Operation and Setting

Display and Function Keys

1 6
C
CH 1 Fix
1 3 . 0 3 . 2 0 1 6
B
09:00
FIX O V R
A
1 2
I
Function displays of the two buttons on the right (G):
Menu Leave auto mode and enter programming Mode
ESC Press briefly = Goes back one step
Press for a long time (about 2 sec) = Goes back to auto mode
OK Make the selection and apply it
< Undo the last input, e .g . when entering the time
Function displays of the two buttons on the left (I):
Channel status for Channel 1
1
Channel status for Channel 2
2
˄
Page upwards in the menu
˅
Page downwards in the menu
- Press briefly = The displayed value (hour, minute, etc.) is decremented by 1/
Press for a long time (about 2 sec) = fast scrolling
+ Press briefly = The displayed value (hour, minute, etc.) is incremented by 1/
Press for a long time (about 2 sec) = fast scrolling
12 18 24
D
Ovr
E
51
F
Menu
H G
Display:
A Function displays of the buttons on the left
B Date and time or menu navigation
C Programmed switching times
D Display of summertime/wintertime
E Bluetooth-Anzeige
F Function displays of the buttons on the right
Buttons:
G Buttons on right
H Reset-Taste
I Buttons on left
