Owner's Instruction and Operation Manual

Model Numbers:

VG2020-P •

VG2020-L

•

Report Number: F19-476

Tested Per EPA Methods ALT-125, ASTM

E2515, ASTM E3053 and CSA B415

Certified to UL 1482-2011 (R2015) and

ULC-S627-00-REV1

Mobile home approved (U.S. ONLY)

* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.

SAFETY NOTICE: If this heater is not properly installed, a house fire may result. For

your safety, follow the installation instructions. Never use make-shift compromises

during the installation of this heater. Contact local building or fire officials about

permits, restrictions and installation requirements in your area. NEVER OPERATE THIS

PRODUCT WHILE UNATTENDED.

CAUTION! Please read this entire manual before you install or use your new room

heater. Failure to follow instructions may result in property damage, bodily injury, or

even death. Improper Installation Will Void Your Warranty!

U.S. Environmental Protection Agency

Certified to comply with 2020 particulate

emissions standards.

VG2020-BP

VG2020-BL

Save These Instructions In A Safe Place For Future Reference.

THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.

CALIFORNIA PROPOSITION 65 WARNING:

This product can expose you to chemicals

including carbon monoxide, which is known to the

State of California to cause cancer, birth defects,

and/or other reproductive harm. For more

information, go to

853527H-1805K

www.P65warnings.ca.gov

Ph. 800-750-2723

Table of Contents

Summary of Contents for Vogelzang International VG2020-P

Page 1 Owner’s Instruction and Operation Manual Model Numbers: VG2020-P • VG2020-BP VG2020-L • VG2020-BL Report Number: F19-476 Tested Per EPA Methods ALT-125, ASTM E2515, ASTM E3053 and CSA B415 Certified to UL 1482-2011 (R2015) and ULC-S627-00-REV1 Mobile home approved (U.S. ONLY) * All Pictures In This Manual Are For Illustrative Purposes Only.
Page 2 INTRODUCTION The instructions pertaining to the installation of your wood stove comply with UL-1482 (R2015) and ULC-S627 standards. This manual describes the installation and operation of the Vogelzang, VG2020 wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s cordwood emission limits for wood heaters sold after May 15, 2020. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 15,261 to 63,196 Btu/hr with 1 g/hr and 70% efficiency.
Page 3: Installation Checklist
INSTALLATION CHECKLIST Your Wood Stove should be installed by a qualified installer only. An NFI qualified Installer can be found at www.nficertified. org/public/find-an-nfi-pro/ CUSTOMER SERVICE 1-800-750-2723 ext 5050 Text to 423-301-5624 Email to: Customerservice@usstove.com COMMISSIONING CHECKLIST This Checklist is to be completed in full by the qualified person who installs this unit. Keep this page for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this checklist will invalidate the warranty.
Page 4: Tools And Materials
ASSEMBLY INSTRUCTIONS FOR CUSTOMER SERVICE CALL: 800-750-2723 EXT 5050 TOOLS AND MATERIALS ASH PAN ASSEMBLY You will need a drill with a 1/8” bit to install sheet metal Remove ash pan from firebox. Under the firebox, there are screws into connector pipe. A 5/16” socket/wrench or two brackets;...
Page 5: Installation
ASSEMBLY INSTRUCTIONS FIREBRICK CONFIGURATION AIR DEFLECTOR ASSEMBLY Replace the Firebrick as shown in the illustration. Use the provided screws to attach the air deflector to the rear of the unit. INSTALLATION SAFETY NOTICE • IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT.
Page 6: Floor Protector
INSTALLATION FLOOR PROTECTOR • A flue pipe crossing a combustible wall must have a minimum clearance of 18” (458 mm). This heater must have a non-combustible floor protector with an R-Value of at least 1.4 installed beneath it if the •...
Page 7: Chimney Connector (Stove Pipe)
