SPLASHDRONE FD1 (New Zealand Version) Drone
Additional Support Information
IMPORTANT – PLEASE READ & ENSURE YOU
UNDERSTAND!
By Flying this Drone you are agreeing that you have read & understand all of the notes &
documentation contained within this packaging including The Product User Manual, Disclaimer
Documentation, and this Support Documentation & that you agree that you will abide by all New
Zealand laws & legislation surrounding the usage of this Drone (Including the Civil Aviation Act
1990)
PLEASE MAKE SURE YOU HAVE FULLY READ, UNDERSTAND, AND ARE WILLING TO FOLLOW THE
INFORMATION & INSTRUCTION CONTAINED IN THIS SUPPORT DOCUMENT, BEFORE ATTEMPTING
TO FLY THE DRONE
PLEASE NOTE: Information contained in this document is designed to supplement the "FD1 User
Manual" & highlights important information to assist when flying specifically in New Zealand.
GIVEN NEW ZEALAND'S DIFFERENT OUTDOOR ENVIRONMENT & RUGGED CONDITIONS, PLEASE USE
INFORMATION CONTAINED IN THIS SUPPORT DOCUMENT FIRST & FOREMOST (WHEN IN DOUBT –
REFER TO THIS DOCUMENT)
(Information contained in this document specifically pertains to The SPLASHDRONE FD1 NZ model and is
correct at the time of publishing, however instructions and information is subject to change without notice.)
For IMPORTANT VIDEO INSTRUCTIONS, PLEASE FOLLOW THE QR CODE LINK THAT CAME WITH
YOUR DRONE, WATCH THE VIDEO & FOLLOW THE INSTRUCTIONS.
PLEASE VISIT THE JCMATTHEW YOUTUBE CHANNEL
IF YOU CAN'T FIND THE QR CODE
ONLINE
on the Internet (Easy to find by searching for "JCMatthew" on YOUTUBE)
There you will find a number of helpful Instructional Videos – particularly in relation to
successfully Calibrating your Splashdrone. It is advisable that you familiarize yourself with
these videos.
There are a number of third party or consumer made videos available online & YOUTUBE. We
advise STRONGLY that you DO NOT take instruction from any of these videos, as the information
can often be incorrect OR they relate to old models OR show incorrect usage of the product, none
1
of which we at JCMatthew NZ Condones.

Advertisement

loading
Need help?

Need help?

Do you have a question about the JCMatthew SPLASHDRONE FD1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SWELLPRO JCMatthew SPLASHDRONE FD1

