Bissell PROHEAT 2X REVOLUTION PET 2457F User Manual page 12

Cleaning with Stain Trapper Tool
WARNING
1
Attach the Stain Trapper
Tool to the end of the hose.
4
Dump dirty water into a
sink or toilet and rinse the
tank out with clean water.
CLEANING THE STAIN TRAPPER TOOL: Clean the front of the tool by removing
the plate over the suction plate. Pull down to remove and rinse with water.
Then replace the plate by sliding back into place.
12
BISSELL.com
Keep spray away from face. Failure to do so may result in personal injury.
2
Slowly move the tool back
and forth over the stain.
Be careful not to move the
tool back and forth too
quickly or soiled water will
flow back into the hose.
5
3
To empty the Stain Trapper
Tool, rotate the small tank
on the bottom of the tool
to unlock it.
Replace the tank by
lining up the locking
teeth with their mating
slots (make sure the
two teeth that are
closest together are
pointed toward the
brush). Turn the tank
to lock it into place.