INSTALLATION 1. Your stove does not draw steadily, smoke roll-out occurs, wood burns poorly, or back-drafts occur whether or not there is combustion present. 2. Existing fuel-fired equipment in the house, such as fireplaces or other heating appliances, smell, do not operate properly, suffer smoke roll-out when opened, or back-drafts occur whether or not there is combustion present.
Page 8: Importance Of Proper Draft
INSTALLATION CHIMNEY a minimum thickness of 0.021” or 0.53 mm. It is strictly forbidden to use galvanized steel. The smoke pipe should be assembled to promote the male section (crimped end) of the pipe to be faced down. Attach each section to another with three metal screws spaced an equal distance apart.
Page 9: Factory Built Chimney
INSTALLATION FACTORY BUILT CHIMNEY When a metal prefabricated chimney is used, the Concrete Cap Fireclay Flue manufacturer’s installation instructions must be followed. Liner With Airspace 1” Clearance You must also purchase (from the same manufacturer) with Firestop and install the ceiling support package or wall pass- through and “T”...
Page 10 INSTALLATION METHOD B - 9” (228.6 mm) Clearance to Combustible Wall Member: Using a 6” (152.4 mm) inside diameter, listed, factory-built Solid-Pak chimney section with insulation of 1” (25.4 mm) or more, build a wall pass-through with a minimum 9” (228.6 mm) air space between the outer wall of the chimney length and wall combustibles.
Page 11 OPERATION INSTRUCTIONS NEVER OPERATE THIS PRODUCT WHILE UNATTENDED better energy yields than others. Higher efficiencies and CAUTIONS: HOUSE FIRE HAZARDS lower emissions generally result when burning air dried • DO NOT STORE WOOD ON FLOOR PROTECTOR, seasoned hardwoods, as compared to softwoods or too UNDERNEATH STOVEPIPE(S) ANYWHERE...
Page 12: Testing Your Wood
OPERATION INSTRUCTIONS TAMPER WARNING center then the wood should be dry enough to burn. If your wood sizzles in the fire, even though the surface is dry, it This wood heater has a manufacturer-set minimum low may not be fully cured and should be seasoned longer. It burn rate that must not be altered.
Page 13: Fueling Instructions
OPERATION INSTRUCTIONS FUELING INSTRUCTIONS position). For a low burn setting once the high burn (or medium) fuel load is burned down to an established coal This wood stove has been certified by the US EPA to bed, load the unit with 19 lbs of cordwood and close the meet strict 2020 guidelines.
Page 14: Blower Operation
OPERATION INSTRUCTIONS BLOWER OPERATION clockwise for slower speeds and counter-clockwise for faster speeds. To turn the blower off, turn the speed The variable-speed blower circulates air warmed by the control knob fully counter-clockwise. It is recommended firebox into the living area to distribute the heat more to turn the blower off when the unit is not in operation.
Page 15: Glass Care
CHIMNEY MAINTENANCE and replace the damaged piece with a new one. Perform CAUTIONS: the procedure backward after replacing it. When • ASHES COULD CONTAIN HOT EMBERS EVEN AFTER replacing the glass, you should change the glass gasket TWO DAYS WITHOUT OPERATING THE STOVE. to make sure you keep it sealed.
Page 16: Repair Parts
REPAIR PARTS Part # Description 40292A 6” Flue Collar 88042 Rope Gasket 1/4” 25845 Air Deflector 891492 Blower Assembly (B36) 26060 Rear Shield 610926 Rear Ashpan (VG2020-BP) 29068 Pedestal (VG2020-BP) 29065 Pedestal Front (VG2020-BP) 610960 Pedestal Weldment (VG2020-BP) 610925 Ashpan Housing (VG2020-BL) 610883 Leg Weldment (VG2020-BL)
Page 17 REPAIR PARTS Part # Description 88316 Kao Wool Blanket 88146 Ceramic Fiber Board 86953 Secondary Air Tube (Ø1/8) 86952 Secondary Air Tube (Ø11/64) 29039 Brick Retainer (left) 29040 Brick Retainer (right) 40561 Ash Plug 24103A Half Pumice Firebrick (4-1/2 X 4-1/2) 891414A Half Firebrick 89066A Pumice Firebrick (4-1/2 X 9)
Page 18: Service Record
SERVICE RECORD It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions.

This manual is also suitable for:

Vg2020-l Vg2020-bp Vg2020-bl Vg2020e
