- Page 1 FANAWAY ORBIT CEILING FAN • INSTALLATION • OPERATION • MAINTENANCE • WARRANTY INFORMATION CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. V1.1 AU (10/2020)
- Page 2 Fanaway Orbit Installation Instructions THANK YOU FOR PURCHASING Thank you for purchasing this quality Fanaway product. To ensure correct function and safety, please read and follow all instructions carefully before assembly, installation and use of this ceiling fan. Please keep instructions for future reference.
- Page 3 Fanaway Orbit Installation Instructions all-pole disconnection to the ceiling fan electrical circuit, meeting the requirements of clause 7.12.2 of AS/NZS 60335.1. A single-pole switch on the active of the receiver input of remote control must also be included in the wiring, and located the same room as the ceiling fan.
-
Page 4: Parts List
Fanaway Orbit Installation Instructions PARTS LIST • Unpack your ceiling fan carefully. Remove all parts and hardware. • Lay out all the components on a smooth surface and make sure there are no components missing before assembling. If parts are missing, return the complete product to the place of purchase for inspection or replacement. -
Page 5: Installing The Fan
Fanaway Orbit Installation Instructions INSTALLING THE FAN TOOLS REQUIRED: Phillips / flat head screwdriver Pair of pliers Adjustable spanner Step ladder Wire cutter Wiring, supply cable as required by local provincial and national wiring codes and regulations INSTALLING THE MOUNTING BRACKET •... - Page 6 Fanaway Orbit Installation Instructions HANGING THE FAN ASSEMBLY • Lift the fan assembly（1）up to the mounting bracket. Hang the fan assembly onto the J-hook (2) of the mounting bracket. (Fig.3) （2） （1） Fig. 3 • Complete the electrical wiring according to the ‘ELECTRICAL WIRING DIAGRAM’ section below.
- Page 7 Fanaway Orbit Installation Instructions USE WITH REMOTE WIRING DIAGRAM: (REMOTE sold separately) Ensure the motor earth wire is connected to the single earthing terminal block “1” in the diagram for (Fig.5 and Fig.6) 1/ Remote without plugs (manual wiring) Fig. 5...
- Page 8 Fanaway Orbit Installation Instructions INSTALL THE FAN ASSEMBLY TO THE MOUNTING BRACKET • After completing the electrical connection at the mounting bracket terminal block, connect the ceiling fan wiring via the quick connector plug. • NOTE: Ensure the earth wiring is secure and correct, by performing an earthing continuity test from the fan’s accessible metal body back to the earth terminal at the terminal...
-
Page 9: Light Kit Installation
Fanaway Orbit Installation Instructions LIGHT KIT INSTALLATION LIGHT KIT INSTALLATION (Fig. 6 & 7) 1. Loosen the screw (2) from the fan bracket. Align the two slot screws (1 and 3) with the keyhole slots (1 and 3) of the light kit plate . (Fig. 6) 2. -
Page 10: Using Your Ceiling Fan
Fanaway Orbit Installation Instructions USING YOUR CEILING FAN FAN WALL CONTROL (Fig. 8) Turn on the power and check the operation of the fan. • OFF Position – Fan Off • 3rd Position – Low fan speed • 2nd Position – Medium fan speed •... -
Page 11: After Installation
To clean the fan blade, wipe with only a damp clean cloth with NO organic solvents or cleaners. • The motor has a permanently lubricated ball bearing so there is no need to oil. TECHNICAL INFORMATION 36’’ fan – Fanaway Orbit Fan Models LD-36 CTC FAN (SKU# 210664 / 210665 / 210666 ) Rated Voltage... - Page 12 In the event of a service being required, please call the Lucci Warranty Service Hotline acting as the service agent for Fanaway on 1800 602 243 between 9AM and 5PM (E.S.T) Monday to Friday. Ensure you have the following details on hand.
- Page 13 CONTACTS: Contact Lucci Warranty Service Hotline acting as the service agent for Fanaway on 1800 602 243 between 9AM and 5PM (E.S.T) Monday to Friday, or go to Website: for more information.
