- Page 1 NOTE: Parts are no longer available for this tool. The manual will continue on the next page.
- Page 2 Form Z287 Date 5-94 INSTRUCTIONS & PARTS LIST FOR 2A2108BTCF ANGLE TORQUE CONTROL TOOL All Sioux Air Tools are manufactured to extremely close tolerances. Reasonable care and preventa- tive maintenance will greatly prolong their service life. This line of tools is designed for a long life of continuous duty on assembly lines, with a minimum of service and maintenance.
- Page 4 PARTS LIST FOR 2A2108BTCF ANGLE TORQUE CONTROL TOOL Fig. Part Fig. Part Description Description 65065 Adaptor—Inlet (Includes Fig. 3) 63192 Ass’y—Rotor Vane (Set of 5) 65066 Bail 64108 Cylinder (Rev) 14378 Ring—“O” 04210 Ring—“O” 21417 Spring 65056 End Plate—Front (Includes Fig. 39)
- Page 5 PARTS LIST FOR 2A2108BTCF ANGLE TORQUE CONTROL TOOL Fig. Part Description 43795 Ass’y—Small Angle Head (Housing) 30356 Fitting—Grease 10012 Bearing—Needle 21545 Ring—Retaining 5. 19721A Ass’y—Gear & Pinion (Includes Fig. 23) 19721 Ass’y—Gear & Pinion (Includes Fig. 23) [Used On Earlier Models] 10226 Bearing—Ball (2)
- Page 6 OPERATION External Adjustment—Uncouple air hose from tool to prevent accidental start up. Remove two These tools are lever operated torque control #07096 screws with 1/8" allen wrench. One screw tools. The air motor starts when the operating is on outside of clutch case which unlocks the lever is depressed.
- Page 7 Printed In U.S.A.
- Page 8 This pdf incorporates the following model numbers: 2A2108BTCF...