Summary of Contents for SWELLPRO JCMatthew SPLASHDRONE FD1

  • Page 1 SPLASHDRONE FD1 (New Zealand Version) Drone Additional Support Information IMPORTANT – PLEASE READ & ENSURE YOU UNDERSTAND! By Flying this Drone you are agreeing that you have read & understand all of the notes & documentation contained within this packaging including The Product User Manual, Disclaimer Documentation, and this Support Documentation &...
  • Page 2 IMPORTANT INITIAL SETUP NOTES  Please note – Your new NZ Model drone has been specifically set up, tuned & calibrated for New Zealand conditions & has been fully checked & tested to ensure it flies and performs perfectly before leaving our New Zealand factory. ...
  • Page 3  Prior to take-off (When in GPS Mode & the drone is sitting on the ground outside) After the Remote control & the Splashdrone have been powered on, the number of Satellites visible (shown in the upper right hand of the Remote LCD Display) will display the strength of the satellites being tracked.
  • Page 4 LID ALWAYS IS SECURED WITH THE SMALL ARROW FACING FORWARD TOWARD THE FRONT OF THE DRONE. The Lid is also Labeled with a “FRONT” Sticker. IF THE COVER IS PUT ON A DIFFERENT WAY – THIS ALMOST CERTAINLY WILL RESULT IN A CRASH –...
  • Page 5 First battery warning can be seen as 14.4V in the TOP MIDDLE-RIGHT CORNER of the LCD Display & it will also show the Icon on your remote display (as highlited below) REMOTE CONTROL LCD DISPLAY  *IMPORTANT* Although the Splashdrone can float, takeoff & land IN CALM WATER CONDITONS if required, the top section of the DOME on the LID of the Lid of the drone is INTENTIONALLY not 100% sealed or completely watertight for technical reasons (although it is designed to resist water entry) –...
  • Page 6  If you have a WIFI Feature on your Smart Phone or Tablet – PLEASE TURN OFF/ PUT it into “FLIGHT MODE” BEFORE attempting to Fly this drone – as there is a small chance that this could cause intereference to your drone potentially causing a crash (at owner’s risk). ...
  • Page 7 Failure to calibrate properly when required may result in a crash (at the owner’s risk). Please ensure that the calibration process is followed correctly, and is completely successfully according to the Drone’s flashing Indicator light. Ensure there are no devices with Wifi enabled, close to you while calibrating ( Smartphone, Go pro camera) &...
  • Page 8 Please ensure that all of your Propellers are securely fastened before Flight.   Please DO NOT Fly with Damaged Propellers OR with Propellers not installed correct as a Crash may result, which is not covered under warranty.  Please DO NOT operate the Drone close to power lines, large metallic objects (like cars) or other radio interference, as this may significantly effect the compass, GPS, and Radio Control possibly resulting in a crash (at owners risk).
  • Page 9 SPLASHDRONE BATTERY & POWER CABLE NOTES: IMPORTANT! AT ALL TIMES, PLEASE PAY ATTENTION TO THE BATTERY INDICATOR IN THE UPPER  CENTRE/RIGHT CORNER OF THE REMOTE CONTROL DISPLAY SCREEN (THIS SHOWS IN “V” FOR VOLTS). ONCE THE VOLTAGE DROPS TO 14.6V (or first visual warning on your remote control) –...
  • Page 10 battery has a fresh set of good quality batteries installed before attempting to fly – in other words, wait for the Battery charger to complete charging & then shut down itself (ie the fan will turn off), before disconnecting the battery from the charger. This will maximise your flight time.
  • Page 11 REFERENCE IMAGE OF THE REMOTE CONTROL LCD DISLAY SCREEN WHEN THE REMOTE IS POWERED ON. NOTE THE BATTERY VOLTAGE INDICATOR IS SHOWN AS 15.4V  Any crash or Drone Damage resulting from not following the above instructions – will not be covered under warranty.
  • Page 12 Important Notes Particularly For Less Experienced Flyers: ALWAYS carry out a PRE-Flight Check on your Drone before attempting to take off. This  includes making sure the Propellers are all spinning Freely, the Drone is free of Salt build-up or Corrosion &...
  • Page 13 General Maintenance & Care Although the drone is water resistant, the remote control is not . Please refrain from  getting the remote control wet at all. Also please make sure that sand is kept away from the remote if possible as if grains enter around the joystick or under the buttons – they can effect your ability to control the drone.
  • Page 14 Under normal conditions when no visible signs of moisture are detected, Once the drone has been sprayed down with fresh water & the drone dried off – it is recommended that the LID is then removed & the Drone is placed & temporarily stored in a dry &...
  • Page 15 If you have crashed your drone into the water, the same applies: ANY MOISTURE NEEDS TO BE COMPLETELY REMOVED STRAIGHT AWAY FROM INSIDE THE DRONE. In this situation it is advisable to get the drone back to the JCMatthew Service Centre for a Service.
  • Page 16 result in a reduced battery life or even an inability to recharge the battery at all. DO NOT USE BATTERIES THAT HAVE SWELLED.  DO NOT CHARGE A BATTERY THAT IS STILL WARM FROM RECENT USE IN AN RC  DEVICE.
  • Page 17 Check Correct Propellers are on the correct Motors – Drone would not get there are two types (Clockwise and Counter-Clockwise), into the Air – keeps the Correct Propeller must be placed on the correct tipping over motor otherwise it won’t fly. IMPORTANT flying tips: ...
  • Page 18  For your Flight times – don’t push your luck, particularly when carrying weights and OBEY any Low Battery warning messages that come up on the Remote. For new pilots, to get used to the drone DON’T carry weights & stay with flight times under 15 minutes.
  • Page 19 Remember that following a crash of the Splashdrone, it may not function or fly as  expected afterwards. If it is only a minor crash or hard landing then a simple Compass/GPS, GYRO & IMU Calibration maybe all that is needed. Please also check for any damage or non-working parts BEFORE FLYING.

  • Page 20: Important Safety Instructions And Warnings

    Lithium HV Batteries LiHV batteries have two separate leads. The shorter lead with the WHITE (JST) connector attached is for charging only. It is the only lead protected by Charge Protection Circuitry, helping prevent costly charging errors. It is very important to note that the circuit only protects during the charge process.
  • Page 21 risk of fire based incidents. 2) Charge in an isolated area, away from other flammable materials on a concrete surface outside of buildings. This will reduce the risk of fire spreading and therefore isolating any incident. It is highly recommended not to charge inside buildings or vehicles.
  • Page 22 3) Please check pack voltage after the first charge. Example 2-Cell: 8.4V (8.30 to 8.44) 3-Cell: 12.6V (12.45 to 12.66) 4) Do not discharge battery to a level below 3V per cell under load. Deep discharge below 3V per cell can deteriorate battery performance.
  • Page 23 JCMatthew NZ Ltd takes no responsibility or liability whatsoever for the use of this product, and specifically including (but not limited to) when this use is outside or contravenes any national or local laws and regulations. Limitation of Liability JCMATTHEW NZ LTD accepts no liability for damage(s)or injuries incurred directly or indirectly from the use of this product in the following conditions: Damage(s) or injuries incurred when users are drunk, taking drugs, anesthesia, dizziness, fatigue, physically or mentally that could impair your ability.
  • Page 24 website. Operators do not obey the 10661 law or regulation. Other losses that not covered by the scope of Liability. Warning NOTE: Neither JCMatthew NZ Ltd or the manufacturer is responsible for any radio, or TV interference caused by unauthorized modifications or changes to this equipment. Such modifications or changes could void the users authority to operate the product.
  • Page 25 5. The User takes full responsibility to ensure they are following ALL local and national laws governing the usage of UAV, and Drones including Council by-laws and Conservation Department laws and regulations.
