1.4.2 PIM Site Connector and Pinout (J10)

Figure 1-6 PIM Site (J10) Connector

Table 1-2 PIM Site (J10) Connector Pinout

PIM Connector (J10)
Left Side
Right Side
Pin
Name
Pin
1
N/C
2
3
N/C
4
5
5.0VDC
6
7
N/C
8
9
N/C
10
11
N/C
12
13
GND
14
15
N/C
16
17
N/C
18
19
N/C
20
21
5.0VDC
22
23
N/C
24
25
N/C
26
27
N/C
28
29
GND
30
31
N/C
32
PIM Connector (J10)
Left Side
Name
Pin
Name
N/C
33
N/C
N/C
35
N/C
N/C
37
5.0VDC
N/C
39
N/C
3.3VDC
41
N/C
N/C
43
N/C
N/C
45
GND
N/C
47
N/C
GND
49
N/C
N/C
51
N/C
N/C
53
5.0VDC
N/C
55
N/C
3.3VDC
57
N/C
N/C
59
N/C
N/C
61
N/C
N/C
63
N/C
Right Side
Pin
Name
34
GND
36
N/C
38
N/C
40
N/C
42
3.3VDC
44
N/C
46
N/C
48
N/C
50
GND
52
N/C
54
N/C
56
N/C
58
3.3VDC
60
N/C
62
N/C
64
N/C
Handling and Installation 12
