Creating Lua Scripts
4.2

Example Applications

Various example applications can be found after installation of the CAN-Gateway Configurator
download package in folder C:\Users\Public\Documents\HMS\Ixxat CAN-Gateway Configurator
\\Examples\Lua.
Example application
\can_demo.lua
\canfd_demo.lua
\coroutine.lua
\hello_world.lua
\iso15765.lua
\mqtt.lua
\mqtt_json.lua
\repack.lua
CAN@net NT/CANbridge NT User Manual
Description
Shows how to handle (send and receive) CAN messages via Lua.
Shows how to handle (send and receive) CAN FD messages via Lua.
Implements a task and delay function and show how more than one
task can be executed simultaneously.
Read and output ADK and device information, additionally blink with
the user LED.
Segmentation of large CAN FD messages into classic CAN messages
using the ISO 15765-2 transport protocol
Shows how to subscribe and publish MQTT messages.
Subscribes MQTT JSON messages and sends the messages on CAN and
vice versa.
Repack the data bytes of a receive CAN messages from CAN1 and send
on CAN2
