- (American/European configuration) (Model 2) ©2021 Swellpro All rights reserved...
Page 17 Place the drone in an open area at least 3 meters away from you and others. After the aircraft is powered on, the system will self-inspection. After the self-inspection is completed, you can hear a sound "DI". Beginner is recommended to unlock and take off in GPS mode. ©2021 Swellpro All rights reserved...
Page 18 If the drone flips,The flight controller will stop the motor. If the drone is turned over, do not stay on the water for too long. Use the flip switch to turn the drone over as quickly as possible to avoid water ingress. ©2021 Swellpro All rights reserved...
Page 19 2. Gust = 14m/s (F7) Peak Hovering Precision: ±0.5m Max Flight Time (per charge): 39 minutes (hovering without load) Max flight distance: 1.3km Max take-off weight: 3.7kg Max Payload Capacity:1.5kg Satellite positioning: GPS/GLONASS dual module Flight control: Swellpro S4 ©2021 Swellpro All rights reserved...
Page 20 Channel: 6 Battery: 6V(1.5V AA*4) Page: 22 Warranty and after-sales service Please visit Swellpro website (www.swellpro.cn) to find the "After-sales Service Policy" and submit a service request when needed. Optional parts: PL1-F Integrated design of the waterproof release device, the maximum loading weight support 2KG...
Page 21 ⚫ It is strictly forbidden to use batteries that are not officially provided by Swellpro. If you need to replace it, please go to Swellpro's official website for relevant purchase information.
Page 22 ● The aircraft battery and the remote control battery must be charged with a special charger provided by Swellpro. For the use of non Swellpro will not be responsible for all consequences caused by the charger provided by Swellpro. ● When charging, please place the battery and charger on cement or other non-flammable ground, and there are no flammable or combustible materials around.
Page 23 ● Make sure that the aircraft motor rotates smoothly, and manually rotate it to check if it can rotate smoothly. ● Make sure that the GPS top cover is installed in the correct direction, and the locking bolts are sealed. ©2021 Swellpro All rights reserved...
Page 24 Please switch back to ATTI Attitude Mode for the first time and manually control the flight to land within the line of sight, turn off the power of the aircraft, and then turn off the remote control controller. ©2021 Swellpro All rights reserved...
Page 25 ● It is forbidden to use this product for any behavior that violates the privacy of others (make sure that the user knows and understands before using the aircraft’s camera) Understand local privacy laws and regulations). ©2021 Swellpro All rights reserved...
Page 26 Responsible for losses suffered by purchasing, using or not being able to use this product. Page 28 Swellpro does not accept personal injury or property damage caused by improper use of the following ● Operate the aircraft while drunk or under the influence of drugs ●...
Page 27 ● Other damages not within the scope of Sweipu’s liability Version Information Swellpro products are continuously improving and upgrading. Therefore, the latest manual may contain different information from the equipment you purchased, but we will Continuously improve and add content.
