The C-250 allows single line telephones or a
telephone system to share a phone line with a
single Viking entry phone. Tenants may answer
an entry phone call, converse with the visitor
and let them in with a touch tone command.
The C-250 also has a built in five number dialer
to make an outside call if there is no answer on
the inside phone. If the outside call is busy or
ring no answer, the C-250 can call up to four
more numbers.
The C-250 provides a "Call Waiting" tone when the phone line is in use. Tenants may
also call out to the entry phone for monitoring purposes.
F
e
a
t
u
r
e
s
F
e
a
t
u
r
e
s
• Allows single line telephones or a telephone system
to share a phone line with a Viking entry phone
• House phones ring with C.O. line cadence or
distinctive ring when the entry phone is calling
• Built in five number dialer
• Detects busy or ring no answer and goes onto the
next number
• Built in door strike relay with 1 or 2 digit commands
• Remote programming
• Auto answer
• Detects touch tones as fast as 50 milliseconds
• Trigger input for postal lock, Request for Exit (REX)
or immediate call forwarding
• Produces "Call Waiting" tones if the entry phone
is activated when the house phones are already
on a call
• Compatible with any Viking E Series or K Series
entry phone or use with any standard analog phone
S
S
C
O
M
O
L
U
T
I
O
N
S
C
O
M
O
L
U
T
I
O
N
S
Single Entry Phone Controller with Call
Forwarding and Door Strike Control
P
r
a
c
P
r
a
c
2
1
C
2
1
C
F
O
R
T
H
E
S
T
F
O
R
T
H
E
S
T
A
p
p
l
i
A
p
p
l
i
• Add an entry phone to your standard home or
office phones to provide door communication
• Provide commercial or residential security via
two-way handsfree communication at the door
or gate
• Connects in series with a single phone line or
with a phone system's line/trunk input
h
t
t
p
h
t
t
p
S
p
e
c
S
p
e
c
Power: 120VAC / 13.8VAC 1.25A, UL listed adapter provided
Dimensions: 133mm x 104mm x 44mm (5.25" x 4.1" x 1.75")
Shipping weight: 0.9kg (2 lbs.)
Environmental: 0°C to 32°C (32°F to 90°F) with 5% to 95%
non-condensing humidity
Ring Output: 5 REN, capable of ringing (10) 0.5 REN phones
Talk Battery: 32V DC
Relay Contact Rating: 5A @ 30VDC / 250VAC Maximum
Connections: (12) cage clamp screw terminals
C-250
C-250
Entry Phone Controller
