- Page 1 FANAWAY EVO1 LED CEILING FAN WITH DIMMABLE AND COLOUR SHIFTING LED LIGHT INSTALLATION OPERATION MAINTENANCE WARRANTY INFORMATION CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. V2.0 – EN – AU EVO1 CS (07/2018)
-
Page 2: Safety Precautions
Fanaway LED EVO1 Installation Instructions THANK YOU FOR PURCHASING Thankyou for purchasing this quality Fanaway product. To ensure correct function and safety, please read all instructions before using the product and keep the instructions for future reference. SAFETY PRECAUTIONS In Europe: This appliance can be used by children aged from 8 years and above and persons with... - Page 3 Fanaway LED EVO1 Installation Instructions Example: If a fan is connected to a circuit that can be isolated via an all-pole safety switch at the switchboard, then this is considered to be an all-pole disconnection to the ceiling fan electrical circuit, meeting the requirements of clause 7.12.2 of AS/NZS 60335.1.
-
Page 4: Before Installation
Fanaway LED EVO1 Installation Instructions BEFORE INSTALLATION Unpack the fan and carefully identify the parts. Please refer to Fig 1. Fig. 1 4 | P a g e... -
Page 5: Installing The Mounting Bracket
Fanaway LED EVO1 Installation Instructions Mounting bracket x 1 Blades x 4 Canopy screw x 4 Retraction mechanism x 1 Canopy x 1 Lamp base x 1 Down rod x 1 LED board x 1 Bolt x 1 Lamp shade x 1 Bolt &... -
Page 6: Installing The Fan
Fanaway LED EVO1 Installation Instructions INSTALLING THE FAN 1. Installing the down rod Feed the down rod (5) through the canopy (4) and the bolt and pin cover (6). Remove the ball joint by loosening the set screw (3), insert the motor wires through the down rod then secure the ball joint back to the down rod. -
Page 7: Light Kit Installation
Fanaway LED EVO1 Installation Instructions 4. After completing the electrical wiring at the mounting bracket terminal and connecting the remote receiver power input wires and fixed wiring via the 4-port quick connectors (1); connect the LED driver power input wires and remote receiver power output wires via the 2-port quick connectors (3); connect the LED driver PWM signal input wires and remote receiver PWM signal output wires via the 3-port quick connectors (2);... - Page 8 Fanaway LED EVO1 Installation Instructions The remote (transmitter) and receiver must be configured so that communication between each other is paired up. This is achieved by setting the DIP switch on the receiver and remote on the same setting. Note: The DIP switch assembly has 4 switches which can be setup to 16 different transmitting code combinations.
-
Page 9: After Installation
Fanaway LED EVO1 Installation Instructions REVERSE FUNCTION Your ceiling fan can operate either in fan mode or reverse fan mode. SUMMER Mode: The reverse switch should be in the “Left” (SUMMER) position to rotate the fan in an anticlockwise direction. The airflow will be directed downwards, for cooling in summer. -
Page 10: Technical Information
Fanaway LED EVO1 Installation Instructions a new fan disappear during this time. Please note that this is not a product fault and as such is not covered under warranty – All electric motors are audible to some extent. CARE AND CLEANING: ... - Page 11 In the event of a service being required, please call the Lucci Warranty Service Hotline acting as the service agent for Fanaway on 1800 602 243 between 9AM and 5PM (E.S.T) Monday to Friday. Ensure you have the following details on hand. If you are unable to establish the date of purchase, or the fault is not covered by this Warranty, or if the product is found to be in working order, you will be required to bear all service call charges.
- Page 12 CONTACTS: Contact Lucci Warranty Service Hotline acting as the service agent for Fanaway on 1800 602 243 between 9AM and 5PM (E.S.T) Monday to Friday, or go to Website: www.fanaway.com for more information.
