FANAWAY LED EVO1
Retracting Blade Ceiling Fan and Light
INSTALLATION
OPERATION
MAINTENANCE
WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.
VER 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LED EVO1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fanaway LED EVO1

  • Page 1 FANAWAY LED EVO1 Retracting Blade Ceiling Fan and Light INSTALLATION OPERATION MAINTENANCE WARRANTY INFORMATION CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. VER 1.0...
  • Page 2 Fanaway LED EVO1 Installation Instructions CONTENTS Installation instruction manual ..................2 Installationsanleitung ......................11 Guide d’installation......................18 Manual de instrucciones de instalación................26 Manuale delle istruzioni di installazione................34 Installatiehandleiding......................42 1 | P a g e V e r 1 . 0...
  • Page 3: Safety Precautions

    Fanaway LED EVO1 Installation Instructions THANK YOU FOR YOUR PURCHASE Thankyou for purchasing this quality Fanaway product. To ensure correct function and safety, please read and save all instructions before using the product. SAFETY PRECAUTIONS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 4: Before Installation

    Fanaway LED EVO1 Installation Instructions BEFORE INSTALLATION Unpack your fan and check contents. You should have the following: Fig. 1 3 | P a g e V e r 1 . 0...
  • Page 5: Installing The Fan

    Fanaway LED EVO1 Installation Instructions Mounting bracket x 1 Retraction mechanism x 1 Canopy screws x 4 Lamp base x 1 Canopy x 1 LED board x 1 Down rod x 1 Lamp shade x 1 Bolt x 1 Wooden screws x 2 Bolt &...
  • Page 6: Hanging The Fan

    Fanaway LED EVO1 Installation Instructions ANGLED CEILING INSTALLATION This fan hanging system supports a maximum 15 degree angled ceiling installation. Fig. 3 HANGING THE FAN Installing the down rod Feed the down rod (5) through the canopy (4) and the bolt and pin cover (6).
  • Page 7 Fanaway LED EVO1 Installation Instructions Select the color temperature (3000K or 4000K) by sliding the switch (2). Finally install the lamp to the lamp base by turning it clockwise (No.13 – Fig. 1). Fig. 6 Fig. 7 ELECTRICAL WIRING DIRAGRAM PREPARE AND COMPLETE THE ELECTRICAL WIRING --- WIRING DIAGRAM (FIG.
  • Page 8: Finish The Installation

    Fanaway LED EVO1 Installation Instructions Fig. 8 Wiring requirement at the terminal block:  Switch the active wire out from the rotary switch speed control “F” to the “L” terminal of the terminal block on the mounting bracket.  Switch the active wire out from wall controller “light” switch, to the “LA” terminal of the terminal block on the mounting bracket.
  • Page 9: Using Your Ceiling Fan

    Fanaway LED EVO1 Installation Instructions USING YOUR CEILING FAN FAN WALL CONTROL Turn on the power and check the operation of the fan. • OFF Position – fan off • 3rd Position – low fan speed • 2nd Position – medium fan speed •...
  • Page 10: After Installation

    Fanaway LED EVO1 Installation Instructions AFTER INSTALLATION WOBBLE: The fan blades have been adjusted in the factory to minimize any wobble. NOTE: CEILING FANS TEND TO MOVE DURING OPERATION DUE TO THE FACT THAT THEY ARE MOUNTED ON A RUBBER GROMMET. IF THE FAN WAS MOUNTED RIGIDLY TO THE CEILING IT WOULD CAUSE EXCESSIVE VIBRATION.
  • Page 11: Technical Information

    Fanaway LED EVO1 Installation Instructions TECHNICAL INFORMATION FAN models Rated Voltage Rated power (motor) Light power 40W, 3000K/4000K FANAWAY LED FAN 220-240VAC LED driver model: ES0363D-E090 WARRANTY CONDITIONS IN AUSTRALIA / NEW ZEALAND – Please refer to the separated WARRANTY STATEMENT.
