Lua API Function and Module Reference

5 Lua API Function and Module Reference
5.1

Lua Callback Functions Called from C

5.1.1

Function 'initialize'

initialize()
Called once while the firmware is being initialized. It is used to register CAN and MQTT messages
for reception and to initialize variables.
5.1.2

Function 'loop'

loop(ticks, elapsed)
Called cyclically every 100 ms after the initialization phase, when the device is up and running. It
is used to trigger cyclically recurring tasks.
• ticks: counter value that is incremented with each call of loop
• elapsed: time in ms since the last call of loop
5.1.3

Function 'on_can'

on_can(topic, port, format, ident, data)
Called on each CAN message reception, based on message registrations via
can.register_msg.
• topic: user defined reference value used by
port: CAN port number (1 .. 4), depending on the available CAN ports of the target device
• format: combination of three characters to specify the message format, e.g.:
– csr means: "classic CAN", "standard identifier (11 bit)", "remote frame"
– fed means: "CAN-FD", "extended identifier (29 bit)", "data frame"
• ident: CAN message identifier (0 .. 0x7FF for standard messages and 0 .. 0x1FFFFFFF
for extended messages)
• data: message data bytes provided as Lua table or as byte array (see module array)
5.1.4

Function 'on_mqtt'

on_mqtt(handle, topic, payload, qos)
Called on each MQTT message reception, based on message registrations via
mqtt.subscribe.
• handle: user defined reference value used by
• topic: message topic as string
• paqload: message data as string
• qos: quality of service (0, 1, 2)
CAN@net NT/CANbridge NT User Manual
can.register_msg
mqtt.subscribe
4.02.0332.20002 1.2 en-US
12 (22)
